考虑土抗力方向的<em>p-y</em>曲线法研究

上官士青; 刘红军; 朴春德

doi:10.11779/CJGE201408020

考虑土抗力方向的p-y曲线法研究 English Version

1. 同济大学土木工程学院,上海 200092; 2. 中国海洋大学环境科学与工程学院,山东青岛 266100; 3. 中国矿业大学资源与地球科学学院,江苏徐州 221116

基金项目: 国家自然科学基金项目（41072216）; 博士点基金项目（20100132110001）

详细信息

作者简介:
上官士青（1989- ）,男,博士研究生,主要从事桩基础研究。E-mail: shangguansq@gmail.com。

中图分类号: TU43
计量
- 文章访问数: 0293
- HTML全文浏览量: 0
- PDF下载量: 0347
出版历程
- 收稿日期: 2013-10-20
- 发布日期: 2014-08-18

A modified p-y curve method considering rotation of soil resistance

1. Collage of Civil Engineering, Tongji University, Shanghai 200092, China; 2. Institute of Environmental Science and Engineering, Ocean University of China, Qingdao 266100, China; 3. The School of Resource and Earth Science, China University of Mining and Technology, Xuzhou 221116, China

摘要

摘要: 当桩顶受到不在同一平面内的水平力—弯矩组合荷载时,桩身变形复杂,多采用三维有限元法进行分析,不方便实用。为此,文章提出了一种三维情况下土抗力弹簧可在水平面内旋转的p-y曲线法,并建立了相应的数学规划模型进行求解。根据最小势能原理,以广义势能方程为目标函数,将p-y曲线积分计算土弹簧做功,同时以桩身变形协调条件作为数学模型的约束条件,构成了一个非线性规划模型。模型假设桩身每个节点5自由度,并考虑了p-效应。通过3个算例对该数学规划模型进行了验证,结果表明该模型整体假设条件合理,方法可行。文章同时对桩身双向不均匀弯曲下的土弹簧在水平面内旋转的情况进行分析,认为模型可有效反映出桩身在三维空间内的位移和力的协调。
- 曲线法 /
- 水平荷载 /
- 土抗力方向 /
- 数学规划
Abstract: The combined load of moments and horizontal forces which are not coplanar at pile top generally cause a complex pile deformation. Under this circumstance, analysis is often performed by using the three-dimensional finite element method, which is not convenient and practical. To simplify the procedure, a modified p-y curve method is proposed in 3D space under the assumption that soil resistance springs can be rotated on the horizontal plane. A corresponding mathematical programming (optimization) model is established for solving this method. Based on the principle of the minimum potential energy, the generalized potential energy equation is selected as the objective function in which the soil spring acting work is represented by the integrated p-y curve functions, and the pile deformation compatibility conditions are selected as constraints, forming a nonlinear programming model. This model assumes five DOFs (degrees of freedom) per node, and the p- effect is considered. The mathematical programming model is validated through three examples. The results show that the assumptions in the proposed method are reasonable, and the model is feasible. Analysis of the soil resistance rotation on the horizontal plane is carried out under bi-directional unevenness bending, and the coordination of displacement and force is presented effectively in the proposed model.
- curve method /
- horizontal load /
- /
- direction of soil resistance

HTML全文

参考文献(16)

