二层水平介质球面波正反演联用与震源定位

张向东, 王帅, 贾宝新

张向东, 王帅, 贾宝新. 二层水平介质球面波正反演联用与震源定位[J]. 岩土工程学报, 2015, 37(2): 225-234. DOI: 10.11779/CJGE201502003
引用本文: 张向东, 王帅, 贾宝新. 二层水平介质球面波正反演联用与震源定位[J]. 岩土工程学报, 2015, 37(2): 225-234. DOI: 10.11779/CJGE201502003
shu
ZHANG Xiang-dong, WANG Shuai, JIA Bao-xin. Positioning of seismic sources combined with forward and inversion of spherical wave in double-layer horizontal media[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(2): 225-234. DOI: 10.11779/CJGE201502003
Citation: ZHANG Xiang-dong, WANG Shuai, JIA Bao-xin. Positioning of seismic sources combined with forward and inversion of spherical wave in double-layer horizontal media[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(2): 225-234. DOI: 10.11779/CJGE201502003
shu

二层水平介质球面波正反演联用与震源定位  English Version

  • 辽宁工程技术大学土木与交通学院,辽宁 阜新 123000

基金项目: 国家自然科学基金委员会-神华集团有限公司煤炭联合基金项目（51174268）; 辽宁省自然科学基金项目（201202095）
详细信息
    作者简介:

    张向东(1962- ),男,教授,博士生导师,主要从事岩土工程等方面的教学和科研。E-mail: jwd101@126.com。

  • 中图分类号: TU47

Positioning of seismic sources combined with forward and inversion of spherical wave in double-layer horizontal media

  • College of Civil Engineering and Transportation, Liaoning Technical University, Fuxin 123000, China

