砂质泥岩卸荷流变本构模型研究

原先凡; 邓华锋; 李建林

doi:10.11779/CJGE201509024

砂质泥岩卸荷流变本构模型研究 English Version

1. 中国电建集团成都勘测设计研究院有限公司,四川成都 610072; 2. 三峡大学三峡库区地质灾害教育部重点实验室,湖北宜昌 443002; 3. 中国水利水电科学研究院流域水循环模拟与调控国家重点实验室,北京 100044

基金项目: 中国水利水电科学研究院流域水循环模拟与调控国家重点; 实验室开放研究基金项目（IWHR-SKL-201316）; 湖北省高等学校青; 年教师深入企业行动计划项目（XD2014035）

详细信息

作者简介:
原先凡(1988- ),男,河南焦作人,硕士,助理工程师,主要从事水利水电工程地质及岩土工程方面的研究工作。E-mail: xianfanyuan@163.com。。

计量
- 文章访问数: 0302
- HTML全文浏览量: 0
- PDF下载量: 0237
出版历程
- 收稿日期: 2014-11-15
- 发布日期: 2015-09-17

Unloading rheological constitutive model for sandy mudstone

1. PowerChina Chengdu Engineering Corporation Limited, Chengdu 610072, China; 2. Key Laboratory of Geological Hazards on Three Gorges Reservoir Area of Ministry of Education,China Three Gorges University, Yichang 443002, China; 3. State Key Laboratory of Simulation and Regulation of Water Cycle in River Basin, China Institute of Water Resources and Hydropower Research, Beijing 100044, China

摘要

摘要: 基于隧洞开挖过程中围岩应力的实际调整路径设计加轴压卸围压条件下的分级卸荷流变实验,对某水电站引水隧洞洞轴线主要穿越的砂质泥岩的卸荷流变力学特性进行研究。试验结果表明：①应力水平低于岩石破坏应力时,砂质泥岩的流变只表现出衰减流变阶段和稳态流变阶段,且随着围压的逐级卸除,应力水平逐渐超过岩石的长期强度,试样的稳态流变速率由最初接近于0的常数逐渐增大至一个大于0的常数;②应力水平高于岩石破坏应力时,砂质泥岩经过衰减流变阶段和稳态流变阶段之后进入非线性加速流变阶段直至发生破坏,通过对比发现,不同卸荷初始围压下试样发生流变破坏的总历时不同,且各试样发生非线性加速流变的启动时间也显著不同。对砂质泥岩卸荷流变试验结果分析表明,西元模型能够较好地描述应力水平低于破坏应力时砂质泥岩的流变特性,但却无法反映应力水平高于其破坏应力时的非线性加速流变特征,基于此,引入岩石非线性加速流变启动元件,通过将其与西元模型相结合建立了一个新的非线性黏弹塑性流变模型,对提出的模型进行参数辨识,并将流变模型拟合结果与试验结果进行对比,结果表明,新建立的卸荷流变本构模型能够较全面地描述砂质泥岩卸荷流变破坏的全过程,证明所建模型是正确合理的。
- 砂质泥岩 /
- 加轴压卸围压 /
- 卸荷流变 /
- 长期强度 /
- 非线性黏弹塑性流变模型
Abstract: Based on the actual adjustment path of the surrounding rock stress in the process of tunnel excavation, the grading unloading rheological tests under unloading confining pressure with axial compression are designed, and the unloading rheological mechanical properties of sandy mudstone which is mainly threaded by the tunnel axis of diversion tunnel of a hydropower station are studied. The test results show that: (1) When the stress level is lower than the rock failure stress, the rheology of sandy mudstone only has the stages of attenuation creep and steady-state creep, and with the unloading of confining pressure step by step, the stress level is gradually over the long-term strength of rock, and the steady-state creep rate of sample gradually increases from being close to 0 originally to a constant greater than 0. (2) When the stress level is higher than the rock failure stress, the sandy mudstone goes into nonlinear acceleration creep stage until destruction after the stages of attenuation creep and steady-state creep. By comparison, the whole time of the sample for rheological damage under different initial unloading confining pressures is different, and the start time of the sample for accelerated nonlinear rheology is also significantly different. The analysis of the test results shows that Nishihara model can well describe the rheological properties of sandy mudstone when the stress level is lower than the failure stress, but it cannot reflect the nonlinear accelerating rheological characteristics when the stress level is higher than its failure stress. Based on this, by introducing a start element of nonlinear acceleration creep of rock and combining with Nishihara model, a new nonlinear visco-elastoplastic rheological model is established. The rheological parameters of the model are identified, and the fitting results of the rheological model are compared with the test results. It is concluded that the proposed unloading rheological constitutive model can fully

HTML全文

参考文献(15)

