一种广义节理元模型

韦立德; 韦昌富

doi:10.11779/CJGE201410022

一种广义节理元模型 English Version

韦立德^{1, 2},
韦昌富^{1, 2}

1. 中国科学院武汉岩土力学研究所,湖北武汉 430071;
2. 岩土力学与工程国家重点实验室,湖北武汉 430071

基金项目: 国家自然科学基金项目（51074152）

详细信息

作者简介:
韦立德(1974- ),男,博士（后）,副研究员,主要从事岩土力学与工程方面科研工作。E-mail: ldwei@whrsm.ac.cn。

计量
- 文章访问数: 295
- HTML全文浏览量: 0
- PDF下载量: 310
出版历程
- 收稿日期: 2014-02-20
- 发布日期: 2014-10-19

A generalized joint element method

WEI Li-de^{1, 2},
WEI Chang-fu^{1, 2}

1. Institute of Rock and Soil Mechanics, The Chinese Academy of Sciences, Wuhan 430071, China;
2. State Key Laboratory of Geomechanics and Geotechnical Engineering, Wuhan 430071, China

摘要

摘要: 采用传统节理元近似模拟岩石破坏过程需要同时增加单元和节点,过程非常复杂。为了更有效模拟岩石岩石破坏过程产生的节理,建议了一种只包含2个节点的广义节理元的模拟方法,通过推导给出了基本方程,提供了单元信息设置方式。采用该广义节理元近似模拟岩石破坏过程只需要增加单元,不需要增加节点。模拟实例表明：采用广义节理元法模拟效果在应力方面精度和传统节理元法的精度一样,该广义节理元法有效可行。
- 岩石力学 /
- 有限元 /
- 广义节理元
Abstract: When the traditional joint element methods are used to simulate the failure process of rock, it is necessary to increase the elements and the nodes, and the data processing is extremely complex. In order to more efficiently simulate the interaction between nodes in the finite element in fractured rock, a new simulating method is proposed. A simple interface element including two nodes, called the generalized joint element here, is suggested. Its fundamental equations are deduced, and its element organization method is offered. Using the generalized joint elements to simulate the joint in rock, it is necessary to increase the elements compared to the finite element mesh, and not necessary to change or increase the nodes. Numerical experiments of simulation of a rock joint indicate that the generalized joint element method is effective, and the accuracy of stress with the generalized joint elements is equal to that with the traditional ones.
- rock mechanics /
- finite element /
- generalized joint element

HTML全文

参考文献(9)

[1]	潘鹏志, 冯夏庭, 周辉. 脆性岩石破裂演化过程的三维细胞自动机模拟[J]. 岩土力学, 2009, 30(5): 1471-1476. (PAN Peng-zhi, FENG Xia-ting, ZHOU Hui. Failure evolution processes of brittle rocks using 3D cellular automaton method[J]. Chinese Journal of Rock and Soil Mechanics, 2009, 30(5): 1471-1476. (in Chinese))
[2]	张楚汉. 论岩石、混凝土离散-接触-断裂分析[J]. 岩石力学与工程学报, 2008, 27(2): 217-235. (ZHANG Chu-han. Discrete-contact-fracture analysis of rock and concrete[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(2): 217-235. (in Chinese))
[3]	JING L. A review of techniques, advances and outstanding issues in numerical modelling for rock mechanics and rock engineering[J]. International Journal of Rock Mechanics & Mining Sciences, 2003, 40(3): 283-353.
[4]	GOODMAN R E, TAYLOR R L, BREKKE T L. A model for the mechanics of jointed rock[J]. Journal of Soil Mechanics & Foundations Div, 1968(5): 637-659.
[5]	BEER G. An isoparametric joint/interface element for finite element analysis[J]. International Journal for Numerical Methods in Engineering, 1985, 21: 585-600.
[6]	雷晓燕, SWOBODA G, 杜庆华. 接触摩擦单元的理论及应用[J]. 岩土工程学报, 1994, 16(3): 23-32. (LEI Xiao-yan, SWOBODA G, DU Qing-hua. Theory and application of contact-friction interface element[J]. Chinese Journal of Geotechnical Engineering, 1994, 16(3): 23-32. (in Chinese))
[7]	邱峰, 丁桦. 模拟岩石材料破坏的有限元方法[J]. 岩石力学与工程学报, 2007, 26(增刊1): 26633-2668. (QIU Feng, DING Hua. Finite element method simulating failure of rock material[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26(S1): 2663-2668. (in Chinese))
[8]	CHARALAMBIDES P G, MCMEEKING R M. Finite element method simulation of crack propagation in a brittle microcracking solid[J]. Mechanics of Materials, 1987, 6(1): 71-87.
[9]	ZHANG Xiu-li, JIAO Yu-yong, ZHAO Jian. Simulation of failure process of jointed rock[J]. Journal of Center South University of Technologe, 2008, 15(6): 888-894.
