矿震P波到时拾取优化与降低震源定位误差应用研究

胡静云; 李庶林

doi:10.11779/CJGE201410023

矿震P波到时拾取优化与降低震源定位误差应用研究 English Version

胡静云¹,
李庶林^2,

1. 长沙矿山研究院有限责任公司国家金属采矿工程技术研究中心,湖南长沙 410012;#br#2. 厦门大学建筑与土木工程学院,福建厦门 361005

基金项目: 国家科技部科研院所技术开发研究专项资金项目（2013EG215024）; 国家科技支撑计划课题（2013BAB02B06）

详细信息

作者简介:
胡静云(1985-),男,工程师,硕士,主要从事岩石力学声发射与微震监测等方面的研究。E-mail: hujingyun007@163.com。

计量
- 文章访问数: 329
- HTML全文浏览量: 5
- PDF下载量: 360
出版历程
- 收稿日期: 2013-12-01
- 发布日期: 2014-10-19

Optimization of picking mine microseismic P-wave arrival time and its application in reducing error of source locating

HU Jing-yun¹,
LI Shu-lin^2,

1. Changsha Institute of Mining Research, Changsha 410012, China;#br#2. School of Architectural and Civil Engineering, Xiamen University, Xiamen 361005, China

摘要

摘要: 多通道微震监测系统采用的定位算法一般是基于P波到时与等速度模型,P波到时拾取的准确与否直接影响着定位精度的高低。然而由于地震波传播衰减与应用环境背景噪声的原因,参与定位的一些通道信噪比偏低,P波到时拾取的随意性较大,导致震源定位结果与实际震源位置相差较大,影响了在矿山的实际应用效果。简要介绍了震源定位方法并开发应用了基于小波理论的离散信号滤噪程序,通过对原始信号进行小波分解、给定阀值与重构处理后,提高了原始信号的信噪比,显著地提高了P波到时拾取准确度。结合某矿山特大采空区采场冒顶实例,应用基于小波理论的信号滤噪方法对信噪比偏低的通道进行了滤噪处理,重新优化拾取了P波到时。所得到的定位结果,与处理前相比,定位误差从47~94 m减小到14~23 m,大大提高了微震监测在矿山的实际应用效果。方法1的P波到时/ms 方法2的P波到时#br#/ms 方法1 方法2
- 矿震 /
- 微震监测 /
- P波到时 /
- 小波滤噪 /
- 定位误差
Abstract: The locating algorithm of multi-channel microseismic monitoring system is generally based on the P-wave arrival time and equal velocity model. The P-wave arrival time directly influences the precision of positioning. However, due to the attenuation of earthquake wave propagation and background noise, some channels are involved in positioning with low SNR, and random picking of P-wave arrival time may lead to great positioning error and affect the actual application effect in mines. The source location method and application of the noise signal filtering procedure based on wavelet theory are introduced. According to the wavelet decomposition, given threshold and reconstruction of signal, the SNR of the original signals is enhanced, and the picking accuracy of the P-wave arrival time is significantly improved. Taking some roof collapse examples in a mine with outsize goaf, re-optimization of picking the P-wave arrivals time in low SNR channels improves the precision of positioning results from 47 ~ 94 m to 14 ~ 23 m, and the actual application effect in mines is greatly improved.
- mine microseism /
- microseismic monitoring /
- P-wave arrival time /
- wavelet de-noising /
- locating error

HTML全文

参考文献(19)

