新型桶式基础防波堤桶体阻力分析

杨立功; 蔡正银; 徐志峰

doi:10.11779/CJGE201604021

新型桶式基础防波堤桶体阻力分析 English Version

1.同济大学地下建筑与工程系，上海200092;
2.南京水利科学研究院岩土工程研究所，江苏南京210029;
3.江苏科兴项目管理有限公司，江苏南京210021

基金项目: 江苏省科技计划项目（BE201370828）; 江苏省交通运输科; 技项目（2013Y20）; 南京水利科学研究院院基金项目（Y315010）

详细信息

作者简介:
杨立功（1982- ）,男,河南信阳人,博士研究生,主要从事结构与土的相互作用研究。E-mail: 65481875@qq.com。

中图分类号: TU44
计量
- 文章访问数: 371
- HTML全文浏览量: 2
- PDF下载量: 275
出版历程
- 修回日期: 2015-04-23
- 发布日期: 2016-04-24

Numerical analysis of bucket resistance of new bucket foundation breakwater

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China;
2. Nanjing Hydraulic Research Institute, Nanjing 210029, China;
3. Jiangsu Kexing Engineering Construction Superivsion Co., Nanjing 210021, China

摘要

摘要: 包括桶壁、隔墙摩阻力和桶底端阻力的桶体阻力是维持桶体稳定性的一个重要因素。外侧桶壁摩阻力与桶土相对位移及接触状态有关,内侧桶壁和隔墙摩阻力与桶土相对位移有关,桶底端阻力与桶土接触状态有关。波浪荷载作用下,海侧上部的外侧桶壁与土体脱离,下部产生相对土体的向上位移,陆侧桶壁则相反; 海侧内侧桶壁与隔墙产生相对桶内土体的向上位移,陆侧则相反; 海侧桶体底部与土体脱离,陆侧则挤压土体。波浪荷载作用下,在绕桶体转动中心发生向上位移的迎浪侧,随荷载水平增加,桶壁与隔墙摩阻力由桶体自重作用下的正摩阻力减小变为负摩阻力,桶底端阻力则减小直至为零; 在绕桶体转动中心发生向下位移的背浪侧,桶体阻力在桶体自重的基础上增加。
- 新型桶式基础防波堤 /
- 摩阻力 /
- 端阻力
Abstract: The resistance including the frictional resistance on the bucket wall and the partition wall and the end resistance at the bottom of the bucket is an important factor to maintain the stability of the bucket. The frictional resistance on the outside bucket wall is connected with the relative displacement and the contact status between the bucket and the soil. The frictional resistance on the inside bucket wall and the partition wall relates with the relative displacement between the bucket and the soil, while the end resistance at the bottom of the bucket is connected with the contact status between the bucket and the soil. Under wave loads, the upper outside bucket wall breaks away from the soil, and the lower bucket wall generate upward displacement against the soil at the sea side, while the bucket wall at the land side is opposite. At the same time, the inside bucket wall and the partition wall generates upward displacement at the sea side against the soil, and the situation is opposite at the land side, while the bottom breaks away from the soil at the sea side and it compresses the soil at the land side. At the head side of the waves where an upward displacement is generated around the rotating center of the bucket, the frictional resistance on the bucket wall and the partition wall changes from the positive frictional resistance under self-weight to the negative one, and the end resistance at the bottom of the bucket reduces until to zero. At the same time, at the reverse side of the waves where a downward displacement is generated around the rotating center of the bucket, the resistance of the bucket increases based on its self-weight.
- new bucket foundation breakwater /
- frictional resistance /
- end resistance

HTML全文

参考文献(10)

[1]	王元战, 王海龙, 付瑞清. 沉入式大直径圆筒码头稳定性计算方法研究[J]. 岩土工程学报, 2002, 24(4): 417-420. (WANG Yuan-zhan, WANG Hai-long, FU Rui-qing. Method of stability analysis of embedded large-diameter cylinder quay[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(4): 417-420. (in Chinese))
[2]	WANG Y Z, ZHU Z Y. An approach to stability analysis of embedded large-diameter cylinder quay[J]. China Ocean Engineering, 2002, 16(3): 383-393.
[3]	王元战, 王文良. 大圆筒结构计算及工程应用[M]. 北京: 人民交通出版社, 2008. (WANG Yuan-zhan, WANG Wen-liang. The computational method and engineering application of large-diameter cylindrical structure[M]. Beijing: China Communications Press, 2008. (in Chinese))
[4]	范庆来. 软土地基上深埋式大圆筒结构稳定性研究[D]. 大连: 大连理工大学, 2005. (FAN Qing-lai. A study of stability deeply embedded large-diameter cylindrical structure in soft ground[D]. Dalian: Dalian University of Technology, 2005. (in Chinese))
[5]	吴梦喜. 软土地基中深埋式大圆筒结构的承载机制与稳定性分析方法[C]// 第九届土力学及岩土工程学术会议论文集. 北京: 清华大学出版社, 2003: 593-598. (WU Meng-xi. The bearing mechanism and stability analysis method of embedded large- diameter in soft ground[C]// Academic Collected Papers of Soil Mechanics and Geotechnical Engineering of the Ninth Session. Beijing: Tsinghua University Press, 2003: 593-598. (in Chinese))
[6]	肖忠, 王元战, 及春宁. 基于极限平衡法的箱筒型基础防波堤稳定性分析[J]. 岩土工程学报, 2013, 35(5): 828-833. (XIAO Zhong, WANG Yuan-zhan, JI Chun-ning. Stability analysis of bucket foundation breakwaters based on limit equilibrium method[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(5): 828-833. (in Chinese))
[7]	徐光明, 章为民, 赖忠中. 沉入式大圆筒结构码头工作机理离心模型试验研究[J]. 海洋工程, 2001, 19(1): 38-43. (XU Guang-ming, ZHANG Wei-min, LAI Zhong -zhong. Centrifuge modeling of quay walls composed of large-diameter cylinders embedded below mud line[J]. Ocean Engineering, 2001, 19(1): 38-43. (in Chinese))
[8]	王元战, 迟丽华. 考虑土体竖向剪切刚度的大直径圆筒结构变位计算方法[J]. 水运工程, 1996, 12: 1-5. (WANG Yuan-zhan, CHI Li-hua. Method of displacement calculation of large-diameter cylinder considering soil vertical shear stiffness[J]. Port & Waterway Engineering, 1996, 12: 1-5. (in Chinese))
[9]	王元战, 迟丽华. 沉入式圆筒结构与土相互作用的模式及位移计算方法[J].土木工程学报, 1997, 30(2): 68-73. (WANG Yuan-zhan, CHI Li-hua. Mode of interaction between embedded large-diameter cylinder and soil and method of displacement calculation[J]. China Civil Engineering Journal, 1997, 30(2): 68-73. (in Chinese))
[10]	迟丽华, 王玉红. 一种切力模型下大圆筒结构位移的迭代算法[J]. 天津大学学报, 1998, 31(1): 85-89. (CHI Li-hua, WANG Yu-hong. An iterative approach to the displacements of large cylinder based on a vertical shear model [J]. Journal of Tianjin University, 1998, 31(1): 85-89. (in Chinese))
