高填黄土明洞卸载结构土压力模型试验和数值模拟分析

李 盛; 马 莉; 王起才; 李善珍; 李建新; 张延杰

doi:10.11779/CJGE201604007

高填黄土明洞卸载结构土压力模型试验和数值模拟分析 English Version

1.兰州交通大学土木工程学院，甘肃兰州730070;
2.兰州工业学院土木工程学院，甘肃兰州730050

基金项目: 长江学者和创新团队发展计划项目（IRT_15R29）; 国家自; 然科学基金青年基金项目（51408289,41402252）

详细信息

作者简介:
李盛(1982- ),男,博士,副教授,主要从事桥梁与隧道方面的教学与研究。E-mail: ligwin@126.com。

中图分类号: TU43
计量
- 文章访问数: 0384
- HTML全文浏览量: 0
- PDF下载量: 0377
出版历程
- 修回日期: 2015-02-07
- 发布日期: 2016-04-24

Model tests and numerical simulations of earth pressure for unloading structures of high fill open cut tunnel

1. College of Civil Engineering, Lanzhou Jiaotong University, Lanzhou 730070, China;
2. College of Civil Engineering, Lanzhou Institute of Technology, Lanzhou 730050, China

摘要

摘要: 通过模型试验,研究了高填黄土明洞不同卸载结构的土压力、土体位移随填土高度的变化规律。试验结果表明,边坡的摩擦上提作用、低压实土产生的土拱效应以及土工格栅变形后的“提兜”作用均能够引起明洞洞顶土压力的减小,其中,低压实土+土工格栅卸载结构卸载率最大; 卸载结构不同,明洞顶平面土压力分布规律不同,SY0和SY1在1倍明洞宽度范围内的土压力近似为梯形分布,大于1倍明洞宽度的土压力基本保持不变,近似为均匀分布,SY2~SY5明洞中轴线到0.75倍明洞宽度处,土压力基本保持一致,大于0.75倍明洞宽度的土压力呈先增大后减小的趋势。随后对试验过程进行了数值模拟分析,两者结果较为吻合。最后探讨了土拱效应形成机理,从而为高填明洞土压力卸载技术的进一步研究提供科学依据。
- 高填明洞 /
- 土压力 /
- 土拱效应 /
- 卸载措施
Abstract: The influence laws of earth pressure and soil displacement for different unloading structures of high fill loess open cut tunnel with the increase of filling height are studied through the model tests. The results show that the friction resistance of slope, the soil arch effect of low compacted soil and the geogrid effect can reduce the earth pressure of the open cut tunnel, and the unloading rate of low compacted soil and geogrid is the largest. Under different unloading structures, the distribution law of earth pressure on the top of the open cut tunnel is also different. Within the scope of 1 times the width, the earth pressures of SY0 and SY1 are approximately in trapezoidal distribution. Within the scope of over 1 times the width, the earth pressures keep unchanged, and are approximately in uniform distribution. The earth pressures are basically consistent in the scope of the central axis to 0.75 times the width, and they increase at first and decrease later within the scope of over 0.75 times the width. Based on the numerical simulation analysis, the test and numerical results are basically identical. Finally, the formation mechanism of soil arch effect is discussed so as to provide a scientific evidence for further researches on the unloading technology of the earth pressure of the high fill open cut tunnel.
- high fill open cut tunnel /
- earth pressure /
- soil arch effect /
- unloading measure

HTML全文

参考文献(15)

