桩筏结构复合地基中筏板受力分析的理论计算模型与试验研究

    陈洪运, 马建林, 陈红梅, 许再良, 胡伟明

    陈洪运, 马建林, 陈红梅, 许再良, 胡伟明. 桩筏结构复合地基中筏板受力分析的理论计算模型与试验研究[J]. 岩土工程学报, 2014, 36(4): 646-653. DOI: 10.11779/CJGE201404008
    引用本文: 陈洪运, 马建林, 陈红梅, 许再良, 胡伟明. 桩筏结构复合地基中筏板受力分析的理论计算模型与试验研究[J]. 岩土工程学报, 2014, 36(4): 646-653. DOI: 10.11779/CJGE201404008
    CHEN Hong-yun, MA Jian-lin, CHEN Hong-mei, XU Zai-liang, HU Wei-ming. Theoretical and experimental studies on forces acting on raft of pile-raft composite foundation[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(4): 646-653. DOI: 10.11779/CJGE201404008
    Citation: CHEN Hong-yun, MA Jian-lin, CHEN Hong-mei, XU Zai-liang, HU Wei-ming. Theoretical and experimental studies on forces acting on raft of pile-raft composite foundation[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(4): 646-653. DOI: 10.11779/CJGE201404008

    桩筏结构复合地基中筏板受力分析的理论计算模型与试验研究  English Version

    基金项目: 铁道部京沪高速铁路科技重大专项项目(2008G032-A); 中央高校基金科研业务费专项资金专题研究项目(SWJT11ZT0)
    详细信息
      作者简介:

      陈洪运(1984- ),男,湖北鄂州人,博士研究生,主要从事高速铁路地基加固等方面的研究工作。E-mail: 278709407@qq.com。

      通讯作者:

      马建林

    • 中图分类号: TU47

    Theoretical and experimental studies on forces acting on raft of pile-raft composite foundation

