Application of spectrum inversion method in GPR signal processing for tunnel lining detection
-
摘要: 隧道衬砌模型的空间结构属于典型的层状分布,采用探地雷达进行隧道二衬检测时,往往很难识别高度小于调谐厚度的脱空。通过建立含有脱空薄层的隧道二衬层状几何模型,结合电磁波在隧道衬砌中的传播规律,给出了隧道衬砌检测时电磁波的反射模型,并推导了其广义反射系数谱域表达式,从而提出一种根据反射系数序列频谱估算隧道二衬厚度及脱空高度的反演方法。通过分析反射系数序列的幅度谱属性,进一步提出一种估计脱空层高度的快速方法,即根据幅度谱凹陷周期确定脱空层双程走时,进而估算脱空层高度。最后,利用1stOpt数学优化分析软件进行全局优化,并反演求解各参数。物理模型实验及现场应用实例的处理结果表明,当脱空厚度小于1/4波长时,本文所述的频谱反演法仍能准确反演出二衬厚度及脱空层高度,从而提高了探地雷达资料的垂直分辨率。Abstract: The spatial structure of tunnel lining model is a typical stratiform distribution, so it is difficult to identify the void area if its height is less than tuning thickness when using ground penetrating radar (GPR) to detect the second lining of tunnel. In this paper, by establishing a geometrical model for the second lining layer of tunnel including void area and considering the spreading law of electromagnetic waves in tunnel lining, a reflection model for electromagnetic waves in tunnel lining detection is obtained, and the generalized reflection coefficient in spectrum expression is deduced as well as an inversion method to further estimate the lining thickness of tunnel and the height of void area according to the reflection coefficient sequence spectrum. By analyzing the amplitude spectrum properties of the reflection coefficient sequence, a quick method to estimate the height of void area is proposed, namely determining the two-way travel time of void area and leading to the height of void area according to the depressing period of the amplitude spectra. Finally, 1stopt mathematical optimization analysis software is adopted for the global optimization and calculation of parameters. The results of physical model experiments and field tests indicate that the spectrum inversion method can also estimate the lining thickness of tunnel and the height of void area accurately when the height of void area is less than 1/4 wavelength, consequently enhancing the vertical resolution of GPR data.
-
[1] 李晋平, 邵丕彦, 谷牧. 地质雷达在铁路隧道工程质量检测中的应用[J]. 中国铁道科学, 2006, 27(2): 56-59. (LI Jin-ping, SHAO Pi-yan, GU Mu. Application and analysis of GPR in railway tunnel engineering quality inspection[J]. China Railway Science, 2006, 27(2): 56-59. (in Chinese)) [2] 郭有劲. 地质雷达在铁路隧道衬砌质量检测中的应用[J]. 铁道工程学报, 2002, 74(2): 71-74. (GUO You-jin. Exploration and application of geology radar for quality examination of railway tunnel lining[J]. Journal of Railway Engineering Society, 2002, 74(2): 71-74. (in Chinese)) [3] SIGGINS A F, WHITELY R J A. Laboratory simulation of high frequency GPR responses of damaged tunnel liners[J]. Proceedings of SPIE-The International Society for Optical Engineering, 2000, 40(11): 805-811. [4] BUNGEY J H, MILLARD S G, SHAW M R. Influence of reinforcing steel on radar surveys of concrete structures[J]. Construction and Building Materials, 1994, 8(2): 119-126. [5] 杨艳青, 贺少辉, 齐法琳, 等. 铁路隧道复合式衬砌地质雷达检测模拟试验研究[J]. 岩土工程学报, 2012, 34(6): 1159-1165. (YANG Yan-qing, HE Shao-hui, QI Fa-lin, et al. Simulation tests on GPR detection of composite linings of railway tunnels[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(6): 1159-1165. (in Chinese)) [6] 刘新荣, 舒志乐, 朱成红, 等. 隧道衬砌空洞探地雷达三维探测正演研究[J]. 岩石力学与工程学报, 2010, 29(11): 2221-2229. (LIU Xin-rong, SHU Zhi-le, ZHU Cheng-hong, et al. Study of forward simulation for ground penetrating radar three-dimensional detection of tunnel lining cavity[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(11): 2221-2229. (in Chinese) ) [7] 杨峰, 彭苏萍, 刘杰, 等. 衬砌脱空雷达波数值模拟与定量解释[J]. 铁道学报, 2008, 30(5): 92-96. (YANG Feng, PENG Su-ping, LIU Jie, et al. Simulation of lining void area by radar waves and explanatory strategy[J]. Journal of the China Railway Society, 2008, 30(5): 92-96. (in Chinese)) [8] HUANG C L, SU Y. A new GPR calibration method for high accuracy thickness and permittivity measurement of multi-layered pavement[C]// Proceedings of the Tenth International Conference on Ground Penetrating Radar. Delft, IEEE, 2004: 627-630 [9] WIDESS M B. How thin is a thin bed[J]. Geophysics, 1973, 38(6): 1176-1180. [10] 张蓓. 路面结构层材料介电特性及其厚度反演分析的系统识别方法：路面雷达关键技术研究[D]. 重庆: 重庆大学, 2003. (ZHANG Bei. System identification method for conversion analysis of dielectric characteristics and thickness of pavement structure: research of the key techniques of pavement radar[D]. Chongqing: Chongqing University, 2003. (in Chinese)) [11] PURYEAR C I, CASTAGNA J P. Layer-thickness determination and stratigraphic interpretation using spectral inversion: Theory and application[J]. Geophysics, 2008, 73(2): 37-48. [12] 黄忠来, 张建中. 利用探地雷达频谱反演层状介质几何与电性参数[J]. 地球物理学报, 2013, 54(4): 1381-1391. (HUANG Zhong-lai, ZHANG Jian-zhong. An inversion method for geometric and electric parameters of layered media using spectrum of GPR signal[J]. Chinese Journal of Geophysics, 2013, 54(4): 1381-1391. (in Chinese)) [13] 秦瑶, 陈洁, 方广有. 频谱拟合法提高探地雷达垂直分辨率[J]. 仪器仪表学报, 2010, 31(7): 1148-1453. (QIN Yao, CHEN Jie, FANG Guang-you. Spectrum fitting method for improving the vertical resolution of ground penetrating radar[J]. Chinese Journal of Scientific Instrument, 2010, 31(7): 1148-1453. (in Chinese)) [14] JOL H M. Ground penetrating radar: theory and applications[M]. Amsterdam: Elsevier Science 2009. [15] WENG CH CH. Waves and fields in inhomogeneous media[M]. New York: Wiley-IEEE Press, 1990: 37-65. [16] 柴新涛, 韩文功, 李振春, 等. 基于LSQR算法的谱反演方法研究[J]. 石油物探, 2012, 51(1): 11-18. (CHAI Xin-tao, HAN Wen-gong, LI Zheng-chun, et al. Spectrum inversion method analysis based on the LSQR algorithm[J]. Geophysical Prospecting for Petroleum, 2012, 51(1): 11-18. (in Chinese)) [17] LOIZOS A, PLATI C. Accuracy of pavement thicknesses estimation using different ground penetrating radar analysis approaches[J]. NDT&E International, 2007, 40: 147-157. -
