金川水电站地下厂房裂隙围岩渗控效应数值模拟与评价

孙超伟, 柴军瑞, 许增光, 覃源

孙超伟, 柴军瑞, 许增光, 覃源. 金川水电站地下厂房裂隙围岩渗控效应数值模拟与评价[J]. 岩土工程学报, 2016, 38(5): 786-797. DOI: 10.11779/CJGE201605003
引用本文: 孙超伟, 柴军瑞, 许增光, 覃源. 金川水电站地下厂房裂隙围岩渗控效应数值模拟与评价[J]. 岩土工程学报, 2016, 38(5): 786-797. DOI: 10.11779/CJGE201605003
shu
SUN Chao-wei, CHAI Jun-rui, XU Zeng-guang, QIN Yuan. Numerical simulation and assessment of seepage control effects on surrounding fractured rocks of underground powerhouse in Jinchuan Hydropower Station[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(5): 786-797. DOI: 10.11779/CJGE201605003
Citation: SUN Chao-wei, CHAI Jun-rui, XU Zeng-guang, QIN Yuan. Numerical simulation and assessment of seepage control effects on surrounding fractured rocks of underground powerhouse in Jinchuan Hydropower Station[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(5): 786-797. DOI: 10.11779/CJGE201605003
shu

金川水电站地下厂房裂隙围岩渗控效应数值模拟与评价  English Version

  • 1. 西安理工大学西北旱区生态水利工程国家重点实验室,陕西 西安710048;
    2. 三峡大学水利与环境学院,湖北 宜昌 443002

基金项目: 陕西省重点科技创新团队项目（2013KCT-15）；国家自然科学基金项目（51409206，51409208）
详细信息
    作者简介:

    孙超伟(1989- ),男,博士研究生,主要从事水利和岩土工程渗流数值分析研究。E-mail: chao_wei_106@126.com。

  • 中图分类号: TU43

Numerical simulation and assessment of seepage control effects on surrounding fractured rocks of underground powerhouse in Jinchuan Hydropower Station

  • 1. State Key Laboratory of Eco-hydraulic Engineering in Northwest Arid Area, Xi'an University of Technology, Xi'an 710048, China;
    2. College of Hydraulic and Environmental Engineering, China Three Gorges University, Yichang 443002, China

