青草沙水源地原水工程输水隧道单层衬砌管片接头荷载试验研究

闫治国, 彭益成, 丁文其, 朱合华, 黄锋

闫治国, 彭益成, 丁文其, 朱合华, 黄锋. 青草沙水源地原水工程输水隧道单层衬砌管片接头荷载试验研究[J]. 岩土工程学报, 2011, 33(9): 1385-1390.
引用本文: 闫治国, 彭益成, 丁文其, 朱合华, 黄锋. 青草沙水源地原水工程输水隧道单层衬砌管片接头荷载试验研究[J]. 岩土工程学报, 2011, 33(9): 1385-1390.
shu
YAN Zhi-guo, PENG Yi-cheng, DING Wen-qi, ZHU He-hua, HUANG Feng. Load tests on segment joints of single lining structure of shield tunnel in Qingcaosha Water Conveyance Project[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(9): 1385-1390.
Citation: YAN Zhi-guo, PENG Yi-cheng, DING Wen-qi, ZHU He-hua, HUANG Feng. Load tests on segment joints of single lining structure of shield tunnel in Qingcaosha Water Conveyance Project[J]. Chinese Journal of Geotechnical Engineering, 2011, 33(9): 1385-1390.
shu

青草沙水源地原水工程输水隧道单层衬砌管片接头荷载试验研究  English Version

  • 1. 同济大学土木工程学院地下建筑与工程系，上海 200092 ； 2. 同济大学岩土及地下工程教育部重点实验室，上海 200092

基金项目: 国家自然科学基金项目（50878149）；教育部新世纪优秀人才支持计划项目（NCET-08-0402）
详细信息
    作者简介:

    闫治国 (1977 – ) ，博士，讲师，主要从事地下建筑结构力学试验及抗火性能方面研究。

  • 中图分类号: TU451.5

Load tests on segment joints of single lining structure of shield tunnel in Qingcaosha Water Conveyance Project

  • (1. Department of Geotechnical Engineering, Tongji University, Shanghai 200092, China; 2. Key Laboratory of Geotechnical and Underground Engineering of Ministry of Education, Tongji University, Shanghai 200092, China)

