基于高密度电阻率法的水分迁移模型试验研究

刘庭发; 聂艳侠; 胡黎明; 周启友; 温庆博

doi:10.11779/CJGE201604023

基于高密度电阻率法的水分迁移模型试验研究 English Version

1.清华大学水利水电工程系，水沙科学与水利水电工程国家重点实验室，北京100084;
2.南京大学地球科学与工程学院，江苏南京210046

基金项目: 国家重点基础研究发展计划（“973”计划）课题项目; （2012CB719804）; 国家自然科学基金项目（51323014,41372352,

详细信息

作者简介:
刘庭发(1990- ),男,硕士,从事岩土工程方面的研究。E-mail: liutingfa2011@163.com。

中图分类号: TU411
计量
- 文章访问数: 0438
- HTML全文浏览量: 0
- PDF下载量: 0404
出版历程
- 修回日期: 2015-01-18
- 发布日期: 2016-04-24

Model tests on moisture migration based on high-density electrical resistivity tomography method

1. State Key Laboratory of Hydro-Science and Engineering, Department of Hydraulic Engineering, Tsinghua University, Beijing 100084, China;
2. School of Earth Sciences and Engineering, Nanjing University, Nanjing 210046, China

摘要

摘要: 在土工模型试验中,常用的应用于水分及溶质迁移过程量测的传感器量测、图像分析及取样分析等方法并不能充分满足三维、无损、实时的量测需求。高密度电阻率成像法为土工模型试验中三维、无损、实时量测需求提供了新的解决思路。基于高密度电阻率成像法发展一套适用于常规物理模型及超重力离心环境中土体电阻率测试设备和分析方法,并通过开展模型试验验证其应用于水分迁移过程量测的适用性及有效性。常规物理模型试验（1g）表明,该设备及方法能够获得模型土体中电阻率的三维时空分布,入渗过程中电阻率与含水率的分布及变化合理反映电阻率与含水率定性关系; 在低有效饱和度区间,电阻率法具有很高的灵敏度。离心模型试验结果表明,重力水平的变化可导致水分在模型土柱中的分布发生显著变化; 实时量测技术及分析方法可为土工离心环境中渗流及溶质运移过程的分析提供更为准确的依据。高密度电阻率成像法可以成功应用于常规物理模型及超重力离心环境中水分迁移过程量测,并保证一定的精度和灵敏度。
- 电阻率成像法（ERT） /
- 温纳法 /
- 土壤电阻率 /
- 水分迁移 /
- 土工离心模型试验
Abstract: In geotechnical model tests, the methods conventionally employed in measuring water content and solute transport include sensor techniques, image processing techniques and direct soil sampling methods. However, these techniques cannot fully satisfy the necessities of three-dimensional, non-destructive and real-time measurement, especially in geotechnical centrifuge environment. A set of new measuring device and analyzing technique based on the high-density electrical tomography (ERT) method, is developed to investigate water migration at multiple gravitational levels. Two model tests, one on ground and the other in a geotechnical centrifuge, are conduced to verify the capability of the developed device in capturing moisture migration and distribution. The 3D infiltration model tests on ground (1g) show that the device is capable of measuring the 3D spatial and temporal distribution of soil resistivity in the model. The water migration and distribution during the infiltration process is reasonably reflected by the variation and distribution of soil resistivity. The resistivity method presents high sensitivity, especially when the soil is at relatively low saturation degree. In the 50g centrifugal model tests, obvious non-uniformity of water content distribution is observed at the loading and unloading stages, which indicates that moisture migration is highly subjected to gravitational levels and boundary conditions. The capability of real-time measurement and analysis of the ERT method provides critical insights into moisture migration in geotechnical model tests at multiple gravitation levels, and can be fed into a wide range of investigations regarding seepage and solute transport.
- electrical resistivity tomography /
- Wenner array /
- soil resistivity /
- moisture migration /
- centrifugal model test
