小应变三轴试验方法及其在上海软土的初步应用

陈超斌; 武朝军; 叶冠林; 王建华

doi:10.11779/CJGE2015S2008

小应变三轴试验方法及其在上海软土的初步应用 English Version

上海交通大学土木工程系,上海 200240

详细信息

作者简介:
陈超斌(1991- ),男,浙江宁波人,硕士研究生,主要从事软黏土力学特性、隧道的研究。

计量
- 文章访问数: 0259
- HTML全文浏览量: 0
- PDF下载量: 0610
出版历程
- 收稿日期: 2015-03-25
- 发布日期: 2015-07-24

Small-strain triaxial test method and its preliminary application in Shanghai soft clay

Department of Civil Engineering, Shanghai Jiao Tong University, Shanghai 200240, China

摘要

摘要: 对软土小应变三轴测试方法进行了整理,对霍尔效应局部位移传感器、LVDT位移传感器、压电陶瓷弯曲元、共振柱仪等小应变刚度测试手段进行了梳理和总结。并利用安装有霍尔效应传感器的三轴仪对上海软土进行了试验,探讨霍尔效应传感器对于测试土体小应变特性的有效性,获得霍尔效应传感器能够得到土体在0.01%~0.1%小应变范围内的弹性模量的结论,并建议今后结合运用LVDT传感器和弯曲元进一步测试土体在应变0.001%~0.01%范围内的特性。
- 小应变 /
- 霍尔效应传感器 /
- LVDT传感器 /
- 弯曲元 /
- 上海软土
Abstract: The methods of small-strain triaxial tests on soft clay are collated and summarized, including those using Hall-effect sensors, LVDT, bender elements and resonant columns. To discuss the effectiveness of the Hall-effect sensors on getting clay property in small strain, the triaxial tests with the Hall-effect sensors are performed on Shanghai soft clay. A conclusion is drawn that the elastic modulus of clay in small strain (0.01%~0.1%) can be measured by using the Hall-effect sensors. Finally, it is advised that the LVDT and bender elements should be applied in measuring clay property in smaller strain (0.001%~ 0.01%).
- small strain /
- Hall-effect sensor /
- LVDT sensor /
- bender element /
- Shanghai soft clay

HTML全文

参考文献(12)

[1]	BURLAND J B. Ninth Laurits Bjerrum Memorial Lecture:" Small is beautiful"-the stiffness of soils at small strains[J]. Canadian Geotechnical Journal, 1989, 26(4): 499-516.
[2]	MAIR R J. Unwin Memorial Lecture 1992 Developments in geotechnical engineering research: application to tunnels and deep excavations[J]. Proceedings of the Institution of Civil Engineers-Civil Engineering, 1993, 97: 27-41.
[3]	BALDI G, HIGHT D W, THOMAS G E. A reevaluation of conventional triaxial test methods[M]// DONAGHE R T, CHANEY R C, SILVER M L, eds. Advanced Triaxial Testing of Soil and Rock, ASTM STP 977. Philadelphia: American Society for Testing and Materials, 1988: 219-263.
[4]	CLAYTON C R I, KHATRUSH S A. A new device for measuring local axial strains on triaxial specimens[J]. Géotechnique, 1986, 36(4): 593-597.
[5]	姬美秀. 压电陶瓷弯曲元剪切波速测试及饱和海洋软土动力特性研究[D]. 杭州: 浙江大学, 2005. (JI Mei-xiu. Study on the shear wave velocity measurement from bender elements and dynamic properties of saturated soft marine clay[D]. Hangzhou: Zhejiang University, 2005. (in Chinese))
[6]	YE G L, WU C J, SHENG J R. Depositional environment and mechanical properties of Shanghai clays[C]// Proceeding of NFCOMGEO VI - New Frontiers in Computational Geotechnics. Takayama, 2012: 21-23.
[7]	盛佳韧, 武朝军, 叶冠林, 等. 上海黏土强度特性真三轴试验研究[J]. 岩土力学, 2013, 34(1): 47-52. (SHENG Jia-ren, WU Chao-jun, YE Guan-lin, et al. Strength property of Shanghai clay in true triaxial tests[J]. Rock and Soil Mechanics, 2013, 34(1): 47-52. (in Chinese))
[8]	WU C J, YE G L, SHENG J R, et al. Depositional history and geotechnical properties of Shanghai clays[C]// Proceedings of the International Symposium on Coastal Engineering Geology. Shanghai, 2012.
[9]	SHENG Jia-ren, WU Chao-jun, YE Guan-lin, et al. Study on strength of shanghai marine clay by true triaxial test[C]// Proceedings of the ASME 2012 31st International Conference on Ocean, offshore and Arctic Engineering (OMAE 2012). Rio de Janeiro, 2012.
[10]	SCHOLEY G K, FROST J D, LOPRESTI D C, et al. A review of instrumentation for measuring small strains during triaxial testing of soil specimens[J]. Geotechnical Testing Journal, 1994, 18(2): 137-156.
[11]	祝龙根, 徐存森. 共振柱仪及其在工程中的应用[J]. 大坝观测与土工测试, 1993, 1: 32-37. (ZHU Long-gen, XU Cun-sheng. The Resonant column device and its application in engineering[J]. Dam Observation and Geotechnical Tests, 1993, 1:32 - 37. (in Chinese))
[12]	PUZRIN A M, BURLAND J B. A logarithmic stress-strain function for rocks and soils[J]. Géotechnique, 1996, 46(1): 157-164.