摘要

    摘要
  • 摘要: 纵缝转角刚度、纵缝（环缝）剪切刚度和弯矩传递系数是盾构隧道衬砌结构计算模型中的关键参数，历来是本领域研究的重点和热点。结合青草沙水源地原水工程，通过管片接头 原型荷载试验 ，对上述关键计算参数进行研究。试验结果表明正弯矩作用下接头转角刚度符合双直线模型，负弯矩作用下转角刚度近似成线性，而且不同的接头构造情况下纵缝转角刚度值和其变化规律不同。在纵缝和环缝剪切试验中，管片间的错动随荷载变化过程分为 3 个阶段，其中错动主要发生在第二阶段。弯矩传递试验表明弯矩传递系数随着荷载的增大而减小。并且当纵缝转角刚度较大时，弯矩传递系数较小，反之亦然。最后结合试验结果，给出了盾构隧道衬砌结构计算模型关键参数具体取值范围和一些 有益 的结论，以供盾构隧道衬砌结构设计计算参考。
    Abstract: The key parameters for models of lining structure of shield tunnels, such as bending stiffness of radial joint s, shear stiffness of radial ( circumferential ) joints and moment transfer coefficient , have always been the research focus in this field. The above key parameters are studied by means of the prototype load tests on segment joints in Qingcaosha Water Conveyance Project. The test results indicate that under sagging moments the bending stiffness coincides with the bilinear model, and under hogging moments it is similar to the linear model. The bending stiffness of radial joint and its variation law are different from those of various joint structures. According to the results from shear tests the dislocation change process of radial (circumferential) joint can be divided into three stages. The dislocation occurs mainly at the second stage. The results of moment transfer tests indicate that the moment transfer coefficient decreases with the increase of load. The greater the bending stiffness of radial joint is, the less the moment transfer coefficient is, and vice versa. Finally, based on the test results, the value range of the key parameters for the models of lining structure of shield tunnels is put forward. Several beneficial conclusions for the design of lining structure of shield tunnels are drawn.
    • HTML全文
    • 参考文献(13)
  • [1] 日本土木学会 , 隧道标准规范 ( 盾构篇 ) 及解说 [M]. 朱 伟 , 译 . 北京 : 中国建筑工业出版社 , 2001. ( Japanese Civil Engineering Institute. Shield tunnel design codes and explanation[M]. ZHU Wei, trans. Beijing: China Architecture & Building Press, 2001. (in Chinese))
    [2] 朱合华 , 陶履彬 . 盾构隧道衬砌结构受力分析的梁 - 弹簧系统模型 [J]. 岩土力学 , 1998, 19 (2): 26 – 32 . ( ZHU He-hua, TAO Lu-bin. Beam-spring system model for shield lining analysis[J]. Rock and Soil Mechanics, 1998, 19 (2): 26 – 32. (in Chinese))
    [3] 侯公羽 , 杨 悦 , 刘 波 . 盾构管片接头模型的改进及管片内力的数值计算 [J]. 岩石力学与工程学报 , 2007, 26 ( 增刊 2): 4284 – 4291. (HOU Gong-yu, YANG Yue, LIU Bo. Improved joint model of shield tunnel segments and numerical calculation of inner forces[J]. Chinese Journal of Rock Mechanics and Engineering, 2007, 26 (S2): 4284 – 4291. (in Chinese))
    [4] 胡志平 , 罗丽娟 , 蔡志勇 . 盾构隧道管片衬砌的平板壳 - 弹性铰 - 地基系统模型 [J]. 岩土力学 , 2005, 26 (9): 1403 – 1408. ( HU Zhi-ping, LUO Li-juan, CAI Zhi-yong. Study on flat shell-elastic hinge-foundation model in shield tunnel[J]. Rock and Soil Mechanics, 2005, 26 (9): 1403 – 1408. (in Chinese))
    [5] 朱 伟 , 黄正荣 , 梁精华 . 盾构衬砌管片的壳 - 弹簧设计模型研究 [J]. 岩土工程学报 , 2006, 28 (8): 940 – 947. ( ZHU Wei, HUANG Zheng-rong, LIANG Jing-hua. Studies on shell-spring design model for segment of shield tunnels[J]. Chinese Journal of Geotechnical Engineering, 2006, 28 (8): 940 – 947. (in Chinese) )
    [6] 苏宗贤 , 何 川 . 盾构隧道管片衬砌内力分析的壳 - 弹簧 - 接触模型及其应用 [J]. 工程力学 , 2007, 24 (10): 131 – 136. (SU Zong-xian, HE Chuan. Shell- spring - contact model for shield tunnel segmental lining analysis and its application[J]. Engineering Mechanics, 2007, 24 (10): 131 – 136. (in Chinese))
    [7] 村上博智ほか . シールド工事セダメントのセゲメント继手の拳动について [J]. 土木学会论文报告集 , 1980, 296 : 73 – 85. (Murakami Hirotomo. Study on the mechanical characteristic of segment joints in shield tunnel[J]. Paper Reports of Civil Society, 1980, 296 : 73 – 85. (in Japanese))
    [8] 陆同寿 , 崔铁军 . 圆形衬砌接头刚度模型试验与研究 [J]. 地下工程与隧道 , 1987, 8 (4): 21 – 23. (LU Tong-shou, CUI Tie-jun. Study and test on the joint stiffness of the circular lining[J]. Underground Engineering and Tunnels, 1987, 8 (4): 21 – 23. (in Chinese))
    [9] 张厚美 , 过 迟 , 付德明 . 圆形隧道装配式衬砌接头刚度模型研究 [J]. 岩土工程学报 , 2000, 22 (3): 309 – 313. (ZHANG Hou-mei, GUO Chi, FU De-ming. A study on stiffness model of circular tunnel prefabricated lining[J]. Chinese Journal of Geotechnical Engineering, 2000, 22 (3): 309 – 313. (in Chinese))
    [10] 张厚美 , 付德明 , 过 迟 . 盾构隧道管片接头荷载试验研究 [J]. 现代隧道技术 , 2002, 39 (6): 28 – 33. (ZHANG Hou-mei, FU De-ming, GUO Chi. Study on load test of segment joint in shield driven tunnel[J]. Modern Tunneling Technology, 2002, 39 (6): 28 – 33. (in Chinese))
    [11] 张厚美 , 叶均良 , 过 迟 . 盾构隧道管片接头抗弯刚度的经验公式 [J]. 现代隧道技术 , 2002, 39 (2): 12 – 16. (ZHANG Hou-mei, YE Jun-liang, GUO Chi. Empirical formula for bending stiffness of shield tunnel segment joint[J]. Modern Tunneling Technology, 2002, 39 (2): 12 – 16. (in Chinese))
    [12] 王 哲 , 李京爽 . 地铁管片环向接头弯曲刚度试验研究 [J]. 工业建筑 , 2005, 35 (1): 86 – 88. (WANG Zhe, LI Jing-shuang. Experimental research on bending stiffness of circumferential joint shield tunneling segment[J]. Industrial Construction, 2005, 35 (1): 86 – 88. (in Chinese))
    [13] 滕 丽 , 吕建中 . 通用管片接头荷载试验研究 [J]. 上海大学学报 ( 自然科学版 ), 2010, 16 (2): 216 – 220. (TENG Li, LÜ Jian-zhong. Load test on typical segment joints[J]. Journal of Shanghai University (Natural Science), 2010, 16 (2): 216 – 220. (in Chinese))
