Numerical analysis of 200000-tonnage sheet-pile wharf with relieving platform
-
摘要: 京唐港#36泊位为20万吨级通用散货泊位,采用卸荷式板桩码头结构型式,这是世界上迄今为止设计最大的板桩码头。对于卸荷式深水板桩结构,原有的规范已不再适用,给结构设计带来了一定的困难。基于ABAQUS有限元平台,利用开发的土和结构相互作用软件,对该20万吨级板桩码头初步设计方案进行了三维数值模拟,研究了卸荷式板桩结构的卸荷机理和土与结构的相互作用规律,得到了码头结构的内力和变形等关键设计参数,揭示了码头前墙上的土压力随墙体变形的变化规律,为结构的设计和优化提供了技术支撑。Abstract: No. 36 Berth of Jingtang Port, a 200000-tonnage general bulk cargo berth, adopts the structure of sheet-pile wharf with relieving platform. It is currently the largest sheet-pile wharf in the world. For the deep-water sheet-pile structure with relieving platform, the existing design codes and specifications are not practical, leading to difficulties in structural design and optimization to a certain extent. The design schemes for the 200000-tonnage sheet-pile wharf are numerically simulated by means of the compiled program for the soil-structure interaction based on the finite element software ABAQUS. The relieving mechanism of the sheet-pile structure and the rules of soil-structure interaction are studied. The key design parameters of the sheet-pile structure such as internal force and deformation are yielded. The variation of the earth pressure on the front pile wall with the deformation of the wall is revealed so as to provide technical support for the structural design and optimization of the sheet-pile wharf.
-
Keywords:
- relieving platform /
- numerical simulation /
- sheet-pile wharf /
- earth pressure /
- interaction
-
[1] 刘永绣, 吴荔丹, 徐光明, 等. 遮帘式板桩码头工作机制[J]. 水利水运工程学报, 2006(2): 8-12. (LIU Yong-xiu, WU Li-dan, XU Guang-ming, et al. Working mechanism of sheet pile wharf with barrier piles[J]. Hydro-Science and Engineering, 2006(2): 8-12. (in Chinese)) [2] 刘永绣. 板桩和地下墙码头的设计理论和方法[M]. 北京: 人民交通出版社, 2006. (LIU Yong-xiu. Design theories and methods for wharfs with sheet piles and diaphragms[M]. Beijing: China Communications Press, 2006. (in Chinese)) [3] 李景林, 王剑平, 蔡正银, 等. 遮帘桩方案改造板桩码头离心模型试验研究[J]. 岩土工程学报, 2006, 28(8): 978-982. (LI Jing-lin, WANG Jian-ping, CAI Zheng-yin, et. al. Centrifuge model tests on sheet-piled wharf renovated by barrier pile project[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(8): 978-982. (in Chinese)) [4] 刘延致. 卸荷式板桩码头结构受力分析及优化研究[D]. 青岛: 中国海洋大学, 2012. (LIU Yan-zhi. Force analysis and optimization of sheet-pile wharfs with relieving platform[D]. Qingdao: Ocean University of China, 2012. (in Chinese)) [5] 龚丽飞. 卸荷式地下连续墙板桩码头结构与土相互作用研究[D]. 南京: 南京水利科学研究院, 2007. (GONG Li-fei. Researches on structure-soil of sheet-pile wharfs with relieving platform and diaphragm wall[D]. Nanjing: Nanjing Hydraulic Research Institure, 2009. (in Chinese)) [6] 司海宝, 蔡正银, 俞缙. 遮帘式板桩码头结构与土共同作用3D数值模拟分析[J]. 土木工程学报, 2012, 45(5): 182-190. (SI Hai-bao, CAI Zheng-yin, YU Jin. 3D Numerical modeling of pile-soil interaction for covered sheet-piled wharf[J]. China Civil Engineering Journal, 2012, 45(5): 182-190. (in Chinese))