摘要

    摘要
  • 摘要: 针对金川水电站工程区复杂的地质条件和渗控措施,分别建立基于排水孔等效模拟的坝基整体模型和基于密集排水孔“弃孔算法”精细模拟的左岸厂区子模型,采用Signorini型变分不等式和自适应罚函数相结合的稳定渗流分析方法对厂区围岩的长期渗控效应进行论证和敏感性分析。在数值模拟中,为了克服传统分析所采用的均质各向同性渗透系数不能反映裂隙岩体渗透特性的不足,首先根据两岸和坝基岩体优势裂隙组的空间展布情况,基于统计学方法初步确定其渗透系数张量并获得主值及主方向,再根据钻孔压水试验资料确定的等效渗透系数对其进行修正,并通过坝址区的地下水位反分析对该方法进行了验证。结果表明,运行期工况下防渗排水系统对山体地下水位具有控制作用,主变洞和发电机层底板处于自由面之上,厂房和调压室底板稍有承压性。帷幕的渗透特性、辅助排水孔幕以及排水孔间距对渗流场分布影响很小但能显著减小厂房洞室及排水廊道的渗漏量,因此应保证防渗帷幕的施工质量并建议设置辅助排水孔幕,建议中层廊道以下的排水孔间距设为3 m,中层廊道以上的排水孔间距放宽到4.5 m。
    Abstract: A global model of equivalent modeling and a submodel of accurate modeling based on “abandoned hole algorithm” for densely deployed drainage holes are established respectively to simulate the complicated seepage control measures and geological conditions for the underground hydropower cavern area at the left bank of Jinchuan Hydropower Station. The long-term seepage control effects of the surrounding rocks of the underground powerhouse and the sensitivity analysis of seepage control measures for the project design are performed by using the stationary seepage analysis method and combining the variational inequality formulation of Signorini’s type with an adaptive penalty Heaviside function. The method of determining the hydraulic conductivity tensor is modified so that it can accurately overcome the disadvantage of ignoring the permeability characteristics of the fractured rock mass. The principal values and directions of the hydraulic conductivity tensor are first determined by the statistical method based on the measurements of the spatial spreading of fractures, and are then modified using the estimates of isotropic hydraulic conductivity that are calculated according to the water permeability rate from a field water-pressure test, and finally are verified using the inversion analysis. The results show that the integrated seepage-proof drainage system will control the water flow from the reservoir and mountain area efficiently; the cavern walls of generator floor and transformer room will be above the ground water surface under the operating conditions; the floor of the machine hall and the surge chamber are both under pressure slightly. The seepage distribution is not sensitive to the permeability of grouting curtains, auxiliary drainage hole arrays and spacing of drainage holes, which however can reduce the flux from drainage holes obviously. It is suggested that the quality for grouting curtain should be guaranteed and the auxiliary drainage hole arrays should be arranged. A spacing of 3 m can be taken for the drainage holes below the middle drainage tunnels and a larger spacing (e.g., 4.5 m) is suggested for those holes above the middle drainage tunnels.
    • HTML全文
    • 参考文献(31)
  • [1] 刘建刚, 陈建生. 基岩渗漏成因病险堤坝的两个典型实例[J]. 岩石力学与工程学报, 2003, 22(4): 683-688. (LIU Jian-gang, CHEN Jian-sheng. Two typical examples of dykes with defects or in danger resulted from bed rock permeation[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(4): 683-688. (in Chinese))
    [2] XIAO C L, QI W B, LIANG X J. Research on reservoir leakage through the right-bank basalt of Hengshan hydro-project[C]// Proceedings of 2009 International Forum on Porous Flow and Applications. 2009: 877-881.
    [3] 徐瑞春, 段建肖. 水布垭枢纽地质研究与实践[J]. 人民长江, 2007, 38(7): 1-6. (XU Rui-chun, DUAN Jian-xiao. Geological research for Shuibuya hydropower station and practice[J]. Yangtze River, 2007, 38(7): 1-6. (in Chinese))
    [4] CHEN Y F, ZHOU C B, ZHENG H. A numerical solution to seepage problems with complex drainage system[J]. Computers and Geotechnics, 2008, 35(3): 383-393.
    [5] ZHENG H, LIU D F, LEE C F, et al. A new formulation of Signorini’s type for seepage problems with free surfaces[J]. International Journal for Numerical Methods in Engineering, 2005, 64(1): 1-16.
    [6] 田开铭, 万 力. 各向异性裂隙介质渗透性的研究与评价[M]. 北京: 学苑出版社, 1989. (TIAN Kai-ming, WAN Li. Research and evaluation of anisotropic permeability fractured media[M]. Beijing: National Academy Press, 1989. (in Chinese))
    [7] 仵彦卿. 岩体水力学基础(七) 岩体水力学参数的确定方法[J]. 水文地质工程地质, 1998, 3(2): 42-48. (WU Yan-qing. Base of rock mass hydraulics(7): the method to determine hydraulic parameters[J]. Hydrogeology & Engineering Geology, 1998, 3(2): 42-48. (in Chinese))
    [8] 张有天. 岩石水力学与工程[M]. 北京: 中国水利水电出版社, 2005: 126-127. (ZHANG You-tian. Water Rock Mechanics and Engineering[M]. Beijing: Water Power Press, 2005: 126-127. (in Chinese))
    [9] HSIEH P A, NEUMAN S P. Field determination of the three dimensional hydraulic conductivity tensor of anisotropic media[J]. Water Resources Research, 1985, 21(11): 1655-1665.
    [10] 仵彦卿, 张倬元. 岩体水力学导论[M]. 成都: 西南交通大学出版社, 1995. (WU Yan-qing, ZHANG Zhuo-yuan. Introduction to rock hydraulics[M]. Chengdu: Southwest Jiaotong University Press, 1995. (in Chinese))
    [11] 毛昶熙. 渗流计算分析与控制[M]. 北京: 水利电力出版社, 1991. (MAO Chang-xi. Seepage computation analysis & control[M]. Beijing: Water Power Press, 1991. (in Chinese))
