花岗岩峰后力学特性试验与模型研究

孙闯, 张树光, 贾宝新, 吴作启

孙闯, 张树光, 贾宝新, 吴作启. 花岗岩峰后力学特性试验与模型研究[J]. 岩土工程学报, 2015, 37(5): 847-852. DOI: 10.11779/CJGE201505010
引用本文: 孙闯, 张树光, 贾宝新, 吴作启. 花岗岩峰后力学特性试验与模型研究[J]. 岩土工程学报, 2015, 37(5): 847-852. DOI: 10.11779/CJGE201505010
shu
SUN Chuang, ZHANG Shu-guang, JIA Bao-xin, WU Zuo-qi. Physical and numerical model tests on post-peak mechanical properties of granite[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(5): 847-852. DOI: 10.11779/CJGE201505010
Citation: SUN Chuang, ZHANG Shu-guang, JIA Bao-xin, WU Zuo-qi. Physical and numerical model tests on post-peak mechanical properties of granite[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(5): 847-852. DOI: 10.11779/CJGE201505010
shu

花岗岩峰后力学特性试验与模型研究  English Version

  • 辽宁工程技术大学土木与交通学院,辽宁 阜新 123000

基金项目: 国家自然科学基金项目（51174268,51274109）
详细信息
    作者简介:

    孙 闯(1983- ),男,辽宁阜新人,博士,讲师,主要从事岩土与地下工程等方面的研究与教学工作。E-mail: sunchuang88@163.com。

Physical and numerical model tests on post-peak mechanical properties of granite

  • School of Civil Engineering and Transportation, Liaoning Technology University, Fuxin 123000, China

