宽广吸力范围内弱膨胀土的抗剪强度及其预测

张俊然, 孙德安, 姜彤, 黄志全

张俊然, 孙德安, 姜彤, 黄志全. 宽广吸力范围内弱膨胀土的抗剪强度及其预测[J]. 岩土工程学报, 2016, 38(6): 1064-1070. DOI: 10.11779/CJGE201606013
引用本文: 张俊然, 孙德安, 姜彤, 黄志全. 宽广吸力范围内弱膨胀土的抗剪强度及其预测[J]. 岩土工程学报, 2016, 38(6): 1064-1070. DOI: 10.11779/CJGE201606013
shu
ZHANG Jun-ran, SUN De-an, JIANG Tong, HUANG Zhi-quan. Shear strength of weakly expansive soils and its prediction in a wide range of suction[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(6): 1064-1070. DOI: 10.11779/CJGE201606013
Citation: ZHANG Jun-ran, SUN De-an, JIANG Tong, HUANG Zhi-quan. Shear strength of weakly expansive soils and its prediction in a wide range of suction[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(6): 1064-1070. DOI: 10.11779/CJGE201606013
shu

宽广吸力范围内弱膨胀土的抗剪强度及其预测  English Version

  • 1. 华北水利水电大学河南省岩土力学与结构工程重点实验室,河南 郑州 450045；
    2. 上海大学土木工程系,上海 200072

基金项目: 国家自然科学基金面上项目（11272194）; 华北水利水电大学高层次人才基金项目; 河南省基础与前沿研究计划项目（132300410021）; 河南省科技创新人才计划（154100510006）
详细信息
    作者简介:

    张俊然(1984- ),男,博士,讲师,主要从事非饱和土力学的研究工作。E-mail: zhangjunran911@163.com。

Shear strength of weakly expansive soils and its prediction in a wide range of suction

  • 1. Henan Province Key Laboratory of Rock and Soil Mechanics and Structural Engineering, North China University of Water Resources and Electric Power, Zhengzhou 450045, China;
    2. Department of Civil Engineering, Shanghai University, Shanghai 200072, China

