动载作用下圆形巷道锚杆支护结构破坏机理研究

王正义, 窦林名, 王桂峰

王正义, 窦林名, 王桂峰. 动载作用下圆形巷道锚杆支护结构破坏机理研究[J]. 岩土工程学报, 2015, 37(10): 1901-1909. DOI: 10.11779/CJGE201510019
引用本文: 王正义, 窦林名, 王桂峰. 动载作用下圆形巷道锚杆支护结构破坏机理研究[J]. 岩土工程学报, 2015, 37(10): 1901-1909. DOI: 10.11779/CJGE201510019
shu
WANG Zheng-yi, DOU Lin-ming, WANG Gui-feng. Failure mechanism of anchored bolt supporting structure of circular roadway under dynamic load[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(10): 1901-1909. DOI: 10.11779/CJGE201510019
Citation: WANG Zheng-yi, DOU Lin-ming, WANG Gui-feng. Failure mechanism of anchored bolt supporting structure of circular roadway under dynamic load[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(10): 1901-1909. DOI: 10.11779/CJGE201510019
shu

动载作用下圆形巷道锚杆支护结构破坏机理研究  English Version

  • 1. 中国矿业大学煤炭资源与安全开采国家重点实验室，江苏 徐州 221116;
    2. 中国矿业大学矿业工程学院，江苏 徐州 221116

基金项目: 国家自然科学基金委和神华集团有限公司联合资助项目; （51174285）; 江苏省自然科学基金项目（BK20140194）
详细信息
    作者简介:

    王正义(1990- )，男，硕士研究生，主要从事矿山压力、冲击矿压、采矿地球物理等方面的研究工作。E-mail: 15062193699@163.com。

  • 中图分类号: A

Failure mechanism of anchored bolt supporting structure of circular roadway under dynamic load

  • 1. State Key Laboratory of Coal Resource and Mine Safety, China University of Mining and Technology, Xuzhou 221116, China;
    2. School of Mines, China University of Mining and Technology, Xuzhou 221116, China

