条形荷载下土工格室加筋砂土路堤模型试验研究

孙州; 张孟喜; 姜圣卫

doi:10.11779/CJGE2015S2033

条形荷载下土工格室加筋砂土路堤模型试验研究 English Version

1. 上海大学土木工程系,上海 200072; 2. 江苏省仪征市佳和土工材料有限公司,江苏仪征 211401

基金项目: 国家自然科学基金项目（41372280）

详细信息

作者简介:
孙州(1988- ),男,硕士研究生,主要从事新型土工加筋技术方面的研究工作。

计量
- 文章访问数: 0214
- HTML全文浏览量: 0
- PDF下载量: 0261
出版历程
- 收稿日期: 2015-03-25
- 发布日期: 2015-07-24

Model tests on sand embankment reinforced with geocell subjected to strip loading

1. Department of Civil Engineering, Shanghai University, Shanghai 200072, China; 2. Jiahe Geosynthetics Company, Yizheng 211401, China

摘要

摘要: 为了探讨不同土工格室加筋方式对路堤应力变形特性和不均匀沉降的控制效果,分别对纯砂路堤边坡和土工格室加筋路堤进行多组模型试验,研究了土工格室焊距、埋深、加筋层数以及压实度对路堤承载力特性和变形特性的影响,同时结合土工格室材料应变的变化规律和加筋路堤的坡面变形状态分析了土工格室加筋路堤的破坏模式。试验结果表明：格室加筋效果随着焊距、加筋深度的减小而增加,随着压实度、加筋层数的增加而增加;土工格室加筋路堤承载力是纯砂的2.5倍左右,提高了路堤的极限承载力,减小了路堤沉降,并且土工格室加筋路堤坡面侧向位移比纯砂路堤减小了75%。
- 土工格室 /
- 加筋路堤 /
- 模型试验 /
- 压实度 /
- 侧向变形
Abstract: A series of model tests are carried out on pure embankment and reinforced embankment with geocell to study the effect of the different reinforced types of geocell on variation characteristic of stress and differential settlement in embankment. The influences of welded spacing, single-layer reinforcement depth, reinforcement layers and soil compaction on the bearing capacity and deformation of the embankment are investigated. At the same time, the failure mode of reinforced embankment is analyzed according to the distribution of tensile strain of geocell and the failure state of embankment slope. The results show that the effect of reinforcement increases with the decrease of geocell welded spacing and single-layer geocell depth, moreover, the effect of reinforcement increases with the increase of reinforcement layers and the embankment compaction. The bearing capacity of reinforcement embankment is about 2.5 times that of the pure sand, improves the bearing capacity and reduces the settlement of reinforcement embankment, and the lateral displacement of embankment slope is reduced by 75% than that of the pure sand embankment.
- geocell /
- reinforced embankment /
- model test /
- degree of compaction /
- lateral deformation

HTML全文

参考文献(11)

[1]	ALAWAJI H A. Settlement and bearing capacity of geogrid-reinforced sand over collapsible soil[J]. Geotextiles and Geomembranes, 2001, 19(2): 75-88.
[2]	EL SAWWAF M A. Behavior of strip footing on geogrid-reinfored sand over a soft clay slop[J]. Geotextiles and Geomembranes, 2007, 25(1): 50-60.
[3]	BERGADO D T, LONG P V, SRINIVASA MURTHY B R. A case study of geotextile-reinforced embankment on soft ground[J]. Geotextiles and Geomembranes, 2002, 20(6): 343-365.
[4]	LESHCHINSKY B, LING H. Effects of geocell conﬁnement on strength and deformation behavior of gravel[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2013, 139(2): 340-352.
[5]	MADHAVI LATHA G, RAJAGOPAL K, KRISHNASWAMY N R. Experimental and theoretical investigations on geocell supported embankments[J]. International Journal of Geomechanics, 2006, 6(1): 30-35.
[6]	刘金龙, 栾茂田, 王吉利, 等. 土工织物加固软土路基的机理分析[J]. 岩土力学, 2007, 28(5): 1009-1014. (LIU Jing-long, LUAN Mao-tian, WANG Ji-li, et al. Mechanism of road embankment reinforced with geotextile[J]. Rock and Soil Mechanics, 2007, 28(5): 1009-1014. (in Chinese))
[7]	杨庆, 季大雪, 栾茂田, 等. 土工格栅加筋路堤边坡结构性能模型试验研究[J]. 岩土力学, 2005, 26(8): 1243-1246. (YANG Qing, JI Da-xue, LUAN Mao-tian, et al. Studies on structural performance of embankment slopes reinforced by geogrids with model tests[J]. Rock and Soil Mechanics, 2005, 26(8): 1243-1246. (in Chinese))
[8]	朱湘, 黄晓明. 加筋路堤的室内模拟试验和现场沉降观测[J]. 岩土工程学报, 2002, 24(3): 386-388. (ZHU Xiang, HUANG Xiao-ming. Laboratory simulating test and field settlement observation of reinforced embankment[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(3): 386-388. (in Chinese))
[9]	张良, 罗强, 陈虎, 等. 基于离心模型试验的软基路堤基底压力和垫层筋带拉力分析[J]. 岩土力学, 2010, 31(9): 2772-2779. (ZHANG Liang, LUO Qiang, CHEN Hu, et al. Analysis of tensile force in reinforced cushion and pressure at bottom of soft soil foundation embankment based on centrifugal model tests[J]. Rock and Soil Mechanics, 2010, 31(9): 2772-2779. (in Chinese))
[10]	孙亮富, 张孟喜, 林永亮, 等. 单向网格状带齿加筋砂垫层加固道路软基的变形特性研究[J]. 土木工程学报, 2011, 44(增刊): 13-17. (SUN Liang-fu, ZHANG Meng-xi, LIN Yong-liang, et al. Study on deformation characteristics of sand cushion reinforced by uniaxial grid reinforcement of denti-inclusions on soft ground[J]. China Civil Engineering Journal, 2011, 44(S0): 13-17. (in Chinese))
[11]	GB50007—2011 建筑地基基础设计规范[S]. 北京: 中国建筑工业出版社, 2011. (GB50007—2011 Code for design of building foundation[S]. Beijing: China Architecture and Building Press, 2011. (in Chinese))
