Numerical analysis of mixed mode progressive rock fracture mechanism of cracked chevron notched Brazilian disc specimens
-
摘要: 人字形切槽巴西圆盘（CCNBD）岩石试样由于诸多优点,被国际岩石力学学会确定为岩石I型断裂韧度测试建议方法,并被众多学者应用于复合型（包括纯Ⅱ型）断裂试验研究。然而,CCNBD在复合型荷载下的渐进断裂机理尚未完全获悉,复合型断裂韧度测试基于的穿透直裂纹扩展假设并未严格评估,用于复合型断裂研究的合理性还未得到有效验证。采用细观损伤力学软件首次模拟得到CCNBD在复合型荷载下的渐进破坏过程。结果显示：裂纹不仅萌生于人字形韧带尖端,且易产生于切槽边缘,造成真实裂纹前缘为曲线形,与人字形切槽试样断裂韧度测试所基于的穿透直裂纹假设不符;裂纹并非沿着预制人字形韧带平面扩展到其根部,切槽边缘的破裂方向均朝向加载端,形成扭曲的三维翼形裂纹。数值模拟结果同物理实验对比,十分吻合。CCNBD的裂纹形态和渐进扩展规律不符合当前普遍采用的复合型测试原理,因此采用CCNBD试样进行岩石复合型（包括纯Ⅱ型）断裂韧度测试值得商榷。Abstract: The cracked chevron notched Brazilian disc (CCNBD) method, due to its distinct advantages, has been suggested by ISRM for mode I fracture toughness determination, and later applied extensively to mixed mode fracture researches (pure mode II included). When the CCNBD is applied to mixed mode fracture researches, however, the progressive fracture mechanism and relevant hypotheses have not been thoroughly assessed, and the rationality of mixed mode fracture tests using CCNBD is under suspect. In this paper, the progressive rock fracture mechanism of CCNBD rock samples under mixed mode conditions is first simulated using the meso-scale damage mechanics analysis code. The results show that the fracture initiates not only from the notch tip but also from the saw-cut chevron notch edges, as a result, the crack front is significantly curved, inconsistent with the straight through crack assumption. Furthermore, cracks fail to grow stably to the base of the notch, but depart from the pre-cracked notch plane and develop towards the loading direction, forming a couple of twisty 3D-wing cracks. The results from simulation correspond very well with those from our experiments. Both the fracture pattern and the growing trend of CCNBD under mixed mode conditions are inconsistent with the present hypotheses, which suggests that the application of the CCNBD specimens to the mixed mode (including pure mode Ⅱ) fracture tests is questionable.
-
Keywords:
- progressive fracture /
- CCNBD /
- mixed mode /
- wing crack /
- acoustic emission
-
[1] 陈洪凯, 唐红梅, 王林峰, 等. 缓倾角岩质陡坡后退演化的力学机制[J]. 岩土工程学报, 2010, 32(3): 468-473. (CHEN Hong-kai, TANG Hong-mei, WANG Lin-feng, et al. Mechanical mechanism for retreat evolution of steep rock slopes with gentle dip[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(3): 468-473. (in Chinese)) [2] 赵延林, 王卫军, 万 文, 等. 裂隙岩体渗流-断裂耦合机制及应用[J]. 岩土工程学报, 2012, 34(4): 677-684. (ZHAO Yan-lin, WANG Wei-jun, WAN Wen, et al. Coupling mechanism of seepage-fracture in fractured rock mass and its application[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(4): 677-684. (in Chinese)) [3] ISRM Testing Commission. Suggested methods for determining the fracture toughness of rock[J]. International Journal of Rock Mechanics and Mining Sciences Geomechanics Abstract, 1988, 25: 7-96. [4] ISRM Testing Commission. Suggested method for determining mode Ⅰ fracture toughness using cracked chevron notched Brazilian disc (CCNBD) specimens[J]. International Journal of Rock Mechanics and Mining Sciences Geomechanics Abstract, 1995, 32: 57-64. [5] KURUPPU M D, OBARA Y, AYATOLLAHI M R, et al. ISRM-suggested method for determining the mode Ⅰ static fracture toughness using semi-circular bend specimen[J]. Rock Mechanics and Rock Engineering, 2014, 47: 267-274. [6] DWIVEDI R D, SONI A K, GOEL R K, et al. Fracture toughness of rocks under sub-zero temperature conditions[J]. International Journal of Rock Mechanics and Mining Sciences, 2000, 37: 1267-1275. [7] 崔振东, 刘大安, 安光明, 等. V形切槽巴西圆盘法测定岩石断裂韧度 K IC 的实验研究[J]. 