密砂中圆形锚上拔承载力尺寸效应分析

陈榕, 符胜男, 郝冬雪, 史旦达

陈榕, 符胜男, 郝冬雪, 史旦达. 密砂中圆形锚上拔承载力尺寸效应分析[J]. 岩土工程学报, 2019, 41(1): 78-85. DOI: 10.11779/CJGE201901008
引用本文: 陈榕, 符胜男, 郝冬雪, 史旦达. 密砂中圆形锚上拔承载力尺寸效应分析[J]. 岩土工程学报, 2019, 41(1): 78-85. DOI: 10.11779/CJGE201901008
shu
CHEN Rong, FU Sheng-nan, HAO Dong-xue, SHI Dan-da. Scale effects of uplift capacity of circular anchors in dense sand[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(1): 78-85. DOI: 10.11779/CJGE201901008
Citation: CHEN Rong, FU Sheng-nan, HAO Dong-xue, SHI Dan-da. Scale effects of uplift capacity of circular anchors in dense sand[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(1): 78-85. DOI: 10.11779/CJGE201901008
shu

密砂中圆形锚上拔承载力尺寸效应分析  English Version

  • 1.东北电力大学建筑工程学院,吉林 吉林 132012;
    2.中国电力工程顾问集团东北电力设计研究院有限公司,吉林 长春 130021;
    3.上海海事大学海洋科学与工程学院,上海 201306

基金项目: 国家自然科学基金项目（51308095,51409045,41772273）;吉林省科技厅优秀青年人才基金项目（20170520105JH）
详细信息
    作者简介:

    陈 榕(1979- ),男,辽宁沈阳人,博士,副教授,主要从事输电线路基础承载特性及软土地基处理研究工作。E-mail: lg1316cih@126.com。

    通讯作者:

    郝冬雪，E-mail：haodongxue2005@126.com

  • 中图分类号: TU441.4

Scale effects of uplift capacity of circular anchors in dense sand

  • 1.School of Civil Engineering and Architecture, Northeast Electric Power University, Jilin 132012, China;
    2.Northeast Electric Power Design Institute Co., Ltd.of China Power Engineering Consulting, Changchun 130021, China;
    3.College of Ocean Science and Engineering, Shanghai Maritime University, Shanghai 201306, China

