湿陷性黄土隧道的工程性质分析

邵生俊; 杨春鸣; 焦阳阳; 陆斯

湿陷性黄土隧道的工程性质分析 English Version

邵生俊^1,2,
杨春鸣^1,2,
焦阳阳^1,2,
陆斯^1,2

1. 西安理工大学岩土工程研究所，陕西西安 710048; 2. 陕西省黄土力学与工程重点实验室，陕西西安 710048

基金项目: 国家自然科学基金项目（41272320）

详细信息

作者简介:
邵生俊(1964- )，男，甘肃武威人，教授，博士生导师，从土动力学与黄土力学研究。E-mail: sjshao@xaut.edu.cn。

中图分类号: TU475.3
计量
- 文章访问数: 0455
- HTML全文浏览量: 0
- PDF下载量: 0895
出版历程
- 收稿日期: 2012-12-17
- 发布日期: 2013-09-21

Engineering properties of collapsible loess tunnel

1. Institute of Geotechnical Engineering of Xi'an University of Technology, Xi'an 710048, China; 2. Shaanxi Key Laboratory of Loess Mechanics and Engineering, Xi'an 710048, China

摘要

摘要: 黄土隧道往往具有特殊的湿陷性黄土围岩和干旱半干旱气候地区特殊的地形地貌及地质环境，对隧道结构构成了潜在的不利影响。在对湿陷性黄土隧道修建和运行中工程特性认识的基础上，首先，根据地形地貌、地层结构、侵蚀发育、地下水条件和黄土浸水水源，进行了隧道的岩土环境等级和浸水等级划分，以及湿陷性黄土隧道的环境等级划分。其次，给出了隧道黄土地基湿陷变形量的计算分析方法，依据黄土地基湿陷变形不均匀沉降对衬砌结构的作用影响，以及列车运行对路基沉降变形的控制标准和建筑地基湿陷变形对结构的作用影响，确定了隧道湿陷性黄土地基等级的划分标准。最后，考虑到现行《湿陷性黄土地区建筑规范》适用的局限性，结合湿陷性黄土隧道的工程特点，针对隧道施工过程中围岩稳定性和湿陷变形对衬砌结构影响的两个重要问题，相应的提出了隧道地基湿陷性变形的评价方法和围岩压力的确定方法；由竖向压缩应力系数确定湿陷压缩应力，结合试验得出的湿陷系数计算隧道下地基土在实际压缩应力条件下的湿陷变形量。在考虑黄土结构性的条件下，利用太沙基公式计算隧道围岩压力，得到了围岩压力随黄土构度的变化关系。
- 湿陷性黄土隧道 /
- 环境等级 /
- 湿陷变形 /
- 围岩压力
Abstract: The collapsibility of loess and, the arid and semi-arid climate, complicated landform and topography, and particular geological environment in loess zone potentially have adverse effects on the structure of loess tunnel. Based on the engineering properties of collapsible loess tunnel in the process of construction and operation, this paper presented classification standards for the geotechnical environment, water-immersion environment, and integrated environment of loess tunnel, according to different landform, topography, stratigraphic structure, erosion degree, subsurface water, and surface water source conditions. Furthermore, computed analysis method for the collapse deformation of loess tunnel foundation was proposed. According to differential settlement of loess foundation acting on lining structure, control standard of subgrade settlement during train movement, and influence of collapse deformation of building foundation on structure, classification standard for the foundation of collapsible loess tunnel was put forward. Moreover, considering the application limitation of present “Code for Building Construction in Collapsible Loess Zone” and the engineering properties of collapsible loess tunnel, assessment method for the collapse deformation of loess tunnel foundation and computed method for confining pressure were presented, respectively, corresponding to the stability of surrounding rock during construction and the influence of collapse deformation on lining structure. Collapsible compression pressure can be determined by the coefficient of vertical compression pressure, and the collapse deformation of tunnel subsoil thus can be calculated with the experimental coefficient of collapsibility. Introducing structural index in the Terzaghi equation of surrounding rock pressure, relationship between surrounding rock pressure and structural index was analyzed.
- collapsible loess tunnel /
- environment classification /
- collapse deformation /
- surrounding rock pressure

HTML全文

参考文献(14)

