Evaluation method for multi-story buildings influenced by under-crossing metro tunnel
-
摘要: 地铁隧道下穿建筑物实例越来越多,但下穿建筑物评价方法尚未统一。通过对实测隧道下穿建筑物变形规律分析,提出双线隧道下穿建筑物预测地基基础沉降,可以采用单线隧道已建立的北京Peck修正公式简单叠加。下穿建筑物评价时检测项目可以简化,建议仅以适当的外形测量、裂缝记录和无损探测等即可。下穿建筑物若为条形基础,其任意一段地基基础局部倾斜附加变形均应在控制值之内,已有局部倾斜较大地段为监测重点部位。提出评价地铁隧道下穿单体多层建筑物,可采取3个步骤：①找出其竣工图确认吻合;②进行现状测量和结构体表观检查检测,形成文件得以资料保存;③测定已有地基基础变形值,在总允许值中扣除之,即得隧道下穿建筑物允许附加变形控制标准。Abstract: With the development of urban metro construction, there are more and more under-crossing metro tunnels completed under buildings in Beijing. However, the evaluation method for the upper buildings influenced by under-crossing metro tunnels is not mature. Based on the analysis of the measured settlement of the upper buildings, following conclusions are drawn: (1) The settlement of the upper buildings influenced by double tunnels can be calculated by the superimposed modified Peck equation; (2) Only appearance measurement, crack record and non-destructive detection are necessary for the evaluation of the upper buildings; (3) The additional incline for any local part of strip foundation must be in the control range, and the area with large additional incline value should be highlighted in monitoring; (4) The evaluation of a upper multi-story building can be finished after three steps: a) The completion drawings of the building are used to confirm; b) The appearance measurement, structural detection and original documents are stored for preserving the evidence; c) By reducing the existing deformation of building foundation from the total allowable value, the additional deformation during construction period is given.
-
Keywords:
- metro tunnel /
- under-crossing /
- multi-story building /
- foundation /
- evaluation method
-
[1] 滕延京, 衡朝阳, 姚爱军, 等. 地铁隧道施工对周边建(构)筑物影响与灾害防治关键技术研究[R]. 北京: 2008. (TENG Yan-jing, HENG Chao-yang, YAO Ai-jun, et al. Research on buildings deformation influenced by surrounding construction of the metro tunnel and control technique of engineering disaster[R]. Beijing, 2008. (in Chinese)) [2] PECK R B. Deep excavations and tunneling in soft ground[C]// Proceedings of the 7th International Conference on Soil Mechanics and Foundation Engineering. Mexico, 1969: 225-290. [3] 姚爱军, 赵 强, 管 江, 等. 基于北京地层地铁隧道施工的Peck公式的改进[J]. 地下空间与工程学报, 2010, 6(4): 789-793. (YAO Ai-jun, ZHAO Qiang, GUAN Jiang, et al. Improvement of peck formula in subway construction in Beijing[J]. Chinese Journal of Underground Space and Engineering, 2010, 6(4): 789-793. (in Chinese)) [4] 衡朝阳, 滕延京, 陈希泉. 地铁盾构隧道周边建筑物地基基础变形控制研究[J]. 地下空间与工程学报, 2006, 2(8): 1336-1340. (HENG Chao-yang, TENG Yan-jing, CHEN Xi-quan. Research of allowable deformation value of the building foundation soils above metro shield tunnel[J]. Chinese Journal of Under Ground Space and Engineering, 2006, 2(8): 1336-1340. (in Chinese)) [5] 于 宁, 朱合华. 盾构隧道施工地表变形分析与三维有限元模拟[J]. 岩土力学, 2004, 25(8): 1330-1334. (YU Ning, ZHU He-hua. Analysis of earth deformation caused by shield tunnel construction and 3D-FEM simulation[J]. Rock and Soil Mechanics, 2004, 25(8): 1330-1334. (in Chinese)) [6] 滕延京, 姚爱军, 衡朝阳, 等. 地铁隧道施工对周边环境影响的数值分析方法适宜性评价及其改进方法[J]. 建筑科学, 2011, 27(3): 1-4. (TENG Yan-jing, YAO Ai-jun, HENG Chao-yang, et al. Suitability assessment and improved method for numerical analysis of peripheral environment impact in subway tunnel construction[J]. Building Science, 2011, 27(3): 1-4. (in Chinese)) -
