线热源法测量冻土热参数的适用性分析

周家作, 韦昌富, 魏厚振, 陈 盼

周家作, 韦昌富, 魏厚振, 陈 盼. 线热源法测量冻土热参数的适用性分析[J]. 岩土工程学报, 2016, 38(4): 681-687. DOI: 10.11779/CJGE201604012
引用本文: 周家作, 韦昌富, 魏厚振, 陈 盼. 线热源法测量冻土热参数的适用性分析[J]. 岩土工程学报, 2016, 38(4): 681-687. DOI: 10.11779/CJGE201604012
ZHOU Jia-zuo, WEI Chang-fu, WEI Hou-zhen, CHEN Pan. Applicability of line heat source method in measuring thermal parameters of frozen soil[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(4): 681-687. DOI: 10.11779/CJGE201604012
Citation: ZHOU Jia-zuo, WEI Chang-fu, WEI Hou-zhen, CHEN Pan. Applicability of line heat source method in measuring thermal parameters of frozen soil[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(4): 681-687. DOI: 10.11779/CJGE201604012

线热源法测量冻土热参数的适用性分析  English Version

基金项目: 国家重点基础研究计划(“973”)课题(2012CB026102); 国家自然科学基金重点项目(51239010); 国家自然科学基金面上项目(41572293)
详细信息
    作者简介:

    周家作(1987- ),男,助理研究员,博士,主要从事冻土力学方面的研究。E-mail: jiazuoz@gmail.com。

  • 中图分类号: TU445

Applicability of line heat source method in measuring thermal parameters of frozen soil

