含充填物的厚壁圆筒砂岩的力学性质研究

李夕兵, 吴秋红, 董陇军, 陈璐, 谢晓锋, 张楚旋

李夕兵, 吴秋红, 董陇军, 陈璐, 谢晓锋, 张楚旋. 含充填物的厚壁圆筒砂岩的力学性质研究[J]. 岩土工程学报, 2015, 37(12): 2149-2156. DOI: 10.11779/CJGE201512003
引用本文: 李夕兵, 吴秋红, 董陇军, 陈璐, 谢晓锋, 张楚旋. 含充填物的厚壁圆筒砂岩的力学性质研究[J]. 岩土工程学报, 2015, 37(12): 2149-2156. DOI: 10.11779/CJGE201512003
shu
LI Xi-bing, WU Qiu-hong, DONG Long-jun, CHEN Lu, XIE Xiao-feng, ZHANG Chu-xuan. Mechanical property of thick-walled hollow cylinders of sandstone with filling[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(12): 2149-2156. DOI: 10.11779/CJGE201512003
Citation: LI Xi-bing, WU Qiu-hong, DONG Long-jun, CHEN Lu, XIE Xiao-feng, ZHANG Chu-xuan. Mechanical property of thick-walled hollow cylinders of sandstone with filling[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(12): 2149-2156. DOI: 10.11779/CJGE201512003
shu

含充填物的厚壁圆筒砂岩的力学性质研究  English Version

  • 中南大学资源与安全工程学院,湖南 长沙 410083

基金项目: 国家自然科学基金项目（41272304,11472311）; 湖南省研究生科研创新基金项目（71380100005）
详细信息
    作者简介:

    李夕兵(1962- ),男,博士,教授,博士生导师,主要从事采矿与岩土工程方面的教学与研究工作。E-mail: xbli@mail.csu.edu.cn。

Mechanical property of thick-walled hollow cylinders of sandstone with filling

  • School of Resource and Safety Engineering, Central South University, Changsha 410083, China