摘要

    摘要
  • 摘要: 深部围岩在开挖卸载过程中表现出的峰后复杂力学特性一直是工程界十分关注的问题,深入研究岩石峰后力学行为对深部资源开采工程具有重要意义。以深部立井马头门工程为依托,通过室内试验方法研究花岗岩峰后力学特性,采用非线性拟合方法获得花岗岩峰后软化模量与围压的指数关系式,假定岩石的剪胀角为恒定值,基于塑性理论构建考虑围压及剪胀角影响的岩石峰后应变软化模型;以FLAC3D为平台开发数学模型并进行验证,通过构建马头门巷道数值模型,分析深部围岩在应变软化条件下的破坏特征规律。通过研究可知,花岗岩峰后破坏具有脆-延性转化趋势,在高围压条件下,岩石峰后表现出塑性软化破坏特征,岩石峰后软化模量随着围压的增大而减小;通过FLAC3D进行数值验证可知,构建的应变软化模型与试验数据基本吻合,所建立的应变软化模型具有较高的可靠性;通过数值模拟方法分析深部马头门巷道围岩破坏特征可知,巷道拱顶及拱脚等局部区域出现了塑性剪切应变,与现场巷道围岩破损位置及深度基本相同。
    Abstract: The deep surrounding rock in the process of excavation exhibits complex post-peak mechanical properties. It has long been an issue of great concern to the engineering. Thorough studies on the post-peak mechanical properties are of great significance to resource extraction projects. Based on the deep shaft horsehead project, the mechanical post-peak properties of the granite are studied by using laboratory tests. The nonlinear fitting method is used to obtain the exponential relationship between the post-peak softening modulus and confining pressure of granite. The rock dilatancy angle is assumed to be constant. A post-peak strain softening model is established considering confining pressure and dilatancy angle based on the theory of plasticity. Using FLAC3D as the platform to develop and validate a mathematical model for horsehead tunnel to analyze the failure rules of the deep surrounding rock under strain softening conditions. The research results show that the post-peak destruction of granite has a trend of brittle to ductile transformation. Under high confining pressure, it exhibits plastic softening damage characteristic. The post-peak softening modulus increases with the decrease of the confining pressure. The FLAC3D numerical verification shows that the results of the strain softening model agree with the experimental data, and that the proposed model is reliable. By analyzing the properties of horsehead roadway damage through numerical simulation, it is found that the plastic shear strain appeares in partial areas, such as the vault and arch foot, and that the location and depth are similar to the field ones.
    • HTML全文
    • 参考文献(15)
  • [1] LEE Y, PIETRUSZCZAK S. A new numerical procedure for elasto-plastic analysis of a circular opening excavated in a strain-softening rock mass[J]. Tunnelling and Underground Space Technology, 2008, 23(3): 588-599.
    [2] ALEJANO L R, RODRGUEZ-DONO A, VEIGA M. Plastic radii and longitudinal deformation profiles of tunnels excavatedin strain-softening rock masses[J]. Tunnelling and Underground Space Technology, 2012, 30(4): 169-182.
    [3] HAJIABDOLMAJID V, KAISER P K, MARTIN C D. Modelling brittle failure of rock[J]. International Journal of Rock Mechanics & Mining Sciences, 2002, 39(5): 731-741.
    [4] 孙闯, 张向东, 李永靖. 深部软弱岩体峰后等效力学模型及数值计算研究[J]. 岩土工程学报, 2014, 36(6): 1113-1122. (SUN Chuang, ZHANG Xiang-dong, LI Yong-jing. Soft rock equivalent mechanical model of post-peak in deep and numerical computing research[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(6): 1113-1122. (in Chinese))
    [5] 陆银龙, 王连国, 杨峰, 等. 软弱岩石峰后应变软化力学特性研究[J]. 岩石力学与工程学报, 2010, 29(3): 640-649. (LU Yin-long, WANG Lian-guo, YANG Feng, et al. Post-peak strain softening mechanical properties of weak rock[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(3): 640-649. (in Chinese))
    [6] 余华中, 阮怀宁, 褚卫江. 大理岩脆—延—塑转换特性的细观模拟拟研究[J]. 岩石力学与工程学报, 2013, 32(1): 55-65. (YU Hua-zhong, RUAN Huai-ning, CHU Wei-jiang. Mesoscopic simulation study of brittle-ductile-plastic transition character of marble[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(1): 55-65. (in Chinese))
    [7] ALEJANO L R, RODRIGUEZ-DONO A, ALONSO E, et al. Ground reaction curves for tunnels excavated in different quality rock masses showing several types of post-failure behaviour[J]. Tunnelling and Underground Space Technology, 2009, 11(6): 689-705.
    [8] ALEJANO L R, ALONSO E. Application of the convergence confinement method to tunnels in rock masses exhibiting Hoek-Brown strain-softening behaviour[J]. International Journal of Rock Mechanics and Mining Sciences, 2010, 47(6): 150-160.
    [9] SHARAN S K. Analytical solutions for stresses and displacements around a circular opening in a generalized Hoek-Brown rock[J]. International Journal of Rock Mechanics and Mining Sciences, 2008, 45(1): 78-85.
    [10] 王水林, 吴振君, 李春光, 等. 应变软化模拟与圆形隧道衬砌分析[J]. 岩土力学, 2010, 31(6): 1929-1937. (WANG Shui-lin, WU Zhen-jun, LI Chun-guang, et al. Modeling of strain-softening and analysis of a lining for circular tunnel[J]. Rock and Soil Mechanics, 2010, 31(6): 1929-1937. (in Chinese))
    [11] 孙闯, 张向东, 李永靖. 高应力软岩巷道围岩与支护结构相互作用分析[J]. 岩土力学, 2013, 34(9): 2601-2609. (SUN Chuang, ZHANG Xiang-dong, LI Yong-jing. Analysis of interaction between surrounding rock and support under high stressed soft rock roadway[J]. Rock and Soil Mechanics, 2013, 34(9): 2601-2609. (in Chinese))
    [12] 孙闯, 张向东, 刘家顺. 基于Hoek-Brown强度准则的应变软化模型在隧道工程中的应用[J]. 岩土力学, 2013, 34(10): 2954-2962. (SUN Chuang, ZHANG Xiang-dong, LIU Jia-shun. Application of the strain softening method to tunnels based on the Hoek-Brown strength criterion[J]. Rock and Soil Mechanics, 2013, 34(10): 2954-2962. (in Chinese))
    [13] HOEK E, BROWN E T. Practical estimates of rock mass strength[J]. International Journal of Rock Mechanics and Mining Sciences, 1997, 34(8): 1165-86.
    [14] ZHAO X G, CAI M. A dilation angle model for rocks[J]. International Journal of Rock Mechanics and Mining Sciences, 2010, 47(3): 368-384.
    [15] ALEJANO L R, ALONSO E. Considerations of the dilatancy angle in rocks and rock masses[J]. International Journal of Rock Mechanics and Mining Sciences, 2005, 42(7): 481-507.
