不同刀具配置下隧道掘进机高效破岩机理与推力预估

毛红梅; 陈馈; 冯欢欢

不同刀具配置下隧道掘进机高效破岩机理与推力预估 English Version

1. 陕西铁路工程职业技术学院轨道工程系，陕西渭南 714000; 2. 中铁隧道集团盾构及掘进技术国家重点实验室，河南郑州 450001

基金项目: 国际科技合作专项项目（2011DFB71550）

详细信息

作者简介:
毛红梅（1973- ），女，陕西渭南人，本科，副教授，陕西铁路工程职业技术学院轨道工程系主任，盾构及掘进技术国家重点实验室访问学者，主要从事隧道专业教学与科研工作。E-mail: mhm1108@163.com。

中图分类号: U455.39
计量
- 文章访问数: 379
- HTML全文浏览量: 0
- PDF下载量: 641
出版历程
- 收稿日期: 2013-03-20
- 发布日期: 2013-09-21

Rock-breaking mechanism of TBM with different types of cutter tools and estimation of thrust force

1. Railway Engineering Department, Shaanxi Railway Institute, Weinan 714000, China; 2. State Key Laboratory of Shield Machine and Boring Technology, China Railway Tunnel Group, Zhengzhou 450001, China

摘要

摘要: 为解决隧道掘进机刀盘刀具破岩的安全性、可靠性、高效性这一隧道掘进机施工难题，从高效破岩机理和刀盘刀具与围岩耦合作用规律两个方面进行了研究，对单刀及多刀破岩理论体系进行了完善。结合理论分析和滚刀岩机作用综合实验台上的实验结果，提出了红砂岩、石灰岩和花岗岩等3种常见岩石的最优破岩刀间距，并给出了当岩石强度位于40～170 MPa之间时的最优刀间距计算式。综合考虑各种因素对隧道掘进机总推力、刀盘扭矩的影响，提出了复合式隧道掘进机总推力、刀盘扭矩估算的理论公式。通过工程实例验证，该理论计算式具有较高的科学性和精确性。研究成果可直接用于刀具选型布置、推力、扭矩设计，从而降低隧道掘进机的制造成本、提高施工效率。
- 隧道掘进机 /
- 刀盘 /
- 滚刀 /
- 破岩机理 /
- 围岩
Abstract: The rock-breaking mechanism and the coupling effect rules between the cutter tool and the surrounding rock are studied in order to resolve the TBM construction problems of cutter breaking rock, such as security, reliability and efficiency. The optimal cutter spacings for some common rocks, such as red sandstone, limestone and granite, are put forward based on the theoretical analysis and experimental results from the experimental platform for the function between disc cutter and rock. A formula for the optimal cutter spacing is deduced while the rock strength is under 40～170 MPa. Meanwhile, the mechanism of rock-breaking under single-tool and multi-tool is improved. Considering the impact of various factors, a new method for estimating the total thrust force and cutter-head torque of compound TBM is proposed, and it is proved to be more scientific and accurate through practical projects. The test results can be used to select and arrange the cutters, to design thrust force and torque, to reduce the manufacturing cost of TBM and to increase the efficiency of construction.
- TBM /
- cutter-head /
- hobbing cutter /
- rock-breaking mechanism /
- surrounding rock

HTML全文

参考文献(14)