    [12] 刘佑荣, 唐辉明. 岩体力学[M]. 北京: 中国地质大学出版社, 1999. (LIU You-rong, TANG Hui-ming. Rock mechanics[M]. Beijing: China University of Geosciences Press, 1999. (in Chinese))
    [13] PARK B Y, KIM K S, KWON S, et al. Determination of the hydraulic conductivity components using a three-dimensional fracture network model in volcanic rock[J]. Engineering Geology, 2002, 66(12): 127-141.
    [14] LEE C H, DENG B W, CHANG J L. A continuum approach for estimating permeability in naturally fractured rocks[J]. Engineering Geology, 1995, 39(102): 71-85.
    [15] SNOW D T. Anisotropic permeability of fractured media[J] . Water Resources Research, 1969, 5(6): 1273-1289.
    [16] 王 媛. 求解有自由面渗流问题的初流量法的改进[J]. 水利学报, 1998, 29(3): 69-74. (WANG Yuan. The modified initial flow method for 3D unconfined seepage computation[J]. Journal of Hydraulic Engineering, 1998, 29(3): 68-74. (in Chinese))
    [17] 陈益峰, 周创兵, 毛新莹, 等. 水布垭地下厂房围岩渗控效应数值模拟与评价[J]. 岩石力学与工程学报, 2010, 29(2): 308-317. (CHEN Yi-feng, ZHOU Chuang-bing, MAO Xin-ying, et al. Numerical simulation and assessment of seepage control effects on surrounding rocks of undergrounding powerhouse in Shuibuya hydropower project[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(2): 308-317. (in Chinese))
    [18] LACY S J, PREVOST J H. Flow through porous media: a procedure for locating the free surface[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 1987, 11(6): 585-601.
    [19] 朱伯芳. 渗流场中考虑排水孔作用的杂交元[J]. 水利学报, 1982 (9): 32-41. (ZHU Bo-fang. Analysis of the effect of draining holes in the seepage field by means of hybrid elements[J]. Journal of Hydraulic Engineering, 1982(9): 32-41. (in Chinese))
    [20] 关锦荷, 刘嘉炘, 朱玉侠. 用排水沟代替排水井列的有限单元法分析[J]. 水利学报, 1984, 15(3): 11-18. (GUAN Jin-he, LIU Jia-xin, ZHU Yu-xia. Finite element analysis of an array of wells replaced by a drainage ditch[J]. Journal of Hydraulic Engineering, 1984, 15(3): 11-18. (in Chinese))
    [21] FIPPS G, SKAGGS R W, NIEBER J L. Drains as a boundary condition in finite elements[J]. Water Resources Research, 1986, 22(11): 689-707.
    [22] 王恩志, 王洪涛, 邓旭东. “以管代孔” 排水孔模拟方法探讨[J]. 岩石力学与工程学报, 2001, 20(3): 346-349. (WANG En-zhi,WANG Hong-tao,DENG Xu-dong. “Pipe to represent hole”: numerical method for simulating single drainage hole in rock masses[J]. Chinese Journal of Rock Mechanics and Engineering, 2001, 20(3): 346-349. (in Chinese))
    [23] 王恩志, 王洪涛, 王慧明. “以缝代井列” 排水孔幕模拟方法探讨[J]. 岩石力学与工程学报, 2002, 21(1): 98-101. (WANG En-zhi, WANG Hong-tao, WANG Hui-ming. “Fissure to represent line of holes”: numerical method for simulating the drainage hole curtain in rock masses[J]. Chinese Journal of Rock Mechanics and Engineering, 2002, 21(1): 98-101. (in Chinese))
    [24] 周创兵, 熊文林, 骆雨文. 坝基岩体排水孔幕的等效模拟[C]// 水工结构研究与应用文集. 武汉: 华中理工大学出版社, 1996: 217-230. (ZHOU Chuang-bing, XIONG Wen-lin, LUO Yu-wen. Equivalent simulation for drainage hole array in dam rock foundation[C]// Proceedings of Development and Application of Hydraulic Structures. Wuhan: Huazhong University of Science and Technology Press, 1996: 217-230. (in Chinese))
    [25] CHEN S H, WANG W M, SHE C X, et al. Unconfined seepage analysis of discontinuous rock slope[J]. Journal of Hydrodynamics (Series B), 2000, 12(3): 75-86.
    [26] 胡 静, 陈胜宏. 渗流分析中排水孔模拟的空气单元法[J]. 岩土力学, 2003, 24(2): 281-287. (HU Jing, CHEN Sheng-hong. Air element method for modelling drainage holes in seepage analysis[J]. Rock and Soil Mechanics, 2003, 24(2): 281-287. (in Chinese))
    [27] CHEN S H, XU Q, HU J. Composite element method for seepage analysis of geotechnical structures with drainage hole array[J]. Journal of Hydrodynamics(Series B), 2004, 16(3): 260-266.
    [28] 王 镭, 刘 中, 张有天. 有排水孔幕的渗流场分析[J]. 水利学报, 1992, 23(4): 15-20. (WANG Lei, LIU Zhong, ZHANG You-tian.Analysis of seepage field near a drainage holes curtain[J]. Journal of Hydraulic Engineering, 1992, 23(4): 15-20. (in Chinese))
    [29] 朱岳明, 张燎军. 渗流场求解的改进排水子结构法[J]. 岩土工程学报, 1997, 19(2): 69-76. (ZHU Yue-ming, ZHANG Liao-jun. Solution to seepage field problem with the technique of improved drainage substructure[J]. Chinese Journal of Geotechnical Engineering, 1997, 19(2): 69-76. (in Chinese))
    [30] 朱国盛, 崔浩东, 张家发, 等. 乌东德水电站坝基及右岸地下厂房区渗控措施研究[J]. 岩土工程学报, 2012, 34(9): 1722-1727. (ZHU Guo-sheng, CUI Hao-dong, ZHANG Jia-fa, et al. Seepage control measures for dam foundation and underground powerhouse caverns at right bank of Wudongde Hydropower Station[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(9): 1722-1727. (in Chinese))
    [31] 崔皓东, 朱岳明, 吴世勇. 有自由面渗流分析的密集排水孔幕数值模拟分析[J]. 岩土工程学报, 2008, 30(3): 440-444. (CUI Hao-dong, ZHU Yue-ming, WU Shi-yong. Numerical simulation for the densely-distributed drainage holes in seepage with free surface[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(3): 440-445. (in Chinese))
