列车运行引起高架桥群桩基础地面振动分析

高广运; 李绍毅; 顾晓强

doi:10.11779/CJGE201510002

列车运行引起高架桥群桩基础地面振动分析 English Version

1. 同济大学地下建筑与工程系，上海 200092;
2. 同济大学岩土及地下工程教育部重点实验室，上海 200092

基金项目: 国家自然科学基金项目（51178342）

详细信息

作者简介:
高广运(1961- )，男，安徽人，博士，教授，博士生导师，从事土动力学和桩基的研究。E-mail: gaoguangyun@263.net。

中图分类号: A
计量
- 文章访问数: 0335
- HTML全文浏览量: 0
- PDF下载量: 0866
出版历程
- 收稿日期: 2014-11-19
- 发布日期: 2015-10-19

Ground vibration induced by moving train on viaduct with group pile foundation

1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China;
2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China

摘要

摘要: 采用半解析数值方法分析列车运行引起高架桥群桩基础地面振动，研究合理设计桩基减小地面振动。半解析数值模型包括列车-轨道模型、高架桥模型、群桩模型。列车轨道模型中采用多质点弹簧-阻尼模型模拟列车，采用美国功率谱描述轨道随机不平顺，使用Euler梁模拟钢轨，采用Hertzian非线性公式描述轮轨接触，采用振型分解法求解轮轨作用力。铁路高架桥采用弹性支座简支梁模拟，采用传递系数矩阵和群桩影响因子分析桥墩下群桩的动力阻抗，根据桥墩的动力平衡方程求得桥墩-地基相互作用力，采用Green函数求得弹性半空间地面振动。研究铁路高架桥下群桩参数对地面振动的影响，分析不同桩长、桩直径、桩间距和轨道不平顺条件下地面振动速度1/3倍频程的大小。结果表明：轨道不平顺对桥墩作用力有较大影响，对小于6 Hz的地面振动影响较小，对大于6 Hz的地面振动影响较大。合适调整桥梁跨度与车速组合可减小地面振动。车速小于260 km/h时，桩径对地面振动影响较小;车速大于260 km/h时，增加桩径可减小地面振动。适当增加桩间距可避开振动增大区、减小地面振动随车速的增加。合理设计桩长可减小地面振动的增大区域。
- 高架桥 /
- 高速列车 /
- 地面振动 /
- 群桩动力阻抗 /
- 1/3倍频程
Abstract: The semi-analytic method is adopted to analyze the influence of ground vibration due to train moving on viaduct supported by group piles to explore ways of reducing ground vibration. The semi-analytic numerical models include train-rail model, viaduct model and group pile model. The train is simulated by a multiple-mass spring-damping model. The America power spectrum is used to model the rail irregularities. The rail is modeled by Eular beam and the wheel-rail contact Hertzian non-linear formula is used. The wheel-rail force is solved by modal analysis method. The railway viaduct is modeled by elastically supported beam, and the impedance of group piles is analyzed by transfer coefficient matrix and interaction factors. The bridge pier-ground interaction force is solved by dynamic equilibrium equations and the ground vibration on half space is solved by Green function. The influence of the parameters of group piles on ground vibration is discussed. The results show that the rail irregularities have a great influence on pier force. The ground vibration greater than 6 Hz is influenced by the rail irregularities while the vibration less than 6 Hz is little affected. The ground vibration can be mitigated by combined bridge span and train speed. When the train speed is less than 260 km/h, the influence of pile diameter on ground vibration is limited; while it is greater than 260 km/h, increasing pile diameter can reduce the ground vibration. Increasing the pile spacing has two advantages of keeping away from the vibration increasing area and reducing the ground vibration as the increase of train speed. The increasing area of ground vibration can be reduced by the rational design of pile length.
- viaduct /
- high speed train /
- ground vibration /
- dynamic impedance of group pile /
- 1/3 octave

HTML全文

参考文献(30)