施引文献

    摘要
  • 摘要: 通过模型试验和有限单元法分析了密砂中圆形锚板上拔承载力的尺寸效应问题。分别对直径为20,50,400 mm的锚板在埋深比为2~6时进行拉拔试验,获得上拔力和位移关系曲线及极限上拔力。基于不同埋深比时板径与上拔承载力系数关系曲线,可发现：相同埋深比时,随着锚板直径增加,上拔承载力系数逐渐减小;且随着埋深比增加,此现象愈明显。考虑密砂强度随应变发展而出现的软化现象,对理想弹塑性Mohr-Coulomb模型进行改进,基于改进的模型对上述12个拉拔试验进行有限元数值模拟,同时与理想弹塑性模型模拟结果进行比较。结果表明：理想弹塑性模型严重高估锚板上拔承载力,而考虑土体软化的模型能够模拟锚板上拔过程中破坏面上土体强度逐渐发挥的过程,计算得到的极限承载力与试验结果吻合较好。尺寸效应产生的原因一方面由于应力水平对土体强度的影响,另一方面由渐进破坏引起;埋深比越大,随着锚板直径增加,周围土体依次进入破坏的过程愈加明显。
    Abstract: The scale effects of uplift capacity of circular anchors in dense sand are studied by means of the model tests and finite element method. The pullout tests on the circular anchors with the diameters of 20, 50 and 400 mm as well as the embedment ratios of 2~6 are carried out, where the curves of uplift resistance and displacement and ultimate uplift capacity are obtained. It is seen from the test results that the breakout factor decreases with the increase in anchor diameter under the same embedment ratio, and the phenomenon is more obvious with larger embedment ratio. Numerical analysis for the pullout tests is performed based on the modified Mohr-Coulomb model which can reflect the strain softening of dense sand, and the results are compared with those based on the elastic-perfectly plastic Mohr-Coulomb model. It is shown that the numerical results based on elastic-perfectly plastic model overestimate the uplift capacity of anchors remarkably, while the simulations based on the modified Mohr-Coulomb model can reveal the process of mobilizing soil strength to the peak value, and thus the numerical results agree well with the test ones. The reasons causing the scale effects are the soil strength dependent on stress level and the progressive failure during pullout. The process that the soils surrounding the anchors reach failure step by step becomes more and more obvious with the increase of anchor diameter when the embedment ratio is relatively large.
    • HTML全文
    • 参考文献(23)
  • [1] MURRAY E J, GEDDES J D.Uplift of anchor plates in sand[J]. Journal of Geotechnical Engineering, 1987, 113(3): 202-215.
    [2] GHALY A, HANNA A, HANNA M.Uplift behaviour of screw anchors in sand: І dry sand[J]. Journal of Geotehcnical Engineering, 1991, 117(5): 773-793.
    [3] LIU J Y, LIU M L, ZHU Z D.Sand deformation around an uplift plate anchor[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 2012, 138(6): 728-737.
    [4] OVESEN N K.Centrifuge tests of uplift capacity of anchor[C]// Proceedings of the 10th International Conference on Soil Mechanics and Foundation Engineering. Stockholm, 1981: 717-722.
    [5] TAGAYA K, SCOTT R F, ABOSHI H.Pullout resistance of buried anchor in sand[J]. Soils and Foundations, 1988, 28(3): 114-130.
    [6] DICKIN E A.Uplift beahvior of horizontal anchor plates in sand[J]. Journal of Geotechnical Engineering, ASCE, 1988, 114(11): 1300-1317.
    [7] SAKAI T, TANAKA T.Progressive failure and scale effect of trap-door problems with granular materials[J]. Japanese Society of Soil Mechanics and Foundation Engineering, 1993, 33(1): 11-222.
    [8] SAKAI T, TANAKA T.Scale effect of a shallow circular anchor in dense sand[J]. Soils and Foundations, 1998, 38(2): 93-99.
    [9] SAKAI T, TANAKA T.Experimental and numerical study of uplift behavior of shallow circular anchor in two-layered sand[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 2007, 133: 469-477.
    [10] GHALY A, HANNA A.Ultimate pullout resistance of single vertical anchors[J]. Canadian Geotechnical Journal, 1994, 31(5): 661-672.
    [11] 郝冬雪, 符胜男, 陈榕. 砂土中锚板拉拔模型试验及其抗拔力计算[J]. 岩土工程学报, 2015, 37(11): 2101-2106.
    (HAO Dong-xue, FU Sheng-nan, CHEN Rong, et al.Experimental investigation of uplift behavior of anchors and estimation of uplift capacity in sands[J]. Chinese Journal of Geotechnical Engineering, 2015, 37(11): 2101-2106. (in Chinese))
    [12] ROWE R K, DAVIS E H.The behaviour of anchor plates in sand[J]. Géotechnique, 1982, 32(1): 25-41.
    [13] TAGAYA K, TANAKA A, ABOSHI H.Application of finite element method to pullout resistance of buried anchor[J]. Soils and Foundations, 1983, 23(3): 91-104.
    [14] BHATTACHARYA P, KUMAR J.Uplift capacity of anchors in layered sand using finite-element limit analysis: formulation and results[J]. International Journal of Geomechanics, ASCE, 2016, 16(3): 1532-3641.
    [15] MERIFIELD R S, SLOAN S W.The ultimate pullout capacity of anchors in frictional soils[J]. Canadian Geotechnical Journal, 2006, 43: 852-868.
    [16] KUMAR J.Uplift response of strip anchors in sand using FEM[J]. Irinian Journal of Science and Technology, 2006, 30(4): 475-486.
    [17] KHATRI V N, KUMAR J.Effect of anchor on pullout capacity of strip anchors in sand[J]. Canadian Geotechnical Journal, 2011, 48: 511-547.
    [18] TATSUOKA F, GOTO S, SAKAMOTO M.Effects of some factors on strength and deformation characteristics of sand at low pressures[J]. Soils and Foundations, 1986, 26(1): 105-114.
    [19] ALSHIBLI K A, BATISTE S N, STURE S.Strain localization in sand: plane strain versus triaxial compression[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 2003, 129(6): 483-494.
    [20] ANDERSEN K H, SCHJETNE K.Database of friction angles of sand and consolidation characteristics of sand, silt, and clay[J]. Journal of Geotechnical and Geoenvironmental Engineering, ASCE, 2013, 139(7): 1140-1155.
    [21] BOLTON M D.Strength and dilatancy of sands[J]. Géotechnique, 1986, 36(1): 65-78.
    [22] HSU S T, LIAO H J.Uplift behaviour of cylindrical anchors in sand[J]. Canadian Geotechnical Journal, 1998, 34: 70-80.
    [23] JAKY J.Pressure in silos[C]// Proceedings of the 2nd International Conference on Soil Mechanics and Foundation Engineering. Rotterdam, 1948: 103-107.