摘要

    摘要
  • 摘要: 在宽广吸力范围内对不同吸力的非饱和弱膨胀土进行了一系列吸力控制的三轴剪切试验。关于吸力的施加,较低吸力采用轴平移技术;高吸力采用蒸汽平衡法。试验结果表明：在净应力相同的条件下,试样的应力应变关系曲线随着吸力的增大而升高、剪缩量变小,并且随着吸力的增大其偏应力-应变关系和体变明显地表现出类似超固结土的特性。主要原因是试样受到较大的吸力,弱膨胀土试样失水收缩、孔隙比减小均明显,使试样剪切过程中表现出类似超固结黏土的特性。在宽广吸力范围内,吸力所引起弱膨胀性土体积收缩明显,不可忽视。根据压汞试验结果确定的微观饱和度引入有效饱和度中,再将试验结果与修正后的Bishop非饱和土强度公式的预测值进行比较,证明了修正后的Bishop非饱和土强度公式在宽广吸力范围内可较为准确地预测非饱和弱膨胀土的抗剪强度。
    Abstract: A series of suction-controlled triaxial tests are conducted on unsaturated weakly expansive soils experiencing different suctions in a wide range of suction. With regard to the suction applied, the low and high suctions are imposed by using the axis translation technique and the vapor equilibrium method. The test results show that under the same net stress, the specimen experiencing larger suction shows a higher stress-strain relationship and small contractive volumetric strain shearing, and its deviatoric stress-strain relationship and volumetric strain behavior become more and more similar to deformation characteristics of overconsolidated soils with the increase of the imposed suction. The reason of the above phenomenon is that when the specimen experiences a larger suction, the weakly expansive soils shrink significantly due to the loss of water, and its void ratio decreases obviously, thus the specimen exhibits the deformation characteristics of overconsolidated soils during shearing. In a wide range of suction, the volume shrinkage of weakly expansive soils is significantly caused by the suction, and it cannot be ignored. In addition, on the basis of test data of the mercury intrusion porosimetry (MIP), the Bishop’s equation for unsaturated soils is modified by introducing the concept of the effective degree of saturation. A comparison between the measured and the predicted results shows that the modified equation can predict the strength of unsaturated Nanyang weakly expansive soils well in a wide range of suction.
    • HTML全文
    • 参考文献(19)
  • [1] 孔令伟, 陈正汉. 特殊土与边坡技术发展综述[J]. 土木工程学报, 2012, 45(5): 141-161. (KONG Ling-wei, CHEN Zheng-han. Advancement in the techniques for special soils and slopes[J]. China Civil Engineering Journal, 2012, 45(5): 141-161. (in Chinese))
    [2] 卢再华, 陈正汉, 曹继东. 原状膨胀土的强度变形特性及其本构模型研究[J]. 岩土力学, 2001, 22(3): 339-342. (LU Zai-hua, CHEN Zheng-han, CAO Ji-dong. A study on strength and deformation characteristics and the constitutive model of natural expansive soils[J]. Rock and Soil Mechanics, 2001, 22(3): 339-342. (in Chinese))
    [3] 龚壁卫, 周小文, 周武华. 干—湿循环过程中吸力与强度关系研究[J]. 岩土工程学报, 2006, 28(2): 207-209. (GONG Bi-wei, ZHOU Xiao-wen, ZHOU Wu-hua. Test on suction and strength of expansive soil in adsorption-absorption cycle of moisture[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(2): 207-209. (in Chinese))
    [4] 缪林昌, 崔 颖, 陈可君, 等. 非饱和重塑膨胀土的强度试验研究[J]. 岩土工程学报, 2006, 28(2): 274-276. (MIAO Lin-chang, CUI Ying, CHEN Ke-jun, et al. Test on strength of unsaturated remolded expansive soils[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(2): 274-276. (in Chinese))
    [5] 詹良通, 吴宏伟. 非饱和膨胀土变形和强度特性的三轴试验研究[J]. 岩土工程学报, 2006, 28(2): 196-201. (ZHAN Liang-tong, NG C W W. Experimental study on mechanical behavior of recompacted unsaturated expansive clay[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(1): 82-87. (in Chinese))
    [6] 刘斯宏, 汪易森, 朱克生, 等. 有荷条件下南阳膨胀土强度试验及其应用[J]. 水利学报, 2010, 41(3): 361-367. (LIU Si-hong, WANG Yi-sen, ZHU Ke-sheng, et al. Experimental study on strength characteristics of Nanyang expansive soil under loading and its application[J]. Journal of Hydraulic Engineering, 2010, 41(3): 361-367. (in Chinese))
    [7] 孔令伟, 周葆春, 白 颢, 等. 荆门非饱和膨胀土的变形与强度特性试验研究[J]. 岩土力学, 2010, 31(10): 3036-3042. (KONG Ling-wei, ZHOU Bao-chun, BAI Hao, et al. Experimental study of deformation and strength characteristics of Jingmen unsaturated expansive soil[J]. Rock and Soil Mechanics, 2010, 31(10): 3036-3042. (in Chinese))
    [8] 包承纲, 郭熙灵, 程展林, 等. 南水北调 (中线) 工程若干岩土问题研究[C]// 中国土木工程学会第九届土力学及岩土工程学术会议. 北京, 2003: 120-132. (BAO Cheng-gang, GUO Xi-ling, CHENG Zhan-lin, et al. Geotechnical research in the middle route of South-to-North Water Transfer Project[C]// Proceeding of 9 th National Soil Mechanics and Geotechnial Engineering Academic-China Civil Engineering Society. Beijing, 2003: 120-132. (in Chinese))
    [9] ALONSO E E, PEREIRA J M, VAUNAT J, et al. A microstructurally based effective stress for unsaturated soils[J]. Géotechnique, 2010, 60(12): 913-925.
    [10] ALONSO E E, PINYOL N M, GENS A. Compacted soil behaviour: initial state, structure and constitutive modelling[J]. Géotechnique, 2013, 63(6): 463-478.
    [11] GBJ 112—87 膨胀土地区建筑技术规范[S]. 1987. (GBJ 112—87 Technical code for buildings in expansive soil regions[S]. 1987. (in Chinese))
    [12] ROMERO E, DELLA VECCHIA G, JOMMI C. An insight into the water retention properties of compacted clayey soils[J]. Géotechnique, 2011, 61(4): 313-328.
    [13] SIVAKUMAR V. A critical state framework for unsaturated soils[D]. Sheffield: University of Sheffield, 1993.
    [14] HO D Y F, FREDLUND D G. A multi-stage triaxial test for unsaturated soils[J]. Geotechnical Testing Journal, 1982, 5(2): 18-25.
    [15] ROMERO E, VAUNAT J. Retention curves of deformable clays[C]// Proceedings of International Workshop on Experimental Evidence and Theoretical Approaches in Unsaturated Soils. Trento: A A Balkema, 2000.
    [16] 孙德安, 张俊然, 吕海波. 全吸力范围南阳膨胀土的土-水特征曲线[J]. 岩土力学, 2013, 34(7): 1839-1806. (SUN De-an, ZHANG Jun-ran, LÜ Hai-bo. Soil-water characteristic curve of Nanyang expansive soil in full suction range[J]. Rock and Soil Mechanics, 2013, 34(7): 1839-1806. (in Chinese))
    [17] OIML R121 饱和盐溶液标准相对湿度值[S]. 2000. (OIML R121 The standard values of relative humidity for saturated salt solutions[S]. 2000. (in Chinese))
    [18] BISHOP A W. The principle of effective stress[J]. Tecknisk Ukeblad, 1959, 106(39): 859-863.
    [19] FREDLUND D G, MORGENSTERN N R, WIDGER R A. The shear strength of unsaturated soils[J]. Canadian Geotechnical Journal, 1978, 15(3): 313-321.