摘要

    摘要
  • 摘要: 将冲击应力波进行合理简化，建立平面P波与圆形锚固巷道相互作用简化模型。结合算例，通过分析深部围岩径向应力、巷道表面切向应力、巷道表面径向位移以及深部围岩与巷道表面径向位移差等代表性指标，确定了重点支护位置，推导了重点支护位置的锚杆受力机制并提出了相应破坏类型及判据。结果表明：迎波侧与侧向位置是重点支护位置。迎波侧锚杆总应力是静载轴应力、锚杆振动的动应力和动载下围岩变形引起的附加应力的叠加，强冲击下迎波侧支护结构的破坏类型为单次瞬间摧垮破坏，围岩受压破裂，锚杆松动失去加固作用;循环弱冲击下的破坏类型为循环累积损伤破坏，受压围岩逐渐损伤致裂，锚杆反复受压、受拉直至松动，这进一步加剧围岩的损伤破裂，当承载拱强度降低到一定值后，一次小冲击就能诱发巷道冲击破坏。侧向位置锚杆总应力是静载轴应力、动载下围岩变形引起的附加应力的叠加，锚杆始终受拉，在强冲击下可能发生拉断破坏。通过相似模拟试验，较好地验证了理论分析结果，表明理论分析结果对工程实践具有一定的指导意义。
    Abstract: By reasonably simplifying the stress wave, a simplified model for the reciprocity between the plane p-wave and the circular anchoring roadway is built. Based on a typical case, through analyzing such remarkable parameters as radial stress of deep surrounding rock, tangential stress of roadway surface, radial displacement of roadway surface and radial displacement difference between deep surrounding rock and roadway surface, the strategic locations of support are confirmed, the force mechanism of bolt is deduced, and the corresponding failure patterns and failure criteria are put forward. The results show that the side facing the stress wave and the lateral position are the strategic locations of support. It is found that: (1) The total stress of bolt on the side facing the stress wave is the superposition of static axial stress, dynamic stress of bolt vibration and subsidiary stress caused by the surrounding rock deformation under dynamic load. Under the strong impact, a single instantly destroyed destruction will occur, the surrounding rock is pressed to fracture and the loose bolts lose the reinforcement. Under the cyclic weak impact, the pressed surrounding rock is gradually damaged to fracture, and that the bolt is loose owing to being pressed and straightened repeatedly intensifies the fracture of the surrounding rock further. When the strength of the load-bearing arch is decreased to a certain value, a weak impact can induce the burst failure of roadway; and (2) The total stress of the bolt at the lateral position is the composition of the static axial stress and the subsidiary stress caused by the surrounding rock deformation under the dynamic load. The bolt here is being subjected to tension, so tensile failure will occur under the strong impact. The results of similar simulation experiments are consistent with the theoretical ones, indicating that the theoretical analysis can be a significant guidance for engineering practice.
    • HTML全文
    • 参考文献(20)
  • [1] 窦林名, 何学秋. 冲击矿压防治理论与技术[M]. 徐州: 中国矿业大学出版社, 2001. (DOU Lin-ming, HE Xue-qiu. Rockburst prevention theory and technology[M]. Xuzhou: China University of Mining and Technology Press, 2001. (in Chinese))
    [2] 贺 虎, 窦林名, 巩思园, 等. 巷道防冲机理及支护控制研究[J]. 采矿与安全工程学报, 2010, 27(1): 40-44. (HE Hu, DOU Lin-ming, GONG Si-yuan, et al. Mechanism of rockburst prevention and supporting control technology in roadways[J]. Journal of Mining & Safety Engineering, 2010, 27(1): 40-44. (in Chinese))
    [3] 高明仕, 窦林名, 张 农, 等. 冲击矿压巷道围岩控制的强弱强力学模型及其应用分析[J]. 岩土力学, 2008, 29(2): 359-364. (GAO Ming-shi, DOU Lin-ming, ZHANG Nong, et a1. Strong-soft-strong mechanical model for controlling roadway surrounding rock subjected to rock burst and its application[J]. Rock and Soil Mechanics, 2008, 29(2): 359-364. (in Chinese))
    [4] 王光勇, 张素华, 谢文强, 等. 锚杆动载响应和轴向应力分布规律数值分析[J]. 采矿与安全工程学报, 2009, 26(1): 114-117. (WANG Guang-yong, ZHANG Su-hua, XIE Wen-qiang, et a1. Numerical analysis of dynamic response and axial stress distribution of rock bolts under explosive loads[J]. Journal of Mining & Safety Engineering, 2009, 26(1): 114-117. (in Chinese))
    [5] 杨自友, 顾金才, 杨本水, 等. 锚杆对围岩的加固效果和动载响应的数值分析[J]. 岩土力学, 2009, 30(9): 2805-2809. (YANG Zi-you, GU Jin-cai, YANG Ben-shui, et a1. Numerical analysis of reinforcement effects and response to dynamic loads characteristics of rock bolts[J]. Rock and Soil Mechanics, 2009, 30(9): 2805-2809. (in Chinese))
