膨胀土边坡物理模型试验研究

程展林, 丁金华, 饶锡保, 程永辉, 徐晗

程展林, 丁金华, 饶锡保, 程永辉, 徐晗. 膨胀土边坡物理模型试验研究[J]. 岩土工程学报, 2014, 36(4): 716-723. DOI: 10.11779/CJGE201404016
引用本文: 程展林, 丁金华, 饶锡保, 程永辉, 徐晗. 膨胀土边坡物理模型试验研究[J]. 岩土工程学报, 2014, 36(4): 716-723. DOI: 10.11779/CJGE201404016
shu
CHENG Zhan-lin, DING Jin-hua, RAO Xi-bao, CHENG Yong-hui, XU Han. Physical model tests on expansive soil slopes[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(4): 716-723. DOI: 10.11779/CJGE201404016
Citation: CHENG Zhan-lin, DING Jin-hua, RAO Xi-bao, CHENG Yong-hui, XU Han. Physical model tests on expansive soil slopes[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(4): 716-723. DOI: 10.11779/CJGE201404016
shu

膨胀土边坡物理模型试验研究  English Version

  • 1. 长江科学院水利部岩土力学与工程重点实验室，湖北 武汉 430010；2.浙江大学建筑工程学院，浙江 杭州 310027

详细信息

  • 中图分类号: TU443

Physical model tests on expansive soil slopes

  • 1. Yangtze River Scientific Research Institute, Key Laboratory of Geotechnical Mechanics and Engineering of the Ministry of Water Resources, Wuhan 430010, China; 2. College of Civil Engineering and Architecture, Zhejiang University, Hangzhou 310027, China

Funds: This research is financially supported by the National Key Technology R&D Program in the 11th Five-Year Plan of China（2006BAB0A10）

摘要

    摘要
  • 摘要: 进行了一系列压实膨胀土的大型静力模型试验,对边坡土体吸湿后的含水率、膨胀变形等进行了实时监测。试验成果显示,膨胀土边坡浅层土体吸湿后其含水率场分布不均匀,干湿分界面处土体易由于不均匀膨胀变形而导致局部剪切错动,并随水分在坡体内的迁移,局部滑动面逐渐向边坡纵深扩展,在不同深度、不同部位形成多重剪切滑动面,最终导致边坡整体塌滑。针对静力模型试验进行了考虑膨胀性的非线性有限元计算,比较了边坡自重条件下和吸湿后应力场的变化,可知吸湿引起顺坡向正应力在干湿分界面处变化剧烈,剪应力明显增大,强度折减法得到的模型试验边坡安全系数仅0.92。研究成果表明：影响膨胀土边坡浅层稳定性的最根本原因并非膨胀土的超固结性或裂隙性,而是土的胀缩特性。
    Abstract: A series of large-scale static model tests on a compacted expansive soil slope under artificial rainfall are conducted for real-time monitoring of water content and swelling deformation. The monitoring results show that the distribution of water content in the slope is nonuniform in space and time, which results in the nonuniform distribution of swelling deformation at the drying-wetting interface. According to the survey of failure surface by excavation after landslide, it is observed that local shear ruptures firstly take place at the drying-wetting interface within the shallow layer of slope, and then extend downwards gradually with water infiltration, and multiple shear sliding surfaces are produced at different depths and areas, which connect further with each other and finally lead to an overall landslide. The traditional limit equilibrium method can not correctly simulate the progressive landslide of expansive soil slopes. The finite element method with expansive model is adopted, and the safety factor of the model test slope is calculated to be 0.92 using the strength reduction technique. Both the physical model tests and the finite element analysis prove that the essential influence factor of expansive soil slope stability is the swelling deformation instead of the over-consolidation effect and fissure presence.
    • HTML全文
    • 参考文献(16)
  • [1] SIVAPULLAIAH Puvvadi V, SITHARAM Thallak G, SUBBA RAO Kanakapura S. Modified free swell index for clays[J]. Geotechnical Testing Journal, 1987, 10(2): 80-85.
    [2] GADRE A D, CHANDRASEKARAN V S. Swelling of black cotton soil using centrifuge modeling[J]. Journal of Geotechnical Engineering, 1994, 120: 914-919.
    [3] BASMA Adnan A, AZM S A1-Homoud, Abdallah I Husein Malkawi, et al. Swelling-shrinkage behavior of natural expansive clays[J]. Applied Clay Science, 1996, 11: 211-227.
    [4] LIAO Shi-wen. Expansive soil and railway engineering[M]. Beijing: China Railway Publishing Press, 1984.
    [5] LIU Te-hong. Expansive soil problems in engineering construction[M]. Beijing: China Architecture and Building Press, 1997.
    [6] SHI Bin, JIANG Hong-tao, LIU Zhi-bin, et al. Engineering geological characteristics of expansive soils in China[J]. Engineering Geology, 2002, 67(1): 63-71.
    [7] ZHAN Liang-tong. Field and laboratory study of an unsaturated expansive soil associated with rain-induced slope instability[D]. Hong Kong: Hong Kong University of Science and Technology, 2003.
    [8] ZHAN Liang-tong, NG.W.W Charles, BAO Cheng-gang, GONG Bi-wei. Artificial rainfall infiltration tests on a wel1 Instrumented unsaturated expansive soil slope[J]. Rock and Soil Mechanics, 2003, 24(4): 152-158.
    [9] YIN Hong-Lei, XU Qian-Jun, LI Zhong-Kui. Effect of swelling deformation on stability of expansive soil slope[J]. Rock and Soil Mechanics, 2009, 30(8): 2506-2510.
    [10] YIN Zong-Ze, XU Bin. Slope stability of expansive soil under fissure influence[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(3): 454-459.
    [11] ZHOU Jian, XU Hong-zhong, HU Wen-jie. Impact of wetting-drying cycle effects on stability of expansive soil slopes[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(zk2): 152-156.
    [12] CHENG Zhan-lin, LI Qing-yun, GUO Xi-ling, et al. Study on the stability of expansive soil slope[J]. Journal of Yangtze River Scientific Research Institute, 2011, 28(10): 3-111.
    [13] LI Qing-yun, CHENG Zhan-lin, GONG Bi-wei, et al. Failure mechanism and treatment technology of Expansive Soil Slope of Middle Route Project[J]. Journal of Yangtze River Scientific Research Institute, 2009, 26(11): 1-9.
    [14] CHENG Yong-hui, LI Qing-yun, GONG Bi-wei, et al. Research of centrifuge modeling test on expansive clay slopes treatment effects[J]. Journal of Yangtze River Scientific Research Institute, 2009, 26(11): 42-46, 51.
    [15] CHENG Yong-hui, CHENG Zhan-lin, ZHANG Yuan-bin. Centrifugal model tests on expansive soil slope under rainfall[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(S1): 409-414.
    [16] EINSTEIN H H. Suggested methods for laboratory testing of argillaceous swelling rocks[J]. Intl J of Rock Mech & Mining Sci & Geomechanic Abs, 1989, 26(5): 415-426. (in Chinese)
