Pseudo-three-dimensional experimental study on tunnel face stability in weak and fractured rock mass
-
摘要: 在软弱破碎围岩中进行隧道开挖，往往因岩体应力过大或围岩过分变形而导致开挖面失稳破坏，并引发隧道塌方事故。本文以Ⅳ类破碎围岩为参照对象，首先将其等效为单一均值地层，随后利用相似模型材料对隧道地层进行模拟，并在不同加载模式下再现隧道开挖，研究了开挖面的破坏模式及其渐进破坏特征。结果表明，在缓慢加载模式下，开挖面呈穹顶式塌方，而在快速加载模式下，开挖面呈通天型塌方；隧道开挖后的初期，开挖面上部范围岩体的侧向位移较大，而在后期底部岩体侧向位移迅速增大，并最终形成自下而上的破坏面；隧道开挖后，开挖面前方岩体水平向应力增量最大值位于开挖面上部但靠近隧道中线的位置，而竖向应力增量最大值则始终位于开挖面轮廓的顶部。Abstract: Tunnelling in weak and fractured rock mass will inevitably induce excessive stress or deformation of surrounding rock, which results in tunnel face collapse accidents. In order to understand the failure modes and progressive failure characteristics, the weak and fractured rock mass of grade Ⅳ according to Chinese codes is taken as the reference prototype. This rock mass is firstly equivalent for isotropic continual stratum, and then modeled by similar materials. Subsequently, model tests are carried out to simulate tunnel excavation under different loading modes. The test results show that, the tunnel face collapses in dome-style in the slow loading mode, while in the fast loading mode, it collapses in chimney shape and reaches ground surface. In the initial stage after excavation, the lateral displacement at the upside of tunnel face is relatively large; with the increase of overlying loads, the lateral displacement at the downside of tunnel face grows drastically and forms the final failure face from bottom to top. After tunnel excavation, the position of the maximal horizontal stress increment locats at the upside of tunnel face near the line center, but the location of maximal vertical stress increment lies in the top of tunnel face profile.
-
[1] 邓雄业 , 孔祥金 . 靠椅山隧道大塌方处理 [J]. 公路隧道 , 2001(4): 16 – 20. (DENG Xiog-ye, KONG Xiang-jin. Treatment of Kaoyishan mountain tunnel collapse[J]. Highway Tunnel, 2001(4): 16 – 20. (in Chinese)) [2] 邓良胜 , 宋战平 , 李 宁 . 紫坪铺工程 F3 断层大断面隧洞施工中塌方机理的数值仿真分析研究 [J]. 水利水电技术 , 2002, 33 (11): 30 – 32. (DENG Liang-sheng, SONG Zhang-ping, LI Ning. Numerical simulation and analysis on the large section tunnel collapse mechanism at F3 fault in Zipingpu project[J]. Water Resource and Hydropower Engineering, 2002, 33 (11): 30 – 32. (in Chinese)) [3] MASHIMO H, SUZUKI M. Stability conditions of tunnel face in sandy ground[C]// Centrifuge 98: Proceedings of the International Conference Centrifuge 98. KIMURA T, KUSAKABE O, TAKEMURA J, eds. Tokyo, 1998: 721 – 725. [4] AL HALLAK R. Experimental study of the stability of a tunnel face reinforced by bolts[C]// Geotechnical Aspect of Underground Construction in Soft Ground. Balkema, Rotterdam, 2000: 65 – 68. [5] KAMATA H, MASHIMO H. Centrifuge model test of tunnel face reinforcement by bolting[J]. Tunnelling and Underground Space Technology, 2003(18): 205 – 212. [6] SEO K, DOMON T, NISHIMURA K. Behaviour of a tunnel face reinforced by bolts: Influence of an deviated installation[J]. Tunnelling and Underground Space Technology, 2006(21): 444 – 449. -