  • 摘要: 提出了应用线热源法测量冻土热参数存在的问题,冻土中未冻水含量随温度的变化是导致线热源法测量误差产生的根本原因。对二维无限大——点热源热传导方程进行简化得到一维中心对称——热流边界热传导方程。采用双针法对不同温度的环刀土样进行了测试并对冻土传热过程进行数值试算,反演得到不同温度的相变热容和未冻水含量。结果表明:当温度大于-0.7℃时,相变热容值远远大于冻土体积热容并且随温度急剧变化,线热源法测量的结果严重失真; 当温度介于-0.7~-4℃时,线热源法测量结果仍有较大的误差; 当温度低于-4℃时,相变热容值很小且比较稳定,线热源法测量的热参数能满足一定的精度要求。
    Abstract: The problem in the line heat source method in measuring the thermal parameter of frozen soil is put forward. The variation of unfrozen water content with respect to temperature is the primary cause for the measuring error in the heat source method. The 2-D heat conduction equation for infinite zone-point heat source is simplified as the 1-D one for central symmetry-heat flow boundary. The dual needle method is used to measure the soil samples in cutting ring at various temperatures, and the corresponding numerical simulations for heat conduction are conducted. The volumetric heat capacity due to phase change and unfrozen water content is obtained through back calculation. The results show that as the temperature of soil is higher than -0.7 ℃, the volumetric heat capacity due to phase change is much greater than the volumetric heat capacity of frozen soil, and it varies with the temperature drastically, hence the heat source method loses efficacy; as the temperature of soil is ranging from -0.7~-4 ℃, the measured error remains larger in the volumetric heat capacity. As the temperature of soil is lower than -4℃, the volumetric heat capacity due to phase change is little and steady so that the measured thermal parameters meet the requirements of accuracy to a certain degree.
  • [1] 尹 飞. 冻土导热系数的仪器研制和稳态法模拟试验研究[D]. 长春: 吉林大学, 2008. (YIN Fei. The instrumental development of thermal conductivity of frozen ground and the research on the steady-state method simulation test[D]. Changchun: Jilin University, 2008. (in Chinese))
    [2] 郑志涛. 冻土导热系数测定方法探讨[J]. 低温建筑技术, 2013(12): 124-125. (ZHENG Zhi-tao. Determination method for thermal conductivity of frozen ground[J]. Low Temperature Architecture Technology, 2013(12): 124-125. (in Chinese))
    [3] 侯方卓. 用探针法测定材料的导热系数[J]. 石油大学学报(自然科学版), 1994, 18(5): 94-98. (HOU Fang-zhuo. Measurement of thermal conductivity of materials by the heated probe method[J]. Journal of The University of Petroleum, China, 1994, 18(5): 94-98. (in Chinese))
    [4] 金文桂. 用线热源法测定非金属材料的导热系数[J]. 吉林工业大学学报, 1981(4): 36-43. (JIN Wen-gui. Measuring the heat conductivity of non-metallic material by line heat source method[J]. Journal of Jilin University of Technology, 1981(4): 36-43. (in Chinese))
    [5] 杨 杰. 平面热源法对建筑保温材料热导率和热扩散率的测试研究[D]. 长沙: 中南大学, 2014. (YANG Jie. Research on the test of thermal conductivity and thermal diffusivity for thermal insulation materials for building application with plane source method[D]. Changsha: Central South University, 2014. (in Chinese))
    [6] Decagon Devices. KD2 pro thermal properties analyzer, operator's manual (version 12)[M]. Washington: Decagon Devices Inc, 2012.
    [7] JOHANSEN O. Thermal conductivity of soils[R]. New Hampshire: Cold Regions Research & Engineering Laboratory, US Army Corps of Engineers, 1977.
    [8] 马 巍, 王大雁. 冻土力学[M]. 北京: 科学出版社, 2014: 7-8. (MA Wei, WANG Da-yan. Frozen soil mechanics[M]. Beijing: Science Press, 2014: 7-8. (in Chinese))
    [9] DE VRIES D A. A nonstationary method for determining thermal conductivity of soil in situ[J]. Soil Science, 1952, 73(2): 83-89.
    [10] KLUITENBERG G J, HAM J M, BRISTOW K L. Error analysis of the heat pulse method for measuring soil volumetric heat capacity[J]. Soil Sci Soc Am J, 1993, 57(6): 1444-1451.
    [11] ABRAMOWITZ M, STEGUN I A. Handbook of mathematical functions[M]. New York: Dover Publications Inc, 1972.
    [12] 李 璗, 薛中天. 指数积分函数展开式的初等证明方法[J]. 西安石油学院学报, 1988, 3(1): 57-63. (LI Dang, XUE Zhong-tian. Elementary approach for proving the expansion of exponential integral function[J]. Journal of Xi'an Petroleum Institute, 1988, 3(1): 57-63. (in Chinese))
    [13] DE VRIES D A. Thermal properties of soils. In Physics of plant environment[M]. Amsterdam: North Holland Publishing Company, 1963.
    [14] NUSIER O K, ABU-HAMDEH N H. Laboratory techniques to evaluate thermal conductivity for some soils[J]. Heat and Mass Transfer, 2003, 39(2): 119-123.
    [15] 邱 萍, 郑金宝, 胡胜利. 显热容法分析快速冻结过程中的相边界面移动问题[J]. 低温工程, 1993(6): 57-61. (QIU Ping, ZHENG Jin-bao, HU Sheng-li. Analysis of the phase change moving boundary probleme in the rapid freezing processes using sensible heat capacity method[J]. Cryogenics, 1993(6): 57-61. (in Chinese))
    [16] LIU G, BING C S. Soil ice content measurement using a heat pulse probe method[J]. Can J Soil Sci, 2011, 91(2): 235-246.
    [17] 刘宗超. 湿土冻结温度及其测定[J]. 中国矿业学院学报, 1986(3): 24-31. (LIU Zong-chao. Freezing points of wet soil and its measurement[J]. Journal of China University of Mining & Technology, 1986(3): 24-31. (in Chinese))
    [18] 周家作, 谭 龙, 韦昌富, 等. 土的冻结温度与过冷温度试验研究[J]. 岩土力学, 2015, 36(3): 777-785. (ZHOU Jia-zuo, TAN Long, WEI Chang-fu, et al. Experimental study on the freezing temperature and super-cooling temperature of soil[J]. Rock and Soil Mechanics, 2015, 36(3): 777-785. (in Chinese))
    [19] 文 斌, 吴青柏, 蒋观利, 等. 模拟退火优化算法的冻土热传导参数反分析[J]. 岩土力学, 2013, 34(8): 2401-2408. (WEN Bin, WU Qing-bai, JIANG Guan-li, et al. Back analysis of frozen soil thermal properties based on simulated annealing optimization algorithm[J]. Rock and Soil Mechanics, 2013, 34(8): 2401-2408. (in Chinese))