[1]	李庶林, 尹贤刚, 郑文达, 等. 凡口铅锌矿多通道微震监测系统及其应用研究[J]. 岩石力学与工程学报, 2005, 24(12): 2048-2053. (LI Shu-lin, YIN Xian-gang, ZHENG Wen-da, et al. Research of multi-channel microseismic monitoring system and its application to fankou lead-zinc mine[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24(12): 2048-2053. (in Chinese))
[2]	姜福兴, XUN Luo. 微震监测技术在矿井岩层破裂监测中的应用[J]. 岩土工程学报, 2002, 24(2): 147-149. (JIANG Fu-xing, XUN Luo. Application of microseismic monitoring technology of strata fracturing in underground coal mine[J]. Chinese Journal of Geotechnical Engineering, 2002, 24(2): 147-149. (in Chinese))
[3]	EARLE P, SHEARER P M. Characterization of global seismograms using an automatic-picking algorithm[J]. The Bulletin of the Seismological Society of America, 1994, 84(2): 366-376.
[4]	AKI H, HIROAKI Y. Automatic picking of seismic arrivals in strong motion data using an artificial neural network[J]. Environmental Science and Technology, 2003, 17(5): 201-213.
[5]	COLAK O H, DESTICI T C, OZEN S, CEREZCI O, ARY N. P phase and s phase detection using the daubechies wavelet transform(dwt) to minimize the noise at three component seismograms displacement records[C]// 13th European Signal Processing Conference. Paris, 2005.
[6]	SLEEMAN R, VANECK T. Robust automatic p-phase picking: an online implementation in the analysis of broadband seismogram recording[J]. Physics of the Earth and Planetary Interiors, 1999, 113(1/2/3/4): 265-275.
[7]	HAFEZ G, KHAN A, KOHDA T. Clear p-wave arrival of weak events and automatic onset determination using wavelet filter banks[J]. Digital Signal Processing, 2010, 20(3): 715-723.
[8]	HAFEZ ALI G, MOSTAFA RABIE, KOHDA T. Seismic noise study for accurate P-wave arrival detection via MODWT[J]. Computers & Geosciences, 2013, 54(2): 148-159.
[9]	刘希强, 周彦文, 曲均浩, 等. 应用单台垂向记录进行区域地震事件实时检测和直达P波初动自动识别[J]. 地震学报, 2009, 31(3): 260-271. (LIU Xi-qiang, ZHOU Yan-wen, QU Jun-hao, et al. Real-time detection of regional events and automatic P-phase identification from the vertical component of a single station record[J]. Acta Seismologica Sinica, 2009, 31(3): 260-271. (in Chinese))
[10]	陈飞, 赵永, 刘阳, 等. 多尺度分析在地震信号处理中的应用[J]. 中国地震, 2004, 20(4): 405-409. (CHEN Fei, ZHAO Yong, LIU Yang, et al. Application of wavelet on seismic signal processing[J]. Earthquake Research in China, 2004, 20(4): 405-409. (in Chinese))
[11]	徐宏斌, 李庶林, 陈际经. 基于小波变换的大尺度岩体结构微震监测信号去噪方法研究[J]. 地震学报, 2012, 34(1): 85-96. (XU Hong-bin, LI Shu-lin, CHEN Ji-jing. A study on method of signal denoising based on wavelet transform for micro-seismicity monitoring in large-scale rockmass structures[J]. Acta Seismologica Sinica, 2012, 34(1): 85-96. (in Chinese))
[12]	刘代志, 王仁明, 李夕海, 等. 基于小波包分解及AR模型的单通道地震波信号初至点检测[J]. 地球物理学报, 2005, 48(5): 1098-1102. (LIU Dai-zhi, WANG Ren-ming, LI Xi-hai, et al. Onset point identification of single-channel seismic signal based on wavelet packet and the AR model[J]. Chinese Journal of Geophysics, 2005, 48(5): 1098-1102. (in Chinese))
[13]	吴招才, 刘天佑. 地震数据去噪中的小波方法[J]. 地球物理学进展, 2008, 23(2): 493-499. (WU Zhao-cai, LIU Tian-you. Wavelet transform methods in seismic data noise attenuation[J]. Progress in Geophysics, 2008, 23(2): 493-499. (in Chinese))
[14]	金解放, 赵奎, 王晓军, 等. 岩石声发射信号处理小波基选择的研究[J]. 矿业研究与开发, 2007, 27(2): 12-15. (JIN Jie-fang, ZHAO Kui, WANG Xiao-jun, et al. Study on selection of wavelet basis for processing of rock acoustic emission signal[J]. Mining R & D, 2007, 27(2): 12-15. (in Chinese))
[15]	林峰, 李庶林, 薛云亮, 等. 基于不同初值的微震源定位方法[J]. 岩石力学与工程学报, 2010, 29(5): 996-1002. (LIN Feng, LI Shu-lin, XUE Yun-lian, et al. Microseismic sources location methods based on different initial values[J]. Chinese Journal of Rock Mechanics and Engineering, 2010, 29(5): 996-1002. (in Chinese))
[16]	中国生, 徐国元, 赵建平. 基于小波变换的爆破地震信号阀值去噪的应用研究[J]. 岩土工程学报, 2005, 27(9): 1055-1059. (ZHONG Guo-sheng, XU Guo-yuan, ZHAO Jian-ping. Study and application of threshold de-noising in seismic signals of blasting based on wavelet transform[J]. Chinese Journal of Geotechnical Engineering, 2005, 27(9): 1055-1059. (in Chinese))
[17]	金鑫, 沈珠江, 刘崇茹. MATLAB在土工试验数据处理中的应用[J]. 岩土工程学报, 2004, 26(2): 272-275. (JIN Xin, SHEN Zhu-jiang, LIU Chong-ru. Data processing of geotechnical experiment using MATLAB[J]. Chinese Journal of Geotechnical Engineering, 2004, 26(2): 272-275. (in Chinese))
[18]	胡静云, 林峰, 彭府华, 等. 香炉山钨矿残采区地压灾害微震监测技术应用分析[J]. 中国地质灾害与防治学报, 2010, 21(4): 109-115. (HU Jing-yun, LIN Feng, PENG Fu-hua, et al. Research on application of microseismic monitoring technology on ground pressure hazard of residual are in xianglushan tungsten mine[J]. The Chinese Journal of Geological Hazard and Control, 2010, 21(4): 109-115. (in Chinese))
[19]	程超, 兰晓平, 吴水生, 等. 香炉山钨矿特大采空区地压微震监测技术应用研究[J]. 中国钨业, 2011, 26(5): 10-13. (CHENG Chao, LAN Xiao-ping, WU Shui-sheng, et al. On the microsesmic monitoring technology on the ground pressure in the large gob[J]. China Tungsten Industry, 2011, 26(5): 10-13. (in Chinese))