    • 摘要: 由于缺乏刚性桩复合地基之上筏板受力的合理计算公式,目前中国高速铁路桩筏结构复合地基中筏板的设计计算仍采用简化算法,其计算结果的准确合理性尚不满足要求,为此拟对桩筏基础之上的筏板进行理论求解。选取桩筏结构中单桩作用的筏板区域作为求解单元,将该单元结构视为位于单桩和Winkler弹性地基共同支撑的四边滑支Reissner矩形中厚板,将Reissner矩形中厚板的基本方程导入Hamilton体系,利用辛几何中的分离变量及本征函数展开等方法,求出矩形中厚板弯曲问题的解析解,进而可求得复合地基上筏板的内力、挠度、桩顶反力和桩间土压力等设计值。最后将现场试验实测值与理论模型解析解的计算结果进行对比,结果采用文中理论模型计算得到的筏板弯矩、桩顶轴力及桩间土压应力等与现场实测结果吻合较好,表明在桩筏结构复合地基的筏板设计中,提出的理论模型是一种准确可靠的计算方法。
      Abstract: At present, some simplified algorithms are still used in the design of pile-raft composite foundation of high-speed railway in China because of the lack of a reasonable formula. But their results can not meet the accuracy requirements. The theoretical solution to the raft is essentially studied. In order to get the analytical solution to the raft of the pile-raft foundation, the acting area of a single pile on the raft is selected as an element for solution. The element is regarded as a Reissner rectangular moderately thick plate with four edges shear free-clamped on the Winkler elastic foundation on piles. During calculation, the basic elasticity equation for Reissner rectangular moderately thick plates is transferred into the Hamiltonian system. By separation of variables in Symplectic geometry and characteristic function, the analytic solutions to the bending problems of the rectangular plates with medium and thick thickness can be obtained, and then the internal force, displacement, counter-force at pile top and pressure between the soils and the piles can be calculated. By comparing the measured values with the present analytical solutions, it is shown that the calculated moment of the raft, axial force and pressure between the soils and the piles agree with the measured values. The proposed method is proved to be reliable and can be adopted for the design of the pile-raft composite foundation.
    • [1] TIMOSHENKO S, WOINOWSKY-KRIEGER S. Theory of plates and shells[M]. 2nd ed. New York: McGraw-Hill, 1959.
      [2] 石小平, 姚祖康. 弹性地基上四边自由矩形厚板的解[J]. 河北工学院学报, 1985(1): 54-72. (SHI Xiao-ping, YAO Zu-kang. The solution of a rectangular thick plate with free edges on an elastic foundation[J]. Journal of Hebei Institute of Technology, 1985(1): 54-72. (in Chinese))
      [3] 姚伟岸, 钟万勰. 辛弹性力学[M]. 北京: 高等教育出版社, 2002. (YAO Wei-an, ZHONG Wan-xie. Symplectic elasticity[M]. Beijing: Higher Education Press, 2002. (in Chinese))
      [4] 钟万勰. 弹性力学求解新体系[M]. 大连: 大连理工大学出版社, 1995. (ZHONG Wan-xie. A new systematic methodology for theory of elasticity[M]. Dalian: Dalian University of Technology Press, 1995. (in Chinese))
      [5] 李锐. 矩形板问题的Hamilton求解方法[D]. 大连: 大连理工大学, 2012. (LI Rui. Hamiltonian solution approach for the problems of rectangular plates[D]. Dalian: Dalian University of Technology, 2012. (in Chinese))
      [6] 钟阳, 赵晓雷. 弹性矩形板问题的Hamilton正则方程[J]. 力学与实践, 2004, 26(6): 49-51. (ZHONG Yang, ZHAO Xiao-lei. The canonical Hamiltonian representation for elastic rectangular plate[J]. Mechanics in Engineering, 2004, 26(6): 49-51. (in Chinese))
      [7] 钟阳, 张永山. 弹性地基上矩形薄板问题的Hamilton正则方程及解析解[J]. 固体力学学报, 2005, 26(3): 325-328. (ZHONG Yang, ZHANG Yong-shan. Hamilton canonical equations and the analytical solution for rectangular thin plate on elastic foundation[J]. Acta Mechanica Solida Sinica, 2005, 26(3): 325-328. (in Chinese))
      [8] 胡海昌. 弹性力学的变分原理及其应用[M]. 北京: 科学出版社, 1981. (HU Hai-chang. Variational principle in elasticity and applications[M]. Beijing: Science Press, 1981. (in Chinese))
      [9] 曲庆璋, 章权, 季求知, 等. 弹性板理论[M]. 北京: 人民交通出版社, 2000. (QU Qing-zhang, ZHANG Quan, JI Qiu-zhi, et al. Elastic plate theory[M]. Beijing: China Communications Press, 2000. (in Chinese))
      [10] 肖启航. 高速铁路CFG桩复合地基的沉降特性研究[D]. 成都: 西南交通大学, 2010. (XIAO Qi-hang. Analysis of CFG pile composite foundation settlement character of high-speed railway[D]. Chengdu: Southwest Jiaotong University, 2010. (in Chinese))
      [11] 李峰. 高速铁路CFG桩筏结构中桩土相互作用的研究[D]. 成都: 西南交通大学, 2010. (LI Feng. Study of pile-soil interaction about CFG pile-raft structure in high-speed railway[D]. Chengdu: Southwest Jiaotong University, 2010. (in Chinese))
      [12] 赵国堂, 马建林, 彭声应, 等. 高速铁路CFG桩不同结构形式下地基沉降-时间发展规律的试验研究与预测[J]. 铁道建筑, 2009(7): 62-65. (ZHAO Guo-tang, MA Jian-lin, PENG Sheng-ying, et al. Experimental study and prediction on evolution law of foundation settlement with time under different structural forms of CFG pile for high speed railway[J]. Railway Engineering, 2009(7): 62-65. (in Chinese))
