Thermal effects and infrared detection method for shallow reinforcement corrosion in tunnel linings under natural conditions

LIU Xuezeng; YANG Xueliang; YANG Zhilu; LI Zhen; YANG Zishuo

doi:10.11779/CJGE20220183

Volume 45 Issue 4

Turn off MathJax

Article Contents

Abstract

References

Chinese Journal of Geotechnical Engineering > 2023 > 45(4): 680-689. > DOI: 10.11779/CJGE20220183

LIU Xuezeng, YANG Xueliang, YANG Zhilu, LI Zhen, YANG Zishuo. Thermal effects and infrared detection method for shallow reinforcement corrosion in tunnel linings under natural conditions[J]. Chinese Journal of Geotechnical Engineering, 2023, 45(4): 680-689. DOI: 10.11779/CJGE20220183

Citation:

PDF (13863 KB)

Thermal effects and infrared detection method for shallow reinforcement corrosion in tunnel linings under natural conditions

1.
College of Civil Engineering, Tongji University, Shanghai 200092, China
2.
Shanghai Tongyan Civil Engineering Technology Co., Ltd., Shanghai 200092, China
3.
Shanghai Engineering Reseach Center of Underground Infrastructure Detection and Maintenance Equipment, Shanghai 200092, China

More Information

Received Date: February 20, 2022
Available Online: April 16, 2023

Graphical Abstract

Abstract

Abstract

With the increase of the service life of the tunnel, the diseases such as water leakage and cracking of the linings have become normal, and the induced reinforcement corrosion gradually emerges. After the reinforcement corrosion to a certain extent, the linings will peel off. Therefore, it is particularly important to discover the corrosion degree and position of reinforcement in time. The heat conduction laws of reinforcement corrosion of the linings under the natural temperature difference are studied through the laboratory tests and numerical simulations, the influence laws of temperature difference inside and outside the linings and the degree of reinforcement corrosion on the inner surface temperature distribution of the linings are analyzed, and the feasibility and applicable conditions of infrared thermography technology for detecting the corrosion of the shallow reinforcement corrosion of the linings are explored. The results show that: (1) The infrared detection is feasible when the temperature difference inside and outside the linings is 1.0℃~11.9℃, and the temperature difference inside and outside the linings can meet the conditions in winter. The minimum temperature difference required by the infrared detection is 3.8℃, 1.8℃ and 1.4℃ when the corrosion rate of reinforcement is 6.51%, 19.02% and 23.16%. (2) The relationship among the corrosion rate of lining reinforcement(ρ), the temperature difference of inner surface of the secondary linings (T₁) and the temperature difference between the inner and outer surfaces of the secondary linings(T₂) is $\rho = 1.1 \times {10^5}T_2^{ - 3.2}T_1^3 +$ $503.7T_2^{ - 0.9}{T_1}$ . When the temperature difference inside and outside the lining is 3℃~30℃, the detectable corrosion rate of reinforcement is 9.78%~1.18%. (3) Through the heat conduction effect caused by the temperature difference inside and outside the linings, the position and degree of reinforcement corrosion can be comprehensively judged from the temperature distribution on the inner surface of the linings, which provides a new rapid detection method for the corrosion of shallow reinforcement in tunnel linings.
- tunnel lining,
- reinforcement corrosion,
- infrared detection,
- laboratory test,
- numerical analysis

FullText(HTML)

References (20)

References