[1]	MARSTON A. The theory of external loads on closed conduits in the light of the latest experiments[C]// Highway Research Board Proceedings. Washington D C, 1930: 138-170.
[2]	SPANGLER M G. A theory on loads on negative projecting conduits[C]// Highway Research Board Proceedings. Washington D C, 1950: 153-161.
[3]	LARSEN N G, HENDRICKSON J G. A practical method for construction rigid conduits under high fills[C]// Highway Research Board Proceedings. Washington D C, 1962: 273-280.
[4]	SPANGLER M G. Induced-trench method of culvert installation[C]// Highway Research Record. Washington D C, 1973: 15-31.
[5]	DANCYGIER A N, YANKELEVSKY D Z. A soft layer to control soil arching above a buried structure[J]. Engineering Structures, 1996, 18(5): 378-386.
[6]	顾安全, 郭婷婷, 王兴平. 高填土涵洞(管)采用EPS板减荷的试验研究[J]. 岩土工程学报, 2005, 27(5): 500-504. (GU An-quan, GUO Ting-ting, WANG Xing-ping. Experiment study on reducing-load measurement using EPS of culvert under high-stacked soil[J]. Chinese Joural of Geotechnical Engineering, 2005, 27(5): 500-504. (in Chinese))
[7]	顾安全, 吕镇锋, 姜峰林, 等. 高填土盖板涵EPS板减荷试验及设计方法[J]. 岩土工程学报, 2009, 31(10): 1481-1486. (GU An-quan, LÜ Zhen-feng, JIANG Feng-lin, et al. Load reduction tests and design methods for culverts with high fill soil using EPS slabs[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(10): 1481-1486. (in Chinese))
[8]	杨锡武. 山区公路高填方涵洞土压力理论及加筋减载研究 [D]. 重庆: 重庆大学, 2004. (YANG Xi-wu. Research on the earth pressure theory and reinforcement load reduction for the culverts beneath high fill[D]. Chongqing: Chongqing University, 2004. (in Chinese))
[9]	杨锡武, 张永兴. 山区公路高填方涵洞加筋桥减载方法及其设计理论研究[J]. 岩石力学与工程学报, 2005, 24(9): 1561-1571. (YANG Xi-wu, ZHANG Yong-xing. Study on the method and theory of load reduction by reinforcement bridge for the culvert beneath high filling[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(9): 1561-1571. (in Chinese))
[10]	康佐, 谢永利, 冯忠居, 等. 应用离心模型试验分析涵洞病害机理[J].岩土工程学报, 2006, 28(6): 784-788. (KANG Zuo, XIE Yong-li, FENG Zhong-ju, et al. Studies on distress mechanism of culverts by centrifugal model test[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(6): 784-788. (in Chinese))
[11]	康佐, 谢永利, 杨晓华, 等. 减荷拱涵周围土体位移变化的离心模型试验[J]. 中国公路学报, 2006, 19(6): 13-18. (KANG Zuo, XIE Yong-li, YANG Xiao-hua, et al. Centrifugal model test on displacement variation of earth surrounding reducing-load arch culvert[J]. China Journal of Highway and Transport, 2006, 19(6): 13-18. (in Chinese))
[12]	马强, 郑俊杰, 张军, 等. 高填方涵洞减载机制与数值分析[J]. 岩土力学, 2010, 31(增刊1): 424-429. (MA Qiang, ZHENG Jun-jie, ZHANG Jun, et al. Mechanism analysis and numerical simulation on load reduction for culvert beneath high filling[J]. Rock and Soil Mechanics, 2010, 31(S1): 424-429. (in Chinese))
[13]	郑俊杰, 马强, 张军. 加筋减载涵洞的涵顶土压力计算[J]. 岩土工程学报, 2011, 33(7): 1135-1141. (ZHENG Jun-jie, MA Qiang, ZHANG Jun. Calculation of vertical earth pressure on load reduction culverts under embankments by reinforcement[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(7): 1135-1141. (in Chinese))
[14]	马强. 高填涵洞受力特性及新型格栅卸载方法研究[D]. 武汉: 华中科技大学, 2011. (MA Qiang. Study on stress charaeteristies and load reduetion by triax geogrid reinforeement for high embankment cuIverts[D]. Wuhan: Huazhong University of Science and Technology, 2011. (in Chinese))
[15]	马强, 郑俊杰, 张军. 高填方涵洞加筋减载的现场试验研究[J]. 岩土力学, 2012, 33(8): 2337-2342, 2348. (MA Qiang, ZHENG Jun-jie, ZHANG Jun. Experimental study of high embankment culvert treated by imperfect ditch covered with a geogrid layer[J]. Rock and Soil Mechanics, 2012, 33(8): 2337-2342, 2348. (in Chinese))
