浅埋矩形顶管的“整体背土效应”研究

高毅, 冯超元, 程鹏

高毅, 冯超元, 程鹏. 浅埋矩形顶管的“整体背土效应”研究[J]. 岩土工程学报, 2018, 40(10): 1936-1942. DOI: 10.11779/CJGE201810022
引用本文: 高毅, 冯超元, 程鹏. 浅埋矩形顶管的“整体背土效应”研究[J]. 岩土工程学报, 2018, 40(10): 1936-1942. DOI: 10.11779/CJGE201810022
shu
GAO Yi, FENG Chao-yuan, CHENG Peng. Overall-carrying-soil effect of shallow buried rectangular pipe jacking[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(10): 1936-1942. DOI: 10.11779/CJGE201810022
Citation: GAO Yi, FENG Chao-yuan, CHENG Peng. Overall-carrying-soil effect of shallow buried rectangular pipe jacking[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(10): 1936-1942. DOI: 10.11779/CJGE201810022
shu

浅埋矩形顶管的“整体背土效应”研究  English Version

  • 中铁工程装备集团有限公司地下空间设计研究院,河南 郑州 450016

详细信息
    作者简介:

    高 毅(1984- ),男,高级工程师,主要从事隧道及地下工程科研设计与项目管理工作。Email：gao_yi@126.com。

    通讯作者:

    冯超元，E-mail：fengcy_2017@163.com

  • 中图分类号: TU990.3

Overall-carrying-soil effect of shallow buried rectangular pipe jacking

  • Underground Space Research and Design Institute, China Railway Engineering Equipment Group Co., Ltd., Zhengzhou 450016, China

施引文献

    摘要
  • 摘要: 近年来,矩形顶管在地下空间开发中的应用越来越多,国内外学者针对顶管施工对周边地层的影响、顶推力、摩阻力、减摩措施、管节结构等进行了大量研究,并取得了丰硕的成果。但针对浅埋矩形顶管对其正上方土体整体影响的研究较少。结合矩形顶管浅覆土掘进试验,分析了正上方土体的整体破坏过程,提出“整体背土效应”概念。引入4个假定,建立了正上方土体简化模型,提出整体背土效应的前提条件与破坏条件,并给出了相应的预判方法。采用管土全接触理论、库伦剪切破坏强度准则与朗肯土压力理论进行分析,最终得出整体背土效应与顶程、管节宽度、管土摩阻力以及埋深的相互关系,并进行了算例分析。为今后类似工程避免整体背土效应提供一种新的预判分析理论。
    Abstract: The shallow-buried rectangular pipe jacking project has gradually increased in recent years. The worldwide researchers have achieved fruitful achievements on thrust, friction and pipe structure. However, there are few researches on the carrying-soil effect of rectangular pipe jacking. So the mechanism of carrying-soil effect is analyzed, and the concept and failure process of the overall-carrying-soil effect are proposed. Four assumptions are proposed to establish the simplified model, and its basic and critical conditions are put forward. Based on the theory of pipe-soil contact, the Coulomb's shear failure strength criterion and the theory of Langham's earth pressure, the prejudgment theory is obtained, which reflects the relationship among overall-carrying-soil effect, jacking length, segment width, pipe soil friction and depth. Then an example is given. The conclusions may provide a theoretical reference for avoiding the overall-carrying-soil effect.
    • HTML全文
    • 参考文献(12)
  • [1] 洪开荣. 我国隧道及地下工程发展现状与展望[J]. 隧道建设, 2015, 35(2): 95-107.
    (HONG Kai-rong.State-of-art and prospect of tunnels and underground works in China[J]. Tunnel Construction, 2015, 35(2): 95-107. (in Chinese))
    [2] 彭立敏, 王哲, 叶艺超, 等. 矩形顶管技术发展与研究现状[J]. 隧道建设, 2015, 35(1): 1-8.
    (PENG Li-min, WANG Zhe, YE Yi-chao, et al.Technological development and research status of rectangular pipe jacking method[J]. Tunnel Construction, 2015, 35(1): 1-8. (in Chinese))
    [3] PELLET-BEAUCOUR A L, KASTNER R. Experimental and analytical study of friction forces during microtunneling operations[J]. Tunnelling & Underground Space Technology Incorporating Trenchless Technology Research, 2002, 17(1): 83-97.
    [4] REILLY C C, ORR T L L. Physical modelling of the effect of lubricants in pipe jacking[J]. Tunnelling & Underground Space Technology, 2017, 63: 44-53.
    [5] 荣亮, 杨红军. 郑州市下穿中州大道超大断面矩形隧道顶管姿态控制技术[J]. 隧道建设, 2015, 35(12): 1338-1344.
    (RONG Liang, YANG Hong-jun.Settlement control technology for tunnel crossing underneath zhongzhou avenue in Zhengzhou constructed by super-large rectangular cross-section pipe-jacking machine[J]. Tunnel Construction, 2015, 35(12): 1338-1344. (in Chinese))
    [6] 魏纲, 魏新江, 徐日庆. 顶管施工引起的挤土效应研究[J]. 岩土力学, 2006, 27(5): 717-722.
    (WEI Gang, WEI Xin-jiang, XU Ri-qing.Study on soil-compacting effects induced by pipe jacking construction[J]. Rock and Soil Mechanics, 2006, 27(5): 717-722. (in Chinese))
    [7] 熊翦. 矩形顶管关键受力分析[D]. 北京: 中国地质大学, 2013.
    (XIONG Jian.Analysis of critical mechanics of rectangular pipe jacking[D]. Beijing: China University of Geosciences, 2013. (in Chinese))
    [8] CECS246—2008 给水排水工程顶管技术规程[S]. 2008.
    (CECS246—2008 Technical specification for pipe jacking of water supply and sewerage engineering[S]. 2008. (in Chinese))
    [9] 余彬泉, 陈传灿. 顶管施工技术[M]. 北京: 人民交通出版社, 2003.
    (YU Bin-quan, CHEN Chuan-can.Pipe jacking construction technology[M]. Beijing: China Communications Press, 2003. (in Chinese))
    [10] 张鹏, 马保松, 曾聪, 等. 基于管土接触特性的顶进力计算模型分析[J]. 岩土工程学报, 2017, 39(2): 244-249.
    (ZHANG Peng, MA Bao-song, ZENG Cong, et al.Numerical model for jacking force based on pipe-soil contact characteristics[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(2): 244-249. (in Chinese))
    [11] 叶艺超, 彭立敏, 杨伟超, 等. 考虑泥浆触变性的顶管顶力计算方法[J]. 岩土工程学报, 2015, 37(9): 1653-1659.
    (YE Yi-chao, PENG Li-min, YANG Wei-chao, et al.Calculation of jacking force for pipe-jacking considering mud slurry thixotropy[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(9): 1653-1659. (in Chinese))
    [12] 日本推進技術協会. 推進工法体系[M]. 东京: 日本推進技術協会, 2013.
    (Japan Micro Tunneling Association. Pipe-jacking application[M]. Tokyo: Japan Micro Tunneling Association, 2013. (in Japanese))