岩土力学, 2010, 31(9): 2743-2748. (CUI Zhen-dong, LIU Da-an, AN Guang-ming, et al. Research for determining mode I rock fracture toughness K IC using cracked chevron notched Brazilian disc specimen[J]. Rock and Soil Mechanics, 2010, 31(9): 2743-2748. (in Chinese)) [8] DAI F, CHEN R, IQBAL M J, et al. Dynamic cracked chevron notched Brazilian disc method for measuring rock fracture parameters[J]. International Journal of Rock Mechanics & Mining Sciences, 2010,47: 606-613. [9] ERARSLAN N, WILLIAMS D J. Mixed-mode fracturing of rocks under static and cyclic loading[J]. Rock Mechanics and Rock Engineering, 2013,46: 1035-1052. [10] CHANG S H, LEE C I, SEOKWON J. Measurement of rock fracture toughness under modes Ⅰ and Ⅱ and mixed-mode conditions by using disc-type specimens[J]. Engineering Geology, 2002,66: 79-97. [11] ALIHA M R M, AYATOLLAHI M R. Rock fracture toughness study using cracked chevron notched Brazilian disc specimen under pure modes Ⅰ and Ⅱ loading - A statistical approach[J]. Theoretical and Applied Fracture Mechanics, 2014, 69: 17-25. [12] AMROLLAHI H, BAGHBANAN A, HASHEMOLHOSSEINI H. Measuring fracture toughness of crystalline marbles under modes Ⅰ and Ⅱ and mixed mode Ⅰ - Ⅱ loading conditions using CCNBD and HCCD specimens[J]. International Journal of Rock Mechanics and Mining Sciences, 2011, 48: 1123-1134. [13] OUCHTERLONY F. Compliance calibration of a round fracture toughness bend specimen with chevron edge notch[R]. Stockholm: Swedish Detonic Research Foundation, 1984. [14] DAI F, WEI M D, XU N W, et al. Numerical assessment of the progressive rock fracture mechanism of cracked chevron notched Brazilian disc specimens[J]. Rock Mechanics and Rock Engineering, 2014, doi:10.1007/s00603-014- 0587-8. [15] IQBAL M J, MOHANTY B. Experimental calibration of stress intensity factors of the ISRM suggested cracked chevron-notched Brazilian disc specimen used for determination of mode-I fracture toughness[J]. International Journal of Rock Mechanics and Mining Sciences, 2006, 40: 1270-1276. [16] SHETTY D K, ROSENFILED A R, DUCKWORTH W H. Fracture toughness of ceramics measured by a chevron notch diametrical compression test[J]. Journal of American Ceramic Society, 1985, 68 (12): 325-327. [17] 梁正召, 杨天鸿, 唐春安, 等. 非均匀性岩石破坏过程的三维损伤软化模型与数值模拟[J]. 岩土工程学报, 2005, 27(12): 1447-1452. (LIANG Zheng-zhao, YANG Tian-hong, TANG Chun-an, et al. Three-dimensional damage soften model for failure process of heterogeneous rocks and associated numerical simulation[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(12): 1447-1452. (in Chinese)) [18] 黄志平, 唐春安, 朱万成, 等. 动载荷条件下波长对岩石试件破坏模式影响的数值模拟[J]. 岩土工程学报, 2007, 29(7): 1048-1053. (HUANG Zhi-ping, TANG Chun-an, ZHU Wan-cheng, et al. Numerical simulation on failure modes of rock bars under different wave lengths[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(7): 1048-1053. (in Chinese)) [19] LIANG Z Z, XING H, WANG S Y, et al. A three-dimensional numerical investigation of the fracture of rock specimens containing a pre-existing surface flaw[J]. Computers and Geotechnics, 2012, 45: 19-33. [20] ZHU W C, LI Z H, ZHU L, et al. Numerical simulation on rock burst of underground opening triggered by dynamic disturbance[J]. Tunnelling and Underground Space Technology, 2010, 25(5): 587-599. [21] XU N W, TANG C A, LI L C, et al. Micro seismic monitoring and stability analysis of the left bank slope in Jinping first stage hydropower station in southwestern China[J]. International Journal of Rock Mechanics and Mining Sciences, 2011, 48(6): 950-963. [22] 赵延林, 万 文, 王卫军, 等. 类岩石材料有序多裂纹体单轴压缩破断试验与翼形断裂数值模拟[J]. 岩土工程学报, 2013, 35(11): 2097-2109. (ZHAO Yan-lin, WAN Wen, WANG Wei-jun, et al. Fracture experiments on ordered multi-crack body in rock-like materials under uniaxial compression and numerical simulation of wing cracks[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(11): 2097-2109. (in Chinese)) [23] ALIHA M R M, AYATOLLAHI M R, AKBARDOOST J. Typical upper bound-lower bound mixed mode fracture resistance envelopes for rock material[J]. Rock Mechanics and Rock Engineering, 2012, 45(1): 65-74. [24] ATKINSON C, SMELSER R E, SANCHEZ J. Combined mode fracture via the cracked Brazilian disk test[J]. International Journal of Fracture, 1982, 18(4): 279-291. -
