土工格栅纵横肋的筋土承载特性分析

王家全; 陆梦梁; 周岳富; 张亮亮

doi:10.11779/CJGE201801020

土工格栅纵横肋的筋土承载特性分析 English Version

广西科技大学土木建筑工程学院,广西柳州 545006

基金项目: 国家自然科学基金项目（51469005）；广西自然科学基金项目（2015GXNSFAA139257，2017GXNSFAA198170）；广西科技大学研究生教育创新计划项目（GKYC201627）

详细信息

作者简介:
王家全(1981-),男,广西南宁人,博士,教授,主要从事加筋结构、细观岩土力学、地基基础等方面的教学与研究工作。E-mail:wjquan1999@163.com。

中图分类号: TU433
计量
- 文章访问数: 349
- HTML全文浏览量: 6
- PDF下载量: 266
出版历程
- 收稿日期: 2016-10-27
- 发布日期: 2018-01-24

Bearing characteristics of reinforced soil with longitudinal and transverse ribs of geogrids

College of Civil and Architectural Engineering, Guangxi University of Science and Technology, Liuzhou 545006, China

摘要

摘要: 为研究土工格栅纵横肋与砂土的界面受力特性,进行了不同法向压力的格栅拉拔试验,分别设计了横向与纵向剪除横肋的6种拉拔试验工况,研究横肋减少对格栅受力、拉拔阻力峰值和位移及似摩擦系数的影响,并分别对比了整体剪切和刺入剪切破坏模式下的格栅拉拔阻力,揭示格栅筋土界面的相互作用机理。结果表明,随着横肋的减少,格栅拉拔阻力和似摩擦系数不断地变小;横肋沿横向减少的格栅最大拉拔阻力大于横肋沿纵向减少的最大拉拔阻力,完整横肋有助于筋土界面的加筋作用的充分发挥。理论计算格栅界面摩擦力约为18%~19%的试验拉拔阻力,而试验获得的格栅界面摩擦力与试验拉拔阻力的比值为29%~33%,横肋与土体挤压咬合产生的承载力分量占了总拉拔阻力的67%~71%,横肋极大提高了土工格栅的拉拔阻力。
- 土工格栅 /
- 界面作用 /
- 拉拔试验 /
- 受力特性
Abstract: In order to study the stress characteristics of interface between longitudinal and transverse ribs of geogrids and sand, the pullout tests are carried out under different normal pressures. Six pull-out test conditions are designed by trimming ribs in the transverse and longitudinal directions. The effects of geogrid stress, pullout resistance peak and displacement and apparent friction coefficient are studied owing to reduction of transverse ribs, and the pullout resistances under two modes of general shear failure and punching shear failure are compared, which reveales the interaction mechanism of reinforced soil interface. The results show that with the decrease of the transverse ribs, the pullout resistance and apparent friction coefficient of geogrids are decreased. The maximum pullout resistance of geogrids that the ribs are reduced in the transverse direction is larger than that of the ribs reduced in the longitudinal direction. The full transverse ribs can contribute to the reinforcement effect of the interface. The skin friction component of theoretical calculation is about 18%~19% of the experimental pullout resistance, while the experimental skin friction component is about 29% -33% of the experimental pullout resistance, and the bearing capacity component of the transverse ribs accounts for 67%~71% of the total pullout resistance. The transverse ribs greatly improve the pullout resistance of geogrids.
- geogrid /
- interface effect /
- pullout test /
- mechanical characteristic

HTML全文

参考文献(15)