    [6] 朱传云, 许桂生. 爆炸应力波近似处理的分析与研究[J]. 岩土力学, 2002, 23(4): 455-458. (ZHU Chuan-yun, XU Gui-sheng. Analysis and study on dealing with blasting wave as planar-wave[J]. Rock and Soil Mechanics, 2002, 23(4): 455-458. (in Chinese))
    [7] 鞠文君. 冲击矿压巷道锚杆支护原理分析[J]. 煤矿开采, 2009, 14(3): 59-61. (JU Wen-jun. Analysis of supporting principles of anchored-bolt in roadway with burst danger[J]. Coalmining Technology, 2009, 14(3): 59-61. (in Chinese))
    [8] 李兴华, 龙 源, 纪 冲, 等. 爆破地震波作用下既有圆形隧道衬砌动应力集中系数分析[J]. 岩土力学, 2013, 34(8): 2218-2224. (LI Xing-hua, LONG Yuan, JI Chong, et a1. Analysis of dynamic stress concentration factor for existing circular tunnel lining under blasting seismic wave[J]. Rock and Soil Mechanics, 2013, 34(8): 2218-2224. (in Chinese))
    [9] 钟启凯. 地下圆形组合衬砌洞室在地震波下的动力反应分析[D]. 长沙: 湖南大学, 2009. (ZHONG Qi-kai. Dynamic response analysis of underground cylindrical composite- lining cavern subjected to seismic waves[D]. Changsha: Hunan University, 2009. (in Chinese))
    [10] PAO Y H, MOW C C. The diffraction of elastic waves and dynamic stress concentrations[M]. New York: Crane & Russak, 1973.
    [11] 何 江. 煤矿采动动载对煤岩体的作用及诱冲机理研究[D]. 徐州: 中国矿业大学, 2013. (HE Jiang. Research of mining dynamic loading effect and its induced rock burst in coal mine[D]. Xuzhou: China University of Mining and Technology, 2013. (in Chinese))
    [12] 王光勇. 提高锚固洞室抗爆能力技术措施研究[D]. 合肥: 中国科学技术大学, 2009. (WANG Guang-yong. Technic study on enhancing the explosion resisting capacity of underground opening reinforced by rockbolts[D]. Hefei: University of Science and Technology of China, 2009. (in Chinese))
    [13] 陆士良, 付国彬, 汤 雷. 采动巷道岩体变形与锚杆锚固力变化规律[J]. 中国矿业大学学报, 1999, 28(3): 201-203. (LU Shi-liang, FU Guo-bin, TANG Lei. Regularity of deformation of rocks around roadway under mining influence and change of rockbolt resistance[J]. Journal of China University of Mining & Technology, 1999, 28(3): 201-203. (in Chinese))
    [14] 李志兵, 张 农, 韩昌良, 等. 锚固预紧力与预紧力矩相互关系的研究[J]. 中国矿业大学学报, 2012, 41(2): 189-193. (LI Zhi-bing, ZHANG Nong, HAN Chang-liang, et a1. Relationship between pre-tightening force and tightening torque[J]. Journal of China University of Mining & Technology, 2012, 41(2): 189-193. (in Chinese))
    [15] 李青锋, 茅献彪, 徐金海, 等. 预应力锚杆弹性波检测原理与应用[J]. 采矿与安全工程学报, 2007, 24(1): 32-36. (LI Qing-feng, MAO Xian-biao, XU Jin-hai, et a1. Principles and application of elastic wave method for prestressed bolt testing[J]. Journal of Mining & Safety Engineering, 2007, 24(1): 32-36. (in Chinese))
    [16] IVANOVIC A, STARKEY A, NEILSON R D, et a1. The influence of load on the frequency response of rock bolt anchorage[J]. Advances in Engineering Software, 2003, 12(6): 697-705.
    [17] 刘海峰, 王 珍, 倪 晓, 等. 锚杆在锚固状态下纵向振动规律研究[J]. 矿山压力与顶板管理, 2004, 3(4): 78-80. (LIU Hai-feng, WANG Zhen, NI Xiao, et a1. The study on longitudinal vibration regulation of bolt in anchorage quality[J]. Ground Pressure and Strata Control, 2004, 3(4): 78-80. (in Chinese))
    [18] 杨桂通, 张善元. 弹性动力学[M]. 北京: 中国铁道出版社, 1988. (YANG Gui-tong, ZHANG Shan-yuan. Elastic dynamics[M]. Beijing: China Railway Publishing House, 1988. (in Chinese))
    [19] 陆士良, 汤 雷, 杨新安. 锚杆锚固力与锚固技术[M]. 北京: 煤炭工业出版社, 1998. (LU Shi-liang, TANG Lei, YANG Xin-an. Anchor bolt anchoring force and technology[M]. Beijing: Coal Industry Publishing House, 1998. (in Chinese))
    [20] 高明仕, 窦林名, 严如令, 等. 冲击煤层巷道锚网支护防冲机理及抗冲震级初算[J]. 采矿与安全工程学报, 2009, 26(4): 402-406. (GAO Ming-shi, DOU Lin-ming, YAN Ru-ling1, et a1. Prevention mechanism of roadway supported by bolt-mesh subjected to rock burst and degree calculation[J]. Journal of Mining & Safety Engineering, 2009, 26(4): 402-406. (in Chinese))