摘要

    摘要
  • 摘要: 基于单轴和常规三轴压缩试验,采用完整试样、空心及铝棒充填的厚壁圆筒试样,模拟研究支护对圆形巷道的强度、变形和破坏特征的影响。结果表明：充填试样和完整试样的单轴压缩强度和弹性模量大致相同,而厚壁圆筒试样的强度和弹性模量则偏低31.8%和22.4%;厚壁圆筒试样三轴压缩时出现沿圆周层状破坏,其剪切面积随着围压的增大而减少,围压40 MPa时出现明显塌孔;充填试样进入塑性屈服阶段后,充填物才会对试样的力学性质产生明显影响;充填物改变了孔道内部应力状态,使孔道内壁由原来的二维应力状态恢复到三维应力状态,抑制了孔道内壁的侧向变形,防止自由面岩石的脱落;岩石破坏并不代表承载能力消失,充填试样岩石破坏后失去黏结力,载荷主要通过充填物与岩石、岩石裂隙之间摩擦力共同承载。
    Abstract: Based on uniaxial and pseudo-triaxial compression tests, the effect of support on the strength, deformation and failure characteristics of circular roadway is simulated by using solid specimens, thick-walled hollow cylinder specimens and thick wall cylinder specimens with aluminum rod. The tests indicate that: (1) The uniaxial compressive strength and elastic modulus of solid specimens and filled specimens are roughly the same, and those of the cylinder specimens are decreased by 31.8% and 22.4%; (2) When the thick-wall cylinder specimens have layered destruction along the circumference under triaxial compression, the shear area decreases with the increase of confining pressure, and collapse hole appears when the confining pressure is 40 MPa; (3) Filling have significant influence on mechanical properties of specimens when the filled specimens enter the plastic deformation, and it can change the rock stress state and make the two-dimensional stress state of inner wall back to the three-dimensional stress state; (4) Filling can cause inhibition of larger lateral displacement of inner wall and prevent the rock of free surface fall off; (5) Rock failure doesn't mean that the bearing capacity disappears, rock of filled specimens loses cohesive force, and the bearing capacity of filled specimens mainly depends on friction forces of filling and rock and rock fractures.
    • HTML全文
    • 参考文献(30)
  • [1] WANG C. The optimal support intensity for coal mine roadway tunnels in soft rocks[J]. International Journal of Rock Mechanics and Mining Sciences, 2000, 37(7): 1155-1160.
    [2] ADAMS F D. An experimental contribution to the question of the depth of the zone of flow in the earth’s crust[J]. The Journal of Geology, 1912, 20(2): 97-118.
    [3] KING L V. On the limiting strength of rocks under conditions of stress existing in the earth’s interior[J]. The Journal of Geology, 1912, 20(2): 119-138.
    [4] TALESNICK M L, RINGEL M. Completing the hollow cylinder methodology for testing of transversely isotropic rocks: torsion testing[J]. International Journal of Rock Mechanics and Mining Sciences, 1999, 36(5): 627-639.
    [5] ENEVER J, WU B. Scale effects in hollow cylinder tests[C]// Frontiers of Rock Mechanics and Sustainable Development in the 21st Century (2001 ISRM and 2nd ARMS). Netherlands: Balkema, 2001: 209-212.
    [6] ELKADI A S, VANMIER J G M. Experimental investigation of size effect in concrete fracture under multiaxial compression[J]. International Journal of Fracture, 2006, 140(1/2/3/4): 55-71.
    [7] ELKADI A S, VANMIER J G M, SLUYS L J. Multiaxial failure of low-cohesive frictional materials: Fracture behaviour and size dependency[J]. Philosophical Magazine, 2006, 86(21/22): 3137-3159.
    [8] 尤明庆, 苏承东, 缑 勇. 大理岩孔道试样的强度及变形特性的试验研究[J]. 岩石力学与工程学报, 2007, 26(12): 2420-2429. (YOU Ming-qing, SU Cheng-dong, GOU Yong. Experimental study on strength and deformation properties of hollow cylindrical specimens of marbles[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(12): 2420-2429. (in Chinese))
    [9] 缑 勇, 苏承东, 秦莞臻. 含孔道大理岩圆柱试样的尺寸效应[J]. 采矿与安全工程学报, 2007, 24(3): 302-305. (GOU Yong, SU Cheng-dong, QIN Guan-zhen. Scale effects of marble hollow cylinder specimen[J]. Journal of Mining and Safety Engineering, 2007, 24(3): 302-305. (in Chinese))
    [10] SANTARELLI F J, BROWN E T. Failure of three sedimentary rocks in triaxial and hollow cylinder compression tests[J]. International Journal of Rock Mechanics and Mining Sciences &Geomechanics Abstracts, 1989, 26(5): 401-413.
    [11] LABIOUSE V, VIETOR T. Laboratory and in situ simulation tests of the excavation damaged zone around galleries in Opalinus clay[J]. Rock Mechanics and Rock Engineering, 2014, 47(1): 57-70.
    [12] FRANCOIS B, LABIOUSE V, DIZIER A, et al. Hollow cylinder tests on boom clay: modelling of strain localization in the anisotropic excavation damaged zone[J]. Rock Mechanics and Rock Engineering, 2014, 47(1): 71-86.
