遮帘式板桩码头的工作机理

蔡正银; 侯伟; 关云飞

doi:10.11779/CJGE201510001

遮帘式板桩码头的工作机理 English Version

1. 南京水利科学研究院岩土工程研究所，江苏南京 210024;
2. 同济大学地下建筑与工程系，上海 200092

基金项目: 国家高技术研究发展计划（“863”计划）课题项目

详细信息

作者简介:
蔡正银（1965- ），男，江苏海安人，教授级高级工程师，博士生导师，从事岩土基本理论和试验研究工作。E-mail: zycai@nhri.cn。

中图分类号: A
计量
- 文章访问数: 404
- HTML全文浏览量: 5
- PDF下载量: 348
出版历程
- 收稿日期: 2014-09-09
- 发布日期: 2015-10-19

Mechanism of sheet-pile wharf with barrier piles

1. Department of Geotechnical Engineering, Nanjing Hydraulic Research Institute, Nanjing 210024, China;
2. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China

摘要

摘要: 板桩码头结构深水化过程中遇到的主要问题是如何克服作用于前墙上的随开挖深度剧增的土压力。遮帘式板桩结构的设计思路是在传统的板桩码头前墙陆侧增加一排遮帘桩，利用其遮帘效应来分担一部分作用于前墙上的土压力，从而达到建设大型深水板桩码头的条件。通过前期开发的基于ABAQUS有限元平台的土和结构相互作用分析软件，采用“南水双屈服面弹塑性本构模型”来模拟地基土的应力应变关系，通过基于接触力学的本构模型来模拟土和码头结构的相互作用，研究了遮帘桩的工作机理和遮帘效应，探讨了遮帘式板桩码头前墙两侧的土压力分布规律，以及码头结构的变形和弯矩分布规律。通过与单锚板桩码头结构的比较，验证了遮帘式板桩码头对于板桩码头深水化的作用。
- 板桩码头 /
- 遮帘桩 /
- 数值模拟 /
- 土压力
Abstract: The main problem for deep-water sheet-pile wharf is how to deal with the earth pressures acting on the front wall, which dramatically increase with the excavation depth. The design idea of the barrier-pile structure is as follows: a row of barrier piles are constructed in front of the traditional sheep-pile wharf, and part of the earth pressures acting on the front wall are shared owing to their barrio effects so as to reach the condition for building large deep-water sheet-pile wharf. Using the developed analysis software for soil-structure interaction based on ABAQUS, the NHRI double-yield face elastoplastic constitutive model is employed to simulate stress-strain relation of soils. The constitutive model based on contact mechanics is used to simulate soil-wharf interaction. The mechanism and effect of barrier piles are studied, the distribution rules of earth pressures at the two sides of the front wall of the sheet-pile wharf with barrier piles are discussed as well as its deformation and distribution of bending moment. By comparing with the sheet-pile wharf with single anchorage, the deep-water sheet-pile wharf with barrier piles is validated.
- sheet-pile wharf /
- barrier pile /
- numerical simulation /
- earth pressure

HTML全文

参考文献(10)

[1]	刘永绣, 吴荔丹, 徐光明, 等. 遮帘式板桩码头工作机制[J]. 水利水运工程学报, 2006(2): 8-12. (LIU Yong-xiu, WU Li-dan, XU Guang-ming, et al. Working mechanism of sheet pile wharf with barrier piles[J]. Hydro-Science and Engineering, 2006(2): 8-12. (in Chinese))
[2]	蔡正银, 徐光明, 曾有金, 等. 遮帘式板桩码头土压力离心模型试验研究[J]. 港工技术, 2007, 26(6): 51-55. (CAI Zheng-yin, XU Guang-ming, ZENG You-jin, et al. Experimental study of centrifugal models to test earth pressure on covered sheet pile wharfs[J]. Port Engineering Technology, 2007, 26(6): 51-55. (in Chinese))
[3]	李景林, 蔡正银, 徐光明, 等. 遮帘式板桩码头结构离心模型试验[J]. 岩石力学与工程学报, 2007, 26(6): 1182-1187. (LI Jing-lin, CAI Zheng-yin, XU Guang-ming, et al. Centrifuge modelling test on covered sheet- piled structure of wharf[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(6): 1182-1187. (in Chinese))
[4]	焦志斌, 蔡正银, 王剑平, 等. 遮帘式板桩码头原型观测技术研究[J]. 港工技术, 2005(增刊): 56-59. (JIAO Zhi-bin, CAI Zheng-yin, WANG jian-ping, et al. Study on prototype observation technique of semi-covered type of sheet pile[J]. Port Engineering Technology, 2005(S0): 56-59. (in Chinese))
[5]	李元音, 刘永绣. 遮帘式板桩码头结构的空间有限元法分析[J]. 港工技术, 2005(增刊): 37-40.( LI Yuan-yin,LIU Yong-xiu. Spatial finite element method to analyze covered type structure of sheet piles wharf structure[J]. Port Engineering Technology, 2005(S0): 37-40. (in Chinese))
[6]	彭益达, 赵利平. 港池开挖对遮帘式板桩码头结构的影响[J]. 中国水运, 2014, 14(4): 303-305. (PENG Yi-da, ZHAO Li-ping. The impaction of harbor excavation on the covered sheet-piled wharf[J]. China Water Transport, 2014, 14(4): 303-305. (in Chinese))
[7]	刘文平, 郑颖人, 蔡正银, 等. 遮帘式板桩码头结构有限元分析[J]. 岩土工程学报, 2010, 32(4): 573-577. (LIU Wen-ping, ZHENG Ying-ren, CAI Zheng-yin, et al. Finite element method for covered sheet pile wharfs[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(4): 573-577. (in Chinese))
[8]	黄伟, 潘泓, 王燕燕. 全遮帘式板桩码头结构遮帘桩合理桩间距确定[J]. 地下空间与工程学报, 2012, 8(1): 129-134. (HUANG Wei, PAN Hong, WANG Yan-yan. Determination on rational spacing of barrier pile for all-covered type of sheet pile wharf[J]. Chinese Journal of Underground Space and Engineering, 2012, 8(1): 129-134. (in Chinese))
[9]	王元战, 龚晓龙, 李斌. 遮帘式板桩码头的遮帘效果及其影响因素分析[J]. 水道港口, 2014, 35(1): 81-86. (WANG Yuan-zhan, GONG Xiao-long, LI Bin. Analysis on sheltering effect of covered sheet pile wharf and its influencing factors[J]. Journal of Waterway and Harbor, 2014, 35(1): 81-86. (in Chinese))
[10]	司海宝, 蔡正银, 余缙. 遮帘式板桩码头结构与土共同作用3D数值分析[J]. 土木工程学报, 2012(5): 182-190. (SI Hai-bao, CAI Zheng-yin, YU Jin. 3D numerical modeling of pile-soil interaction for covered sheet-piled wharf[J]. China Civil Engineering Journal, 2012(5): 182-190. (in Chinese))
