隧道穿越断层破碎带震害机理研究

何川; 李林; 张景; 耿萍; 晏启祥

doi:10.11779/CJGE201403004

隧道穿越断层破碎带震害机理研究 English Version

何川^{1, 2},
李林^1,2,,
张景^{1, 2},
耿萍^{1, 2},
晏启祥^{1, 2}

1. 西南交通大学交通隧道工程教育部重点实验室,四川成都 610031; 2. 西南交通大学土木工程学院,四川成都 610031

基金项目: 国家重点基础研究发展计划（973）项目(2010CB732105); 国家科技支撑计划课题（2012BAG05B03,2013BAB10B04）; 国家自然科学基金高铁联合基金项目（U1134208）; 国家杰出青年科学基金项目（50925830）

详细信息

作者简介:
何川(1964- )，男，教授，博士生导师，主要从事隧道及地下工程方面的研究工作。E-mail: chuanhe21@163.com。

通讯作者:
李林

中图分类号: U45
计量
- 文章访问数: 0559
- HTML全文浏览量: 0
- PDF下载量: 01038
出版历程
- 收稿日期: 2013-05-05
- 发布日期: 2014-03-19

Seismic damage mechanism of tunnels through fault zones

HE Chuan^{1, 2},
LI Lin^1,2,,
ZHANG Jing^{1, 2},
GENG Ping^{1, 2},
YAN Qi-xiang^{1, 2}

1. Key Laboratory of Transportation Tunnel Engineering, Ministry of Education, Chengdu 610031, China; 2. School of Civil Engineering, Southwest Jiaotong University, Chengdu 610031, China

摘要

摘要: 首先对汶川“5.12”等各次大地震中跨越断层破碎带隧道震害进行了资料调研,然后通过振动台模型试验及数值计算对跨断层破碎带隧道的动力响应进行了研究,研究内容主要包括围岩与隧道结构的加速度响应特性、地层变形及衬砌结构内力分布规律等。分析结果表明：震害调研结果、振动台模型试验和数值模拟结果有较好的吻合性,穿越断层破碎带隧道在地震中易于产生破坏；隧道断层带段围岩有较大的加速度响应特性,加速度响应在断层接触段不连续；地震过程中断层带段隧道结构对地层具有明显的追随性和依赖性；断层带隧道错动破坏主要由断层带隧道围岩与较好段围岩位移不同步性而造成的位移差值引起,且位移差值与断层带和隧道较好围岩类型有关；隧道断层破碎带段与较好围岩段衬砌结构横断面具有基本相同的内力分布规律,衬砌内力在共轭45°方向最大,但断层破碎带段衬砌具有最大的内力峰值,更易于在地震过程中产生破坏等。以上成果对于合理认识跨越断层破碎带隧道的地震响应特征具有重要意义,可为隧道实际工程设计和施工的抗震设防提供宝贵的基础资料。
- 隧道工程 /
- 震害机理 /
- 断层破碎带 /
- 振动台模型试验 /
- 隧道地震响应特性
Abstract: First of all, a simple investigation into the responses of tunnels through fault zones during Wenchuan Earthquake and other major earthquakes is made. Then comparative analyses are carried out by means of shaking table model tests and numerical analyses, mainly on acceleration characteristics of the surrounding rock and tunnel structures, deformation laws of geological strata and distribution of internal forces and so on. The analyses indicate that the results of investigations, tests and numerical analyses are in good agreement and that the tunnels through fault zones are easily damaged. The acceleration response in fault contact segments is discontinuous, and the peak acceleration is obviously larger at the fault zones at the same elevation. The tunnel structure has little impact on the response of geological strata during earthquakes, and the behavior of the tunnel structure obviously adheres to and relies on geological strata in the fault zones. The tunnel dislocation damage mechanism is the relative displacement between the fault zone and the surrounding rock, and the relative displacement value is relative to the types of the surrounding rock. The tunnel cross-sectional structure in the fault zones has the same distribution characteristics of internal forces, that is, in conjugate directions of 45°, it is the greatest, but the tunnel structure has relatively higher internal forces and is easily damaged during earthquakes. Those findings are of great importance to the rational understanding of earthquake response behaviors of tunnels through fault zones, and they may provide precious data for the earthquake resistant design and construction of practical projects.
- tunneling engineering /
- seismic damage mechanism /
- fault fracture zone /
- shaking table model test /
- seismic response character of tunnel

HTML全文

参考文献(22)

