复杂地形条件下高面板堆石坝应力变形特性研究

杨杰, 李国英, 沈婷

杨杰, 李国英, 沈婷. 复杂地形条件下高面板堆石坝应力变形特性研究[J]. 岩土工程学报, 2014, 36(4): 775-781. DOI: 10.11779/CJGE201404025
引用本文: 杨杰, 李国英, 沈婷. 复杂地形条件下高面板堆石坝应力变形特性研究[J]. 岩土工程学报, 2014, 36(4): 775-781. DOI: 10.11779/CJGE201404025
YANG Jie, LI Guo-ying, SHEN Ting. Stress-deformation properties of super-high CFRDs under complex terrain conditions[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(4): 775-781. DOI: 10.11779/CJGE201404025
Citation: YANG Jie, LI Guo-ying, SHEN Ting. Stress-deformation properties of super-high CFRDs under complex terrain conditions[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(4): 775-781. DOI: 10.11779/CJGE201404025

复杂地形条件下高面板堆石坝应力变形特性研究  English Version

基金项目: 水文水资源与水利工程科学国家重点实验室基本科研业务费专项资金项目(10Y312011)
详细信息
    作者简介:

    杨 杰(1986- ),男,博士研究生,主要从事岩土工程数值模拟分析研究。E-mail: yuzhou-x@163.com。

  • 中图分类号: TV641;TU431

Stress-deformation properties of super-high CFRDs under complex terrain conditions