摘要

    摘要
  • 摘要: 二层水平介质中原几何平均震源定位方法,无法直接确定震源的水平坐标,推广至任意水平层状介质时,包含震源深度的定位参数难以确定和修正,且难以确定震源所在层。根据将水平和铅垂坐标分离、并去根号的走时方程,反演出发震时刻,并合理修正,根据水平层状体系中球面波波阵面的正演方法,得到含震源空间坐标的非线性方程组,求解可得震源的水平和铅垂坐标。各种定位条件下的定位计算表明,正反演联合运用法的水平和铅垂坐标误差的较大值,均不大于几何平均法的震源深度计算误差,且正反演联用法比几何平均法更适合于深震源定位。对参数敏感性的分析表明,发震时刻对定位参数不敏感,震源位置误差对波速、波速比的敏感性介于几何平均法和经典线性法之间。正反演联用法不能改进几何平均法不适应较大水平竖直距离比和较大、较小埋深比的缺点,仍建议在地(矿)震易发区布置台站,并与经典线性法结合使用。正反演联用法不需要确定和修正含震源深度的定位参数,且便于逐层排除和确定震源所在层,因此将比几何平均法更适合于任意水平层状介质中的震源定位。
    Abstract: The positioning method of geometric average in double-layer horizontal media is unable to determine the horizontal coordinates of seismic sources directly. When it is extended to multilayer medium, the positioning parameters containing depth are difficult to be determined and corrected, and it is difficult to determine the layer where the sources are located. Using the travel time equation by which the depth and horizontal coordinates are separated and the square root is removed, the time when the earthquake happens is obtained through inversion and corrected reasonably. According to the forward modeling method for wave front of spherical wave in double-layer horizontal media, nonlinear equations containing space coordinates of the sources are got, and the depth and horizontal coordinates are yielded by solving the nonlinear equations. The calculated results of positioning under a variety of conditions show that the larger values of positioning error of depth and horizontal coordinates derived by the positioning model combined with forward and inversion are all not greater than those by the geometric average method, and the new positioning method is more suitable than the geometric average method for positioning of deep seismic sources. The sensitivity analysis of parameters shows that the origin time of earthquakes is not sensitive to the positioning parameters, and the sensitivity of the focal position error to wave velocity and wave velocity ratio is between the geometric average method and classical linear method. But the proposed model cannot improve the defect of the geometric average method. When the ratio of horizontal to vertical distance between stations and sources is large, the positioning accuracy is poor. There is also no advantages when the ratio of distances from the interface of sources and stations is too large or too small. So stations in the area where earthquakes are easily prone to happen are suggested to be arranged and the classic linear positioning methods are employed. There is no need to determine or correct the positioning parameters containing depth for the positioning model combined with forward and inversion. It is easy to eliminate or identify which layer the seismic sources are located in. Accordingly, the proposed model is more suitable than the geometric average method for positioning of seismic sources in multilayer horizontal media.
    • HTML全文
    • 参考文献(15)
  • [1] 朱权洁, 姜福兴, 尹永明, 等. 基于小波分形特征与模式识别的矿山微震波形识别研究[J]. 岩土工程学报, 2012, 34(11): 2036-2042. (ZHU Quan-jie, JIANG Fu-xing, YIN Yong-ming, et al. Classification of mine microseismic events based on wavelet-fractal method and pattern recognition[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(11): 2036-2042. (in Chinese))
    [2] 彭府华, 李庶林, 程建勇, 等. 中尺度复杂岩体应力波传播特性的微震试验研究[J]. 岩土工程学报, 2014, 36(2): 312-319. (PENG Fu-hua, LI Shu-lin, CHENG Jian-yong, et al. Experimental study on characteristics of stress wave propagation in the mesoscale and complex rock mass by microseismic monitoring[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(2): 312-319. (in Chinese))
    [3] 潘一山, 赵扬锋, 官福海, 等. 矿震监测定位系统的研究及应用[J]. 岩石力学与工程学报, 2007, 26(5): 1002-1011. (PAN Yi-shan, ZHAO Yang-feng, GUAN Fu-hai, et al. Study on rockburst monitoring and orientation system and its application[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(5): 1002-1011. (in Chinese))
    [4] 林峰, 李庶林, 薛云亮, 等. 基于不同初值的微震源定位方法[J]. 岩石力学与工程学报, 2010, 29(5): 996-1002. (LIN Feng, LI Shu-lin, XUE Yun-liang, et al. Microseismic sources location methods based on different initial values[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(5): 996-1002. (in Chinese))
    [5] 张伯军. 弹性动力学简明教程[M]. 2版. 北京: 科学出版社, 2011: 170-174. (ZHANG Bo-jun. A concise course of elastic dynamics[M]. 2nd ed. Beijing: Science Press, 2011: 170-174. (in Chinese))
    [6] 张向东, 王帅, 赵彪, 等. 二层水平介质中震源的精确定位[J]. 岩土工程学报, 2014, 36(6): 1044-1050. (ZHANG Xiang-dong, WANG Shuai, ZHAO Biao, et al. Precise positioning in double-layer horizontal media[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(6): 1044-1050. (in Chinese))
    [7] 黄琼, 陈洁, 孟升卫, 等. 一种快速超宽带穿墙雷达成像算法[J]. 电子与信息学报, 2009, 31(8): 2001-2005. (HUANG Qiong, CHEN Jie, MENG Sheng-wei, et al. A fast imaging algorithm for UWB Through-Wall radar[J]. Journal of Electronics & Information Technology, 2009, 31(8): 2001-2005. (in Chinese))
    [8] 金添, 周智敏, 常文革. 基于两层均匀媒质的GPEN SAR地下目标成像方法及其性能分析[J]. 信号处理, 2006, 22(2): 238-243. (JIN Tian, ZHOU Zhi-min, CHANG Wen-ge. GPEN SAR underground targets imaging formation in two-layer homogeneous media environment and its performance analysis[J]. Signal Processing, 2006, 22(2): 238-243. (in Chinese))
    [9] 赵近芳.大学物理学(上)[M]. 2版. 北京 : 北京邮电大学出版社, 2006: 183-184. (ZHAO Jin-fang. University physics(Vol 1)[M]. 2nd ed. Beijing: Beijing University of Posts and Telecommunications Press, 2006: 183-184. (in Chinese))
    [10] 张明新, 王光力, 吴仁彪. 探地雷达成像中多层介质分界面折射点确定[J]. 中国民航学院学报, 2002, 20(6): 20-24. (ZHANG Ming-xin, WANG Guang-li, WU Ren-biao. Determination of refraction points between the interfaces of multiple media in GPR[J]. Journal of Civil Aviation University of China, 2002, 20(6): 20-24. (in Chinese))
    [11] 田玥, 陈晓非. 水平层状介质中的快速两点间射线追踪方法[J]. 地震学报, 2005, 27(2): 147-154. (TIAN Yue, CHEN Xiao-fei. A rapid and accurate two-point ray tracing method in horizontally layered velocity model[J]. ACTA Seismologica Sinica, 2005, 27(2): 147-154. (in Chinese))
    [12] 韩志勇, 陈佳. 一种有效确定多层介质分界面折射点位置的方法[J]. 河北师范大学学报(自然科学版), 2010, 34(1): 50-53, 56. (HAN Zhi-yong, CHEN Jia. An efficient method of refraction points determination between the interfaces of Multi-media[J]. Journal of Hebei Normal University (Natural Science Edition), 2010, 34(1): 50-53, 56. (in Chinese))
    [13] 贾宝新, 李国臻. 矿山地震监测台站的空间分布研究与应用[J]. 煤炭学报, 2010, 35(12): 2045-2048. (JIA Bao-xin, LI Guo-zhen. The research and application for spatial distribution of mines seismic monitoring stations[J]. Journal of China Coal Society, 2010, 35(12): 2045-2048. (in Chinese))
    [14] 潘一山, 贾宝新, 王帅, 等. 矿震震波传播规律的三维模型及其应用[J]. 煤炭学报, 2012, 37(11): 1810-1814. (PAN Yi-shan, JIA Bao-xin, WANG Shuai, et al. Three-dimension of model and its application mines seismic wave propagation[J]. Journal of China Coal Society, 2012, 37(11): 1810-1814. (in Chinese))
    [15] 贾宝新, 赵培, 姜明, 等. 非均介质条件下矿震震波三维传播模型构建及其应用[J]. 煤炭学报, 2014, 39(2): 364-370. (JIA Bao-xin, ZHAO Pei, JIANG Ming, et al. Three-dimensional propagation model building in heterogeneous medium of mine earthquake shock wave and its application[J]. Journal of China Coal Society, 2014, 39(2): 364-370. (in Chinese))