    [13] LABIOUSE V, SAUTHIER C, YOU S. Hollow cylinder simulation experiments of galleries in boom clay formation[J]. Rock Mechanics and Rock Engineering, 2014, 47(1): 43-55.
    [14] EWY R T, COOK N G W. Deformation and fracture around cylindrical openings in rock I. Observations and analysis of deformations[J]. International Journal of Rock Mechanics and Mining Sciences & Geomechanics Abstracts, 1990, 27(5): 387-407.
    [15] EWY R T, COOK N G W. Deformation and fracture around cylindrical openings in rock II. Initiation,growth and interaction of fractures[J]. International Journal of Rock Mechanics and Mining Sciences & Geomechanics Abstracts, 1990, 27(5): 409-427.
    [16] HOSKINS E R. The failure of thick-walled hollow cylinders of isotropic rock [J]. International Journal of Rock Mechanics and Mining Science & Geomechanics Abstracts, 1969, 6(1): 99-125.
    [17] ADDIS M A, WU B. The Role of the intermediate principal stress in wellbore stability studies: evidence from hollow cylinder tests[J]. International Journal of Rock Mechanics and Mining Sciences & Geomechanics Abstracts, 1993, 30(7): 1027-1030.
    [18] LEE D H, JUANG C H, LIN H M, et al. Mechanical behavior of Tien-liao mudstone in hollow cylinder tests[J]. Canadian Geotechnical Journal, 2002, 39(3): 744-756.
    [19] LEE D H, JUANG C H, LIN H M. Yield surface of Mu-san sandstone by hollow cylinder tests[J]. Rock Mechanics and Rock Engineering, 2002, 35(3): 205-216.
    [20] 张后全, 刘红岗, 贺永年, 等. 岩石厚壁圆筒三向压缩下的卸荷试验与岩石强度破坏[J]. 北京科技大学学报, 2011, 33(7): 800-805. (ZHANG Hou-quan, LIU Hong-gang, HE Yong-nian, et al. Unloading experiment and rock strength failure of rock thick-walled cylinders under triaxial compression[J]. Journal of University of Science and Technology Beijing, 2011, 33(7): 800-805. (in Chinese))
    [21] BROWN E T, HUDSON J A, HARDY M P, et al. Controlled failure of hollow rock cylinders in uniaxial compression[J]. Rock Mechanics, 1972, 4(1): 1-24.
    [22] 郭保华. 岩样尺度、孔道及端部摩擦效应的数值分析[J].岩石力学与工程学报, 2009, 28(增刊2): 59-64. (GUO Bao-hua. Numerical analysis of size scale, inner hole and end restraint effects of rock samples[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(S2): 59-64. (in Chinese))
    [23] MEIER T, RYBACKI E, REINICKE A, et al. Influence of borehole diameter on the formation of borehole breakouts in black shale[J]. International Journal of Rock Mechanics and Mining Sciences, 2013, 62: 74-85.
    [24] CHEN X, TAN C P, HABERFIELD C M. Numerical evaluation of the deformation behavior of thick-walled hollow cylinders of shale[J]. International Journal of Rock Mechanics and Mining Sciences, 2000, 37(6): 947-961.
    [25] 尤明庆, 苏承东. 砂岩孔道试样压拉应力下强度和破坏的研究[J]. 岩石力学与工程学报, 2010, 29(6): 1096-1105. (YOU Ming-qing, SU Cheng-dong. Study on strength and failure of hollow cylinders and rings of sandstone under compression-tension stresses[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(6): 1096-1105. (in Chinese))
    [26] 尤明庆, 邹友峰. 关于岩石非均质性与强度尺寸效应的讨论[J]. 岩石力学与工程学报, 2000, 19(3): 391-395. (YOU Ming-qing, ZOU You-feng. Discussion on heterogeneity of rock material and size effect on specimen strength[J]. Chinese Journal of Rock Mechanics and Engineering, 2000, 19(3): 391-395. (in Chinese))
    [27] 董陇军, 李夕兵. 地下硐室节理岩体区间非概率可靠性分析方法及应用[J]. 岩土工程学报, 2011, 33(7): 1007-1013. (DONG Long-jun, LI Xi-bing. Interval non-probabilistic reliability method for surrounding jointed rockmass stability of underground caverns[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(7): 1007-1013. (in Chinese))
    [28] 董陇军, 李夕兵. 岩石试验抗压、抗拉区间强度及代表值可信度研究[J]. 岩土工程学报, 2010, 32(12): 1969-1974. (DONG Long-jun, LI Xi-bing. Study of interval parameters and credibility of representative value of rock tensile and compression strength tests[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(12): 1969-1974. (in Chinese))
    [29] LI X B, LOK T S, ZHAO J, et al. Oscillation elimination in the Hopkinson bar apparatus and resultant complete dynamic stress- strain curves for rocks[J]. International Journal of Rock Mechanics and Mining Sciences, 2000, 37(7): 1055-1060.
    [30] LI X B, ZHOU Z L, LOK T S, et al. Innovative testing technique of rock subjected to coupled static and dynamic loads[J]. International Journal of Rock Mechanics and Mining Sciences, 2008, 45(5): 739-748.
