Stick-up stability of large-diameter steel pipe pile considering combined wave-current loads
-
摘要: 随着海洋工程建设水深的不断增加,导管架平台的钢管桩基础呈现出大直径、深贯入的特点。桩基承载力的提高导致了打桩施工难度的增长,不仅要求具有更大锤击能量的打桩设备,而且对打桩全过程的安全控制提出了更高的要求。桩的自由站立稳定性是打桩分析的第一个重要环节。针对置锤荷载的瞬态性特征,以钢管桩自由站立稳定性的静力分析方法为基础,提出了采用动力算法考虑作用于钢管桩上的波浪力和海流力,建立了钢管桩自由站立稳定性分析的动力模拟方法。研究表明,由于API规范法考虑的是荷载长期作用效果,与钢管桩置锤瞬间的瞬态过程不符,用该方法验算桩的自由站立稳定性偏于保守;动力法分析与API规范的计算结果对比表明,规范中的强度折减系数用于验算桩基自由站立稳定性时可以放大1.5倍。Abstract: With the increase of water depth in marine construction projects, characteristics of large diameter and deep penetration appear in the steel pipe piles used for jacket platform. Because the bearing capacity of piles is improved, constructions of piles become more difficult. It results in the need of hammers with larger blow energy and higher demand for safety in pile driving. The stick-up stability of piles is the first important part in the analysis of pile driving. Considering the transient characteristics of hammer load, a dynamic method is adopted to calculate the wave and current loads, and a dynamic simulation method is proposed to analyze the stick-up stability of pipe piles. The results show that the calculation of stick-up using the API code, which is different from the transient process and considers the long-term effect of load, is conservative. The API code can be used to check the stick-up stability of piles, and the strength reduction factor can be magnified 1.5 times.
-
[1] BRANDTZAEG A, HARBOE E. Buckling tests of slender steel piles in soft, quick clay[C]// Proc of the 4th Intern Conference on Soil Mechanics and Foundation Engineering. London, 1957: 19-23. [2] American Petroleum Institute. Recommended practice for planning, designing and constructing fixed offshore platforms[M]. Washington D C: API Recommended Practice 2A-WSD (RP2A-WSD), 2000. [3] 陈 波, 闫澍旺, 樊之夏. 桩基平台桩的可打入性和自由站立强度分析[J]. 中国海上油气（工程）, 2001, 13(6): 1-5. (CHEN Bo, YAN Shu-wang, FAN Zhi-xia. Driveability and freestanding analysis of steel pile of offshore platform[J]. China Offshore Oil and Gas(Engineering), 2001, 13(6): 1-5. (in Chinese)) [4] 刘 润, 禚瑞花, 闫澍旺, 等. 超长桩施工中桩身稳定性的三维非线性有限元分析[J]. 天津大学学报, 2006, 39(3): 257-263. (LIU Run, ZHUO Rui-hua, YAN Shu-wang, et al. Nonlinear 3D finite element method analysis for stability of pile stick-up during driving[J]. Journal of Tianjin University, 2006, 39(3): 257-263. (in Chinese)) [5] 刘 润, 闫澍旺, 毛永华, 等. 海洋工程中桩身自由站立稳定性影响因素分析[J]. 海洋工程, 2006, 24(3): 6-13. (LIU Run, YAN Shu-wang, MAO Yong-hua, et al. Study on influence factors for pile stick-up stability in ocean engineering[J]. The Ocean Engineering, 2006, 24(3): 6-13. (in Chinese)) [6] 高喜峰, 刘 润, 谭振东, 等. 基于桩土相互作用的桩体自沉及屈曲稳定性研究[J]. 中国造船, 2012, 53(2): 113-121. (GAO Xi-feng, LIU Run, TAN Zhen-dong, et al. Study on pile self-penetration and buckling stability considering interaction between pile and subsoil[J]. Shipbuilding of China, 2012, 53(2): 113-121. (in Chinese)) [7] JTS 145—2—2013 海港水文规范[S]. 2013. (JTS 145—2—2013 Code of hydrology for sea harbour[S]. 2013. (in Chinese)) [8] JTS 144—1—2010 港口工程荷载规范[S]. 2010. (JTS 144—1—2010 Load code for harbour engineering[S]. 2013. (in Chinese)) [9] 郭玉树, 阿布达, 雷赫曼. 用循环三轴试验分析海上风力发电机单桩基础侧向位移[J]. 岩土工程学报, 2009, 31(11): 1729-1734. (GUO Yu-shu, ACHMUS M, ABDEL- RAHMAN K. Estimation of lateral deformation of monopile foundations by use of cyclic triaxial tests[J]. Chinese Journal of Geotechnical Engineering, 2009, 31(11): 1729-1734. (in Chinese)) [10] MORISON J R, JOHNSON J W. The forces exerted by surface wave on piles[J]. Journal of Petroleum Technology, 1950, 2(5): 149-154. [11] American Petroleum Institute. Recommended practice for planning, designing and constructing fixed offshore platforms[M]. API Recommended Practice 2A-LRFD (RP2A-LRFD), 1993. -