[1]	JB/T10300—2001 风力发电机组设计要求[S]. 2001. (JB/T10300—2001 Wind turbine generator system design requirements[S]. 2001. (in Chinese))
[2]	张问清, 赵锡宏, 宰金珉. 任意力系作用下的层状弹性半空间的有限层分析方法[J]. 岩土工程学报, 1981, 3(2): 27-42. (ZHANG Wen-qing, ZHAO Xi-hong, ZAI Jin-min. Finite layer analysis for layered and elastic half-space under arbitrary force system[J]. Chinese Journal of Geotechnical Engineering, 1981, 3(2): 27-42. (in Chinese))
[3]	何广民, 张崇文, 王甡. 三维有限层—有限元混合法对桩-土-承台相互作用的弹塑性分析[C]//第二届全国结构工程学术会议论文集 (下). 1993: 795-802. (HE Guang-min, ZHANG Chong-wen, WANG Shen. Elastic-plastic analysis of pile-soil-cap interaction with a three dimensional finite layer-finite element mixed method[C]// Proceedings of the Second National Structural Engineering Conference (VolumeⅡ). Chaingsha, 1993: 795-802. (in Chinese))
[4]	赵明华. 倾斜荷载下基桩的受力研究[D]. 长沙: 湖南大学土木工程学院, 2001. (ZHAO Ming-hua. Study on the behavior of piles under inclined loads[D]. Changsha: Hunan University, 2001. (in Chinese))
[5]	KLAR A, FRYDMAN S. Three-dimensional analysis of lateral pile response using two-dimensional explicit numerical scheme[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2002, 128(9): 775-784.
[6]	MATLOCK H S. Correlations for design of laterally loaded piles in soft clay[C]// Proceedings of 2nd Offshore Technology Conference. Houston, 1970: 577-594.
[7]	REESE L C, COX W R, KOOP F D. Field testing and analysis of laterally loaded piles in stiff clay[C]// Proceedings of 7th Offshore Technology Conference. Houston, 1975: 671-690.
[8]	JTS 167-4-2012 港口工程桩基规范[S]. 2012. (JTS 167-4-2012 Code for pile foundation of Harbor Engineering[S]. 2012. (in Chinese))
[9]	佟成仁, 黄诚始. 海上钢制 (石油) 平台上部结构与非线性桩基联合计算的一种实用解法——桩基等效组合梁处理[J]. 数值计算与计算机应用, 1985, 6(2): 113-124. (TONE Cheng-ren, HUANG Cheng-shi. A practical method for solving interaction between the upper structure and the nonlinear piles of a steel offshore platform[J]. Journal on Numerical Methods and Computer Applications, 1985, 6(2): 113-124. (in Chinese))
[10]	孙容. 考虑空间效应的桩-土-结构共同作用的分析[D]. 杭州: 浙江大学, 2003. (SUN Rong. Analysis of the common work of pile structure considering space effects[D]. Hangzhou: Zhejiang University, 2003. (in Chinese))
[11]	杨璐, 陈德龙, 孔方钧, 等. 防护栏支柱-地基的弹簧模型分析[J]. 岩土工程学报, 2013, 35(增刊1): 430-433. (YANG Lu, CHEN De-long, KONG Fang-jun, et al. Spring model for guardrail post-foundation[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(S1): 430-433. (in Chinese))
[12]	BRINKGREVE R B J, SWOLFS W M. Plaxis 3D foundation version 2 user’s manual[M]. Netherlands: Plaxis BV, 2007.
[13]	王用中, 张河水. 弹性地基梁的压弯计算及其应用[J]. 桥梁建设, 1985, 14(4): 30-52. (WANG Yong-zhong, ZHANG He-shui. The calculation of press bending and application for beam on elastic foundation[J]. Bridge Construction, 1985, 14(4): 30-52. (in Chinese))
[14]	赵明华, 李微哲, 杨明辉, 等. 成层地基中倾斜偏心荷载下单桩计算分析[J]. 岩土力学, 2007, 28(4): 670-674. (ZHAO Ming-hua, LI Wei-zhe, YANG Ming-hui, et al. Analysis of single piles under eccentric and inclined loads in layered soils[J]. Rock and Soil Mechanics, 2007, 28(4): 670-674. (in Chinese))
[15]	LESNY K, WIEMANN J. Finite-element-modeling of large diameter monopiles for offshore wind energy converters[C]// Proceedings of the GeoCongress. Atanta, 2006.
[16]	ITASCA F. Fast Lagrangian analysis of continua in 3-Dimensions, version 3.0, manual[M]. Itasca, Minnesota, 2000.