[1]	夏禾, 曹艳梅. 轨道交通引起的环境振动问题[J]. 铁道科学与工程学报, 2004, 1(1): 44-51. (XIA He, CAO Yan-mei. Problem of railway traffic induced vibrations of environments[J]. Journal of Railway Science and Engineering, 2004, 1(1): 44-51. (in Chinese))
[2]	TAKEMIYA H. Field vibration mitigation by honeycomb WIB for pile foundations of a high-speed train viaduct[J]. Soil Dynamics and Earthquake Engineering, 2004, 24(1): 69-87.
[3]	TAKEMIYA H, BIAN X C. Shinkansen high-speed train induced ground vibrations in view of viaduct-ground interaction[J]. Soil Dynamics and Earthquake Engineering, 2007, 27(6): 506-520.
[4]	TAKEMIYA H. Analyses of wave field from high-speed train on viaduct at shallow/deep soft grounds[J]. Journal of Sound and Vibration, 2008, 310(3): 631-649.
[5]	WU Y S, YANG Y B. A semi-analytical approach for analyzing ground vibrations caused by trains moving over elevated bridges[J]. Soil Dynamics and Earthquake Engineering, 2004, 24(12): 949-962.
[6]	YANG Y B, WU Y S. Transmission of vibrations from high speed trains through viaducts and foundations to the ground[J]. Journal of the Chinese Institute of Engineers, 2005, 28(2): 251-266.
[7]	XIA H, ZHANG N, CAO Y M. Experimental study of train-induced vibrations of environments and buildings[J]. Journal of Sound and Vibration, 2005, 280(3): 1017-1029.
[8]	CAO Y, XIA H, LI Z. A semi-analytical/FEM model for predicting ground vibrations induced by high-speed train through continuous girder bridge[J]. Journal of Mechanical Science and Technology, 2012, 26(8): 2485-2496.
[9]	JU S H. Finite element analyses of wave propagations due to a high‐speed train across bridges[J]. International Journal for Numerical Methods in Engineering, 2002, 54(9): 1391-1408.
[10]	JU S H. Finite element analysis of structure-borne vibration from high-speed train[J]. Soil Dynamics and Earthquake Engineering, 2007, 27(3): 259-273.
[11]	CHEN Y J, JU S H, NI S H, et al. Prediction methodology for ground vibration induced by passing trains on bridge structures[J]. Journal of Sound and Vibration, 2007, 302(4): 806-820.
[12]	HE X W, KAWATANI M, NISHIYAMA S. An analytical approach to train-induced site vibration around Shinkansen viaducts[J]. Structure and Infrastructure Engineering, 2010, 6(6): 689-701.
[13]	LI X Z, LIU X H, LIU D J, et al. Influences of soil- structure interaction on coupled vibration of train- bridge system: theoretical and experimental study[J]. Advances in Structural Engineering, 2013, 16(8): 1355-1364.
[14]	ROMERO A, SOLÍS M, DOMÍNGUEZ J, et al. Soil- structure interaction in resonant railway bridges[J]. Soil Dynamics and Earthquake Engineering, 2013, 47: 108-116.
[15]	蒋通, 程昌熟. 用薄层法分析高架轨道交通引发的环境振动[J]. 振动工程学报, 2008, 20(6): 623-628. (JIANG Tong, CHENG Chang-shu. Environmental vibration induced by elevated railway traffic using thin-layer method[J]. Journal of Vibration Engineering, 2008, 20(6): 623-628. (in Chinese))
[16]	陈建国. 高架轨道交通引起的环境振动预测与参数研究[D]. 北京: 北京交通大学, 2009. (CHEN Jian-guo. Prediction and parameters research on viaduct train-induced environmental vibrations[D]. Beijing: Beijing Jiaotong University, 2009. (in Chinese))
[17]	AUERSCH L. Ground vibration due to railway traffic—the calculation of the effects of moving static loads and their experimental verification[J]. Journal of Sound and Vibration, 2006, 293(3): 599-610.
[18]	KOUROUSSIS G, VERLINDEN O, CONTI C. Free field vibrations caused by high-speed lines: Measurement and time domain simulation[J]. Soil Dynamics and Earthquake Engineering, 2011, 31(4): 692-707.
[19]	CONNOLLY D, GIANNOPOULOS A, FORDE M C. Numerical modelling of ground borne vibrations from high speed rail lines on embankments[J]. Soil Dynamics and Earthquake Engineering, 2013, 46(1): 13-19.
[20]	KAYNIA A M, KAUSEL E. Dynamic stiffness and seismic response of pile groups[J]. NASA STI/Recon Technical Report N, 1982, 83: 16586.
[21]	NOVAK M. Vertical vibration of floating piles[J]. Journal of the Engineering Mechanics Division, 1977, 103(1): 153-168.
[22]	DOBRY R, GAZETAS G. Simple method for dynamic stiffness and damping of floating pile groups[J]. Géotechnique, 1988, 38(4): 557-574.
[23]	GAZETAS G, MAKRIS N. Dynamic pile-soil-pile interaction. Part I: analysis of axial vibration[J]. Earthquake Engineering & Structural Dynamics, 1991, 20(2): 115-132.
[24]	GAZETAS G, FAN K, KAYNIA A. Dynamic response of pile groups with different configurations[J]. Soil Dynamics and Earthquake Engineering, 1993, 12(4): 239-257.
[25]	李广慧. 车辆-无碴轨道-桥梁系统振动特性及其应用[M]. 郑州: 黄河水利出版社, 2007. (LI Guang-hui. The vibration characteristics of vehicle-ballastless track- bridge system and its application[M]. Zhengzhou: The Yellow River Water Conservancy Press, 2007.(in Chinese))
[26]	MYLONAKIS G, GAZETAS G. Vertical vibration and additional distress of grouped piles in layered soil[J]. Soils and Foundations, 1998, 38(1): 1-14.
[27]	MIURA K, KAYNIA A M, MASUDA K, et al. Dynamic behavior of pile foundations in homogeneous and non‐homogeneous media[J]. Earthquake Engineering & Structural Dynamics, 1994, 23(2): 183-192.
[28]	WOLF J P. Foundation vibration analysis using simple physical models[M]. New Jersey: Prentice Hall Press, 1994. . 振动与冲击, 2011, 30(2): 159-163. (CHEN Jian-guo, XIAN He, YAO Jin-bao. Test for environment vibration induced by trains on viaduct[J]. Journal of Vibration and Shock, 2011, 30(2): 159-163. (in Chinese))
[29]	KOUROUSSIS G, CONNOLLY D P, VERLINDEN O. Railway-induced ground vibrations-a review of vehicle effects[J]. International Journal of Rail Transportation, 2014, 2(2): 69-110.
[30]	陈果, 翟婉明, 左洪福. 仿真计算比较我国干线谱与国外典型轨道谱[J]. 铁道学报, 2001, 23(3): 82-87. (CHEN Guo, ZHAI Wan-ming, ZUO Hong-fu. Comparing track irregularities PSD of Chinese main lines with foreign typical lines by numerical simulation computation[J]. Journal of the China Railway Society, 2001, 23(3): 82-87. (in Chinese))