[1]	HE C, KOIZUMI A. Study on seismic behavior and seismic design methods in transverse direction of shield tunnels[J]. Structural Engineering and Mechanics, 2001, 11(6): 651-662.
[2]	川岛一彦. 地下构筑物の耐震设计[M]. 东京: 鹿岛出版会, 1994: 43-60. (KAWAMATA K. Seismic design of underground structure[M]. Tokyo: Kajima Press, 1994: 43-60. (in Japanese))
[3]	JSCE. The 1995 Hyogoken-Nanbu earthquake[J]. Japan Society of Civil Engineers, 1996, 81(3): 38-45.
[4]	王明年, 崔光耀, 林国进. 汶川地震灾区公路隧道震害调查及初步分析[J]. 西南公路, 2009(4): 41-46. (WANG Ming-nian, CUI Guang-yao, LIN Guo-jin. Reconnaissance and analysis of highway tunnels under Wenchuan earthquake[J]. Southwest Highway, 2009(4): 41-46. (in Chinese))
[5]	李天斌. 汶川特大地震中山岭隧道变形破坏特征及影响因素分析[J]. 工程地质学报, 2008, 16(6): 742-750. (LI Tian-bin. Failure characteristics and influence factor analysis of mountain tunnels at epicenter zones of great Wenchuan earthquake[J]. Journal of Engineering Geology, 2008, 16(6): 742-750. (in Chinese))
[6]	钱七虎, 何川. 隧道工程动力响应特性与汶川地震隧道震害分析及启示[C]// 汶川大地震工程震害调查分析与研究, 2009: 773-778. (QIAN Qi-hu, HE Chuan. Dynamic response characteristics and lessons learnt from damage of tunnels in Wenchuan earthquake[C]// Reconnaissance and Analysis of Tunnel Seismic Damagesin Great Wenchuan Earthquake, 2009: 773-778. (in Chinese))
[7]	WANG Zheng-zheng, GAO Bo, JIANG Yuan-jun, et al. Investigation and assessment on mountain tunnels and geotechnical damage after the Wenchuan earthquake[J]. Science in China Series E: Technological Sciences, 2009, 52(2): 546-558.
[8]	WANG W L, WANG T T, SU J J, et al. Assessment of damage in mountain tunnels due to the Taiwan Chi-Chi Earthquake[J]. Tunneling and Underground Space Technology, 2001, 16: 133-150.
[9]	李林, 何川, 耿萍, 等. 隧道穿越高烈度地震区断层带围岩地震响应分析[J]. 重庆大学学报: 自然科学版, 2012, 35(6): 92-98. (LI Lin, HE Chuan, GENG Ping, et al. Analysis for seismic dynamic responses of tunnel through fault zone in high earthquake intensity area[J]. Journal of Chongqing University: Natural Science, 2012, 35(6): 92-98. (in Chinese))
[10]	王威, 任青文. 活动断裂对深埋隧洞影响的研究概述[J].地震工程与工程振动, 2006, 26(1): 175-180. (WANG Wei, REN Qing-wen. General introduction to the effect of active fault on deeply buried tunnel[J]. Earthquake Engineering and Engineering Vibration, 2006, 26(1): 175-180. (in Chinese))
[11]	蒋华, 蒋树屏, 王晓雯. 断层带处公路隧道横断面抗震分析[J]. 隧道建设, 2009, 29(1): 14-29. (JIANG Hua, JIANG Shu-ping, WANG Xiao-wen. Study on transverse seismic response of highway tunnel in fault region[J]. Tunnel Construction, 2009, 29(1): 14-29. (in Chinese))
[12]	王峥峥. 跨断层隧道结构非线性地震损伤反应分析[D]. 成都: 西南交通大学, 2007. (WANG Zheng-zheng. Nonlinear seismic damage response of tunnel structure across fault[D]. Chengdu: Southwest JiaoTong University, 2007. (in Chinese))
[13]	SHAHIDI A R, VAFAEIAN M. Analysis of longitudinal profile of the tunnels in the active faulted zone and designing the flexible lining[J]. Tunnelling and Underground Space Technology, 2005, 20(3): 213-221.
[14]	方林, 蒋树屏, 林志, 等. 穿越断层隧道振动台模型试验研究[J]. 岩土力学, 2011, 32(9): 2709-2713. (FANG Lin, JIANG Shu-ping, LIN Zhi, et al. Shaking table model test study of tunnel through fault[J]. Rock and Soil Mechanics, 2011, 32(9): 2709-2713. (in Chinese))
[15]	DOWDING C H, ROZEN A. Damage to rock tunnels from earthquake shaking[J]. J Geotech Eng Div, ASCE, 1978, 104(GT2): 175-191.
[16]	SHARMA S, JUDD W R. Underground opening damage from earthquakes[J]. Engineering of Geology, 1991, 30: 263-276.
[17]	李林, 何川, 耿萍, 等. 浅埋偏压洞口段隧道地震响应振动台模型试验研究[J]. 岩石力学与工程学报, 2011, 30(12): 2540-2548. (LI Lin, HE Chuan, GENG Ping, et al. Large-scale shaking table test for shallow-buried unsymmetrical tunnel[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(12): 2540-2548. (in Chinese))
[18]	JTG D70—2004 公路隧道设计规范[S]. 2004. (JTG D70—2004 Code for design of road tunnel[S]. 2004. (in Chinese))
[19]	伍小平, 孙利民, 胡世德, 等. 振动台试验用层状剪切变形土箱的研制[J]. 同济大学学报 (自然科学版), 2002, 30(7): 781-785. (WU Xiao-ping, SUN Li-min, HU Shi-de, et al. Development of laminar shear box used in shaking table test[J]. Journal of Tongji University (Natural Science), 2002, 30(7): 781-785. (in Chinese))
[20]	陈国兴, 王志华, 左熹, 等. 振动台试验叠层剪切型土箱的研制[J]. 岩土工程学报, 2010, 32(1): 89-97. (CHEN Guo-xing, WANG Zhi-hua, ZUO Xi, et al. Development of laminar shear soil container for shaking table tests[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(1): 89-97. (in Chinese))
[21]	MIZUNO H, IIBA M. Shaking table testing of seismic building-pile-soil interaction[C]//Proc 8th of WCEE. San Francisco, 1984: 649-656.
[22]	吴波, 李惠. 建筑结构被动控制的理论与应用[M]. 哈尔滨: 哈尔滨工业大学出版社, 1997. (WU Bo, LI Hui. Theory and application of passive control of building structures[M]. Haerbin: Harbin Institute of Technology Press, 1997. (in Chinese))