[1]	王宇. 软岩瞬时及流变力学特性试验研究[D]. 武汉: 武汉大学, 2012. (WANG Yu. Experimental study on the instantaneous and rheological mechanical properties os soft rock[D]. Wuhan: Wuhan University, 2012. (in Chinese))
[2]	杨春和, 陈锋, 曾义金. 盐岩蠕变损伤关系研究[J]. 岩石力学与工程学报, 2002, 21(11): 1602-1604. (YANG Chun-he, CHEN Feng, ZENG Yi-jin. Investigation on creep damage constitutive theory of salt rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2002, 21(11): 1602-1604. (in Chinese))
[3]	韦立德, 杨春和, 徐卫亚. 基于细观力学的盐岩蠕变损伤本构模型研究[J]. 岩石力学与工程学报, 2005, 24(23): 4253-4258. (WEI Li-de, YANG Chun-he, XU Wei-ya. Study on creep damage constitutive model of salt rock based on mesomechanics[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(23): 4253-4258. (in Chinese))
[4]	胡其志, 冯夏庭, 周辉. 考虑温度损伤的盐岩蠕变本构关系研究[J]. 岩土力学, 2009, 30(8): 2245-2248. (HU Qi-zhi, FENG Xia-ting, ZHOU Hui. Study of creep model of rock salt with thermal damage considered[J]. Rock and Soil Mechanics, 2009, 30(8): 2245-2248. (in Chinese))
[5]	ENRICO M, TSUTOMU Y. A non-associated viscoplastic model for the behaviour of granite in triaxial compression[J]. Mechanics of Materials, 2001, 33(5): 283-293.
[6]	陈沅江, 潘长良, 曹平, 等. 软岩流变的一种新力学模型[J]. 岩土力学, 2003, 24(2): 209-214. (CHEN Ruan-jiang, PAN Chang-liang, CAO Ping, el al. A new mechanical model for soft rock rheology[J]. Rock and Soil Mechanics, 2003, 24(2): 209-214. (in Chinese))
[7]	陈沅江, 潘长良, 曹平, 等. 基于内时理论的软岩流变本构模型[J]. 中国有色金属学报, 2003, 13(3): 735-742. (CHEN Ruan-jiang, PAN Chang-liang, CAO Ping, el al. Endochronic rheological constitutive model of soft rock[J]. The Chinese Journal of Nonferrous Metals, 2003, 13(3): 735-742. (in Chinese))
[8]	巫德斌, 徐卫亚, 朱珍德, 等. 泥板岩流变试验与黏弹性本构模型研究[J]. 岩石力学与工程学报, 2004, 23(8): 1242-1246. (WU De-bin, XU Wei-ya, ZHU Zhen-de, et al. Study on rheological test and viscoelastical constitutive model for shale[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(8): 1242-1246. (in Chinese))
[9]	袁海平, 曹平, 万文, 等. 分级加卸载条件下软弱复杂矿岩蠕变规律研究[J]. 岩石力学与工程学报, 2006, 25(8): 1575-1581. (YUAN Hai-ping, CAO Ping, WAN Wen, et al. Study on creep rules of soft and intricate ore-rock under step load and unload[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25(8): 1575-1581. (in Chinese))
[10]	佘成学. 岩石非线性黏弹塑性蠕变模型研究[J]. 岩石力学与工程学报, 2009, 28(10): 2006-2011. (SHE Cheng-xue. Research on nonlinear viscoelasto-plastic creep model of rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(10): 2006-2011. (in Chinese))
[11]	赵宝云, 刘东燕, 郑志明, 等. 基于短时三轴蠕变试验的岩石非线性黏弹塑性蠕变模型研究[J].采矿与安全工程学报, 2011, 28(3): 446-451. (ZHAO Bao-yun, LIU Dong-yan, ZHENG Zhi-ming, et al. Non-linear visco-elastic plastic creep model of rocks based on the short time triaxial creep test[J]. Journal of Mining & Safety Engineering, 2011, 28(3): 446-451. (in Chinese))
[12]	范庆忠, 高延法. 软岩蠕变特性及非线性模型研究[J]. 岩石力学与工程学报, 2007, 26(2): 391-396. (FAN Qing-zhong, GAO Yan-fa. Study on creep properties and nonlinear creep model of soft rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(2): 391-396. (in Chinese))
[13]	王宇, 李建林, 邓华锋, 等. 软岩三轴卸荷流变力学特性及本构模型研究[J]. 岩土力学, 2012, 33(11): 3338-3344. (WANG Yu, LI Jian-lin, DENG Hua-feng, et al. Investigation on unloading triaxial rheological mechanical properties of soft rock and its constitutive model[J]. Rock and Soil Mechanics, 2012, 33(11): 3338-3344. (in Chinese))
[14]	李建林. 卸荷岩体力学[M]. 北京:中国水利水电出版社, 2003. (LI Jian-lin. Unloading rock mass mechanics[M]. Beijing: China Water Power Press, 2003. (in Chinese))
[15]	张治亮, 徐卫亚, 王伟. 向家坝水电站坝基挤压带岩石三轴蠕变试验及非线性黏弹塑性蠕变模型研究[J]. 岩石力学与工程学报, 2011, 30(1): 132-140. (ZHANG Zhi-liang, XU Wei-ya, WANG Wei. Study of triaxial creep tests and its nonlinear visco-elastoplastic creep model of rock from compressive zone of dam foundation in Xiangjiaba hydropower station[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(1): 132-140. (in Chinese))