[1]	苏翠侠, 王燕群, 蔡宗熙, 等. 盾构刀盘掘进载荷的数值模拟[J]. 天津大学学报, 2011, 44(6): 522-528. (SU Cui-xia, WANG Yan-qun, CAI Zong-xi, et al. Numerical simulation of excavation load on cutterhead in shield tunneling machine[J]. Journal of Tianjin University, 2011, 44(6): 522-528. (in Chinese))
[2]	李晓豁, 姜丽丽. 掘进机截割硬岩的载荷模拟研究[J]. 中国工程机械学报, 2008, 6(4): 415-417+427. (LI Xiao-huo, JIANG Li-li. Excavator loading simulation for hard-rock cutting[J]. Chinese Journal of Construction Machinery, 2008, 6(4): 415-417+427. (in Chinese))
[3]	吕强, 傅德明. 土压平衡盾构掘进机刀盘扭矩模拟试验研究[J]. 岩石力学与工程学报, 2006(增刊1): 3137-3143. (LÜ Qiang, FU De-ming. Research on torque of cutterhead for earth pressure balance shield with simulating experimental[J]. Chinese Journal of Rock Mechanics and Engineering, 2006(S1): 3137-3143. (in Chinese))
[4]	沈建奇, 金先龙, 杨建刚, 等. 盾构机刀盘掘削动态数值模拟[J]. 上海交通大学学报, 2009, 43(6): 1017-1020. (SHEN Jian-qi, JIN Xian-long, YANG Jian-gang, et al. Dynamic numerical simulation of excavation in shield tunnelling[J]. Journal of Shanghai Jiao Tong University, 2009, 43(6): 1017-1020. (in Chinese))
[5]	邢彤, 龚国芳, 杨华勇. 盾构刀盘驱动扭矩计算模型及实验研究[J]. 浙江大学学报(工学版), 2009, 43(10): 1794-1800. (XING Tong, GONG Guo-fang, YANG Hua-yong. Torque calculation model of cutting head in shield machine and experimental study[J]. Journal of Zhejiang University (Engineering Science), 2009, 43(10): 1794-1800. (in Chinese))
[6]	蒲毅, 刘建琴, 郭伟, 等. 土压平衡盾构机刀盘刀具布置方法研究[J]. 机械工程学报, 2011, 47(15): 161-168. (PU Yi, LIU Jian-qin, GUO Wei, et al. Research on cutting tool layout method of earth pressure balance shield[J]. Journal of Mechanical Engineering, 2011, 47(15): 161-168. (in Chinese))
[7]	郭伟, 胡竟, 王磊, 等. 基于CFD的土压平衡盾构刀盘开口分布特征研究[J]. 机械工程学报, 2012, 48(17): 144-151. (GUO Wei, HU Jing, WANG Lei, et al. Study on the opening distribution characteristics of earth pressure balance shield cutter head based on CFD[J]. Journal of Mechanical Engineering, 2012, 48(17): 144-151. (in Chinese))
[8]	SMITS, ANTHONY Robert. The excavation of hard rock by disc and roller cutter[D]. Sydney: University of New South Wales, 1980.
[9]	OZDEMIR L, RMILLE R. Cutter performance study for deep based missile egress excavation[D]. Golden: Earth Mechanics Institute Colorado School of Mines, 1986, 12(23): 105-132.
[10]	管会生, 高波. 盾构刀盘扭矩估算的理论模型[J]. 西南交通大学学报, 2008, 43(2): 213-217, 226. (GUAN Hui-sheng, GAO Bo. Theoretical model for estimation of cutter head torque in shield tunneling[J]. Journal of Southwest Jiaotong University, 2008, 43(2): 213-217, 226. (in Chinese))
[11]	朱合华, 徐前卫, 廖少明, 等. 土压平衡盾构施工的顶进推力模型试验研究[J]. 岩土力学, 2007, 28(8): 1587-1594. (ZHU He-hua, XU Qian-wei, LIAO Shao-ming, et al. Experimental study on thrust force during tunnel excavation with earth pressure balance shield machine[J]. Rock and Soil Mechanics, 2007, 28(8): 1587-1594. (in Chinese))
[12]	王洪新. 土压平衡盾构刀盘扭矩计算及其与盾构施工参数关系研究[J]. 土木工程学报, 2009, 42(9): 109-113. (WANG Hong-xin. Calculation of cutterhead torque for EPB shield and the relationship between cutterhead torque and shield driving parameters[J]. China Civil Engineering Journal, 2009, 42(9): 109-113. (in Chinese))
[13]	徐小荷, 余静. 岩石破碎学[M]. 北京: 煤炭工业出版社, 1984. (XU Xiao-he, YU Jing. Fragmentation of rocks[M]. Beijing: Coal Industry Publishing House, 1984. (in Chinese)))
[14]	中国科学技术情报研究所. 岩石掘进机译文集(第二集)[M]. 北京: 科学技术文献出版社, 1978. (Institute of Scientific and Technical Information of China. The translation groups of rock tunnel boring machine (Volume 2)[M]. Beijing: Scientific and Technical Documents Publishing House, 1978. (in Chinese))