[1]	钱鸿缙, 王继唐, 罗宇生. 湿陷性黄土地基[M]. 北京: 中国建筑工业出版社, 1985. (QIAN Hong-jin, WANG Ji-tang, LUO Yu-sheng. Collapsible loess foundation[M]. Beijing: China Architecture and Building Press, 1985. (in Chinese))
[2]	郑晏武. 中国黄土的湿陷性[M]. 北京: 地质出版社, 1982. (ZHENG Yan-wu. Collapsibility of loess in China[M]. Beijing: Geological Press, 1982. (in Chinese))
[3]	冯连昌, 郑晏武. 中国湿陷性黄土[M]. 北京: 中国铁道出版社, 1982. (FENG Lian-chang, ZHENG Yan-wu. Collapsible loess in China[M]. Beijing: China Railway Publishing House, 1982. (in Chinese))
[4]	谢定义. 试论我国黄土力学研究中的若干新趋向[J]. 岩土工程学报, 2001, 23(1): 3-13. (XIE Ding-yi. Exploration of some new tendencies in research of loess soil mechanic[J]. Chinese Journal of Geotechnical Engineering, 2001, 23(1): 3-13. (in Chinese))
[5]	刘祖典. 黄土力学与工程[M]. 西安: 陕西科学技术出版社, 1997. (LIU Zu-dian. Loess mechanics and engineering[M]. Xi'an: Shaanxi Science and Technology Press, 1997. (in Chinese))
[6]	关文章. 湿陷性黄土工程性能新篇[M]. 西安: 西安交通大学出版社, 1992. (GUAN Wen-zhang, A new chapter of collapsible loess engineering properties[M]. Xi'an: Xi'an Jiaotong University Press, 1992. (in Chinese))
[7]	赵勇, 李国良, 喻渝. 黄土隧道工程[M]. 北京: 中国铁道出版社, 2011. (ZHAO Yong, LI Guo-liang, YU Yu. Loess tunnel engineering[M]. Beijing: China Railway Publishing House, 2011. (in Chinese))
[8]	GB 50025—2004 湿陷性黄土地基建筑规范[S]. 北京: 中国建筑工业出版社, 2004. (GB 50025—2004 Code for building construction in collapsible loess regions[S]. Beijing: China Architecture and Building Press, 2004. (in Chinese))
[9]	许增荣. 湿陷性黄土场地浸水环境分析与分级[J]. 西南交通大学学报, 2009, 44(增刊): 78-85. (XU Zeng-rong. Analysis and classification of soaking environment of collapsible loess fields[J]. Journal of Southwest Jiaotong University, 2009, 44(S0): 78-85. (in Chinese))
[10]	徐干成, 白洪才, 郑颖人. 地下工程支护结构[M]. 北京: 中国水利水电出版社, 2002. (XU Gan-cheng, BAI Hong-cai, ZHENG Ying-ren. Supporting structure of underground engineering[M]. Beijing: China Waterpower Press, 2002. (in Chinese))
[11]	宋克强, 崔中兴, 袁继国, 等. 古刘滑坡的蠕变特征及其预报分析[J]. 岩土工程学报, 1994, 16(4): 56-64. (SONG Ke-qiang, CUI Zhong-xing, YUAN Ji-guo, et al. Creep characteristics analysis and prediction of Guliu slide[J]. Chinese Journal of Geotechnical Engineering, 1994, 16(4): 56-64. (in Chinese))
[12]	邵生俊, 周飞飞, 龙吉勇. 原状黄土结构性及其定量化参数研究[J]. 岩土工程学报, 2004, 26(4): 531-536. (SHAO Sheng-jun, ZHOU Fei-fei, LONG Ji-yong. Structural properties of loess and its quantitative parameter[J]. Chinese Journal of Geotechnical Engineering, 2004, 26(4): 531-536. (in Chinese))
[13]	邵生俊, 龙吉勇, 于清高, 等. 湿陷性黄土的结构性参数本构模型[J]. 水利学报, 2006, 37(11): 1315-1322. (SHAO Sheng-jun, LONG Ji-yong, YU Qing-gao, et al. A constitutive model of collapsible loess with structure parameter[J]. Journal of Hydraulic Engineering, 2006, 37(11): 1315-1322. (in Chinese))
[14]	邵生俊, 郑文, 王正泓, 等. 黄土的构度指标及其试验确定方法[J]. 岩土力学, 2010, 31(1): 15-19. (SHAO Sheng-jun, ZHENG Wen, WANG Zheng-hong, et al. Structural index of loess and its testing method[J]. Rock and Soil Mechanics, 2010, 31(1): 15-19. (in Chinese))