[1]	包承纲. 土工合成材料界面特性的研究和试验验证[J]. 岩石力学与工程学报, 2006, 25(9): 1735-1735. (BAO Cheng-gang.Study on characteristics of geosynthetics interface and its testing validation[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25(9): 1735-1735. (in Chinese))
[2]	王子鹏, 贾梓. 土工格栅横肋在加筋作用中贡献的试验研究[J]. 长江科学院院报, 2014, 31(3): 84-86. (WANG Zi-peng, JIA Zi.Pull-out test on the contribution of geogrid Ribs to reinforcement effect[J]. Journal of Yangtze River Scientific Research Institute, 2014, 31(3): 84-86. (in Chinese))
[3]	PALMEIRA E M.Soil-geosynthetic interaction: Modelling and analysis[J]. Geotextiles and Geomembranes, 2009, 27(5): 368-390.
[4]	杨果林, 王永和. 加筋土筋材工程特性试验研究[J]. 中国公路学报, 2001, 14(3): 11-16. (YANG Guo-lin, WANG Yong-he.Study of engineering of characteristics of material used reinforced earth[J]. China Journal of Highway and Transport, 2001, 14(3): 11-16. (in Chinese))
[5]	WILSON-FAHMY R F, KOERNER R M, SANSONE L J. Experimental behavior of polymeric geogrids in pullout[J]. Journal of Geotechnical Engineering, 1994, 120(4): 661-677.
[6]	杨广庆, 李广信, 张保俭. 土工格栅界面摩擦特性试验研究[J]. 岩土工程学报, 2006, 28(8): 948-952. (YANG Guang-qing, LI Guang-xin, ZHANG Bao-jian.Experimental study on friction characteristics of geogrid interface[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(8): 948-952. (in Chinese))
[7]	陈榕, 栾茂田, 赵维, 等. 土工格栅拉拔试验及筋材摩擦受力特性研究[J]. 岩土力学, 2009, 30(4): 960-964. (CHEN Rong, LUAN Mao-tian, ZHAO Wei.Study on stress characteristics of geogrid pullout friction test and reinforcement[J]. Rock and Soil Mechanics, 2009, 30(4): 960-964. (in Chinese))
[8]	汪明元, 包承纲, 丁金华, 等. 试验条件对土工格栅与膨胀土界面拉拔性状的影响[J]. 岩土力学, 2008, 29(11): 442-448. (WANG Ming-yuan, BAO Cheng-gang, DING Jin-hua, et al.Effect of some test conditions on pull-out behaviors of interface between geogrids and compacted expansive soils[J]. Rock and Soil Mechanics, 2008, 29(11): 442-448. (in Chinese))
[9]	蔡剑韬. 土工格栅加筋膨胀土拉拔试验研究[J]. 岩土力学, 2015, 36(增刊1): 204-208. (CAI Jian-tao.Pull-out test on interface behavior between expansive soils and geogrids[J]. Rock and Soil Mechanics, 2015, 36(S1): 204-208. (in Chinese))
[10]	BERGADO D T, SHIVASHANKAR R, ALFARO M C, et al.Interaction behaviour of steel grid reinforcements in a clayey sand[J]. Géotechnique, 1993, 43(4): 589-603.
[11]	JTGE50—2006 公路工程土工合成材料试验规程[S]. 2016. (JTGE50—2006 Test methods of geosynthetics for highway engineering[S]. 2016. (in Chinese))
[12]	PETERSON L M, ANDERSON L R.Pullout resistance of welded wire mats embedded in soil[D]. Logan: Utah State University, 1980.
[13]	JEWELL R A, MILLIGAN G W E, SARSBY R W, et al. Interaction between Soil and Geogrids[C]// Proceeding from the Symposium on Polymer Grid Reinforcement in Civil Engineering. London: 1984: 18-30.
[14]	MORACI N, GIOFFRÈ D.A simple method to evaluate the pullout resistance of extruded geogrids embedded in a compacted granular soil[J]. Geotextiles and Geomembranes, 2006, 24(2): 116-128.
[15]	孙训海. 土工合成材料界面特性研究[D]. 天津: 天津大学, 2005. (SUN Xun-hai.Study on characteristics of interface interaction between geosynthetics and soil[D]. Tianjin: Tianjin University, 2005. (in Chinese))