  • 摘要: 河谷地形是影响面板堆石坝应力变形的重要因素之一,河谷地形不同导致面板坝边界条件不同,进而影响其应力变形状态。对某拟建坝高256 m的超高混凝土面板堆石坝在复杂地形条件下的应力变形进行分析,得出不对称不规则河谷对面板堆石坝的应力变形协调性影响较大,特别是右岸古河床阶地附近的坝体和面板应力变形梯度变化较大,不利于面板的安全,设计和施工时需采取措施进行处理。并通过与两种调整方案的结果进行对比,针对性的分析了右岸古河床阶地的影响。同时左岸陡岸坡导致面板拉应力和周边缝位移较大,通过与3种调整方案的结果进行对比,分析了陡岸坡的影响程度。
    Abstract: Valley terrain is one of the most important factors which affect the stress and deformation of CFRDs. Different valley terrains lead to different boundary conditions of CFRDs and further influence the state of stress and deformation. 3D-FEM is employed to analyze the stress and deformation of a super-high CFRD 256 m in height under complex topography. It is indicated that the asymmetric and irregular river valley has large influence on the stress and deformation coordination of CFRD, especially the change of stress and deformation gradient is larger near the ancient river terraces at the right bank, which is harmful to the safety of the concrete slab, and thus it is necessary to take measures during design and construction. By comparing the results of two adjustment schemes, the influence of the ancient riverbed on the right bank is analyzed. At the same time, the steep slope at the left bank causes the tensile stress of panel and large displacement of peripheral joints. Based on the results of three adjustment schemes, the influence degree of the steep bank slope is analyzed.
  • [1] 沈婷, 李国英. 超高面板堆石坝混凝土面板应力状态影响因素分析[J]. 岩土工程学报, 2010, 32(9): 1345-1349. (SHEN Ting, LI Guo-ying. Factors for stress behavior of concrete face slab of super-high CFRD[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(9): 1345-1349. (in Chinese))
    [2] 刘恩龙, 陈生水, 李国英, 等. 循环荷载作用下考虑颗粒破碎的堆石体本构模型[J].岩土力学, 2012, 33(7): 1972-1978. (LIU En-long, CHEN Sheng-shui, LI Guo-ying, et al. A constitutive model for rockfill materials incorporating grain crushing under cyclic loading[J]. Rock and Soil Mechanics, 2012, 33(7): 1972-1978. (in Chinese))
    [3] 米占宽, 李国英, 陈生水. 基于破碎能耗的粗颗粒料本构模型[J].岩土工程学报, 2012, 34(10): 1801-1811. (MI Zhan-kuan, LI Guo-ying, CHEN Sheng-shui. Constitutive model for coarse granular materials based on breakage energy[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(10): 1801-1811. (in Chinese))
    [4] 米占宽, 李国英. 堆石料劣化及其对大坝安全运行影响的研究[J]. 岩土工程学报, 2008, 30(11): 1588-1593. (MI Zhan-kuan, LI Guo-ying. Deterioration of rockfill and its effect on safe operation of dams[J]. Chinese Journal of Geotechnical Engineering, 2008, 30(11): 1588-1593. (in Chinese))
    [5] FU Zhong-zhi, LIU Si-hong. Formulations of a hydromecha- nical interface element[J]. Acta Mechanica Sinica, 2011, 27(5): 697-705.
    [6] 朱晟. 水布垭面板堆石坝施工与运行性状反演研究[J]. 岩石力学与工程学报, 2011, 30(增刊2): 3689-3695. (ZHU Sheng. Back analysis on construction and operation properties of Shuibuya concrete face Rockfill DAM[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(S2): 3689-3695. (in Chinese))
    [7] 谢晓华, 李国英. 成屏混凝土面板堆石坝应力变形分析[J].岩土工程学报, 2001, 23(2): 243-246. (XIE Xiao-hua, LI Guo-ying. Stress-deformation analysis of Cheng ping concrete-faced rockfill dam[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(2): 243-246. (in Chinese))
    [8] 李国英. 覆盖层上面板坝的应力变形性状及其影响因素[J].水利水运科学研究, 1997, 4: 348-356. (LI Guo-ying. Stress-strain behavior and its affecting factor of CFRD built on riverbed alluvium[J]. Study on Hydraulic Research, 1997, 4: 348-356. (in Chinese))
    [9] 赵魁芝, 李国英. 梅溪覆盖层上混凝土面板堆石坝流变变形反馈分析及安全性研究[J]. 岩土工程学报, 2007, 29(8): 1230-1235. (ZHAO Kui-zhi, LI Guo-ying. Back analysis of creep deformation and study on safety of Meixi CFRD built on riverbed alluvium[J]. Chinese Journal of Geotechnical Engineering, 2007, 29(8): 1230-1235. (in Chinese))
    [10] 徐泽平, 邵宇, 胡本雄, 等. 狭窄河谷中高面板堆石坝应力变形特性研究[J]. 水利水电技术, 2005, 36(5): 30-33. (XU Ze-ping, SHAO Yu, HU Ben-xiong, et al. Study on stress and deformation properties of high concrete face rock-fill dam in narrow valley[J]. Water Resources and Hydropower Engineering, 2005, 36(5): 30-33. (in Chinese))
    [11] 岑威钧, 任旭华, 李启升. 复杂地形条件下高面板堆石坝的应力变形特性[J]. 河海大学学报(自然科学版), 2007, 35(4): 452-455. (CEN Wei jun, REN Xu-hua, LI Qi-sheng. Stress and deformation analysis of high CFRD under complicated topographic condition[J]. Journal of Hohai University (Natural Sciences), 2007, 35(4): 452-455. (in Chinese))
    [12] 程嵩, 张嘎, 张建民, 等. 河谷地形对面板堆石坝应力位移影响的分析[J]. 水利发电学报, 2008, 27(5): 53-58. (CHENG Song, ZHANG Ga, ZHANG Jian-min, et al. Effect of foundation topography on the stress-displacement response of concrete faced rockfill dam[J]. Journal of Hydroelectric Engineering, 2008, 27(5): 53-58. (in Chinese))
    [13] 朱百里, 沈珠江. 计算土力学[M]. 上海: 上海科技出版社, 1990. (ZHU Bai-li, SHEN Zhu-jiang. Computational soil mechanics[M]. Shanghai: Shanghai Science and Technology Press, 1990. (in Chinese))
    [14] 傅华, 凌华, 韩华强. 新疆库玛拉克河大石峡水电站砼面板砂砾石坝筑坝材料工程特性试验报告[R]. 南京: 南京水利科学研究院, 2011. (FU Hua, LING Hua, HAN Hua-qiang. Report of concrete face sand-gravel dam of dashixia hydroelectric power station on Xinjjiang Kumalak River[R]. Nanjing: Nanjing Hydraulic Research Institute, 2011. (in Chinese))
