交通荷载作用下埋地承插口排水管道动力响应分析

王复明; 方宏远; 李斌; 陈灿

doi:10.11779/CJGE201812015

交通荷载作用下埋地承插口排水管道动力响应分析 English Version

王复明^1,2,3,
方宏远^1,2,3,,
李斌^1,2,3,
陈灿^1,2,3

1. 郑州大学水利与环境学院,河南郑州 450001;
2. 重大基础设施检测修复技术国家地方联合工程实验室,河南郑州 450001;
3. 水利与交通基础设施安全防护河南省协同创新中心,河南郑州 450001

基金项目: 国家重点研发计划（2016YFC0802400）; 河南省重大科技专项（171100310100）; 河南省高校科技创新团队支持计划资助项目（18IRTSTHN007）; 郑州大学优秀青年教师发展基金项目（1621323001）

详细信息

作者简介:
王复明(1957- ),教授,中国工程院院士,主要从事基础设施致灾机理与检测修复技术研究工作。E-mail: fuming573@126.com。

中图分类号: TU990.3
计量
- 文章访问数: 335
- HTML全文浏览量: 10
- PDF下载量: 189
出版历程
- 收稿日期: 2017-11-30
- 发布日期: 2018-12-24

Dynamic response analysis of drainage pipes with gasketed bell and spigot joints subjected to traffic loads

WANG Fu-ming^1,2,3,
FANG Hong-yuan^1,2,3,,
LI Bin^1,2,3,
CHEN Can^1,2,3

1. College of Water Conservancy & Environmental Engineering, Zhengzhou University, Zhengzhou 450001, China;
2. National Local Joint Engineering Laboratory of Major Infrastructure Testing and Rehabilitation Technology, Zhengzhou 450001, China;
3. Collaborative Innovation Center of Water Conservancy and Transportation Infrastructure Safety, Zhengzhou 450001, China

摘要

摘要: 近年来,由于市政排水管道灾变导致的道路坍塌事故频发,水泥混凝土管是目前应用最为广泛的市政排水管道,其在交通荷载作用下的力学响应特征尚不明确。基于ABAQUS有限元软件,建立了带承插口结构排水管道三维数值模型。在考虑承插口、橡胶圈和无限元吸收边界等的基础上计算分析了不同脉冲幅值、不同荷载作用位置和不同管道埋深对管道动力响应的影响。结果表明：管节处受力高度不连续,交通荷载对其作用位置两侧一节管长范围内的管道影响显著;承口和插口环向以受拉和受压为主;交通荷载作用位置对管顶、管底和管侧纵向Mises应力最大值无明显影响,但对管顶和管底纵向Mises应力分布有影响;管道纵向Mises应力及环向竖向应力与管道埋深成正比,应力增量与埋深增量成反比。计算结果为进一步研究交通荷载作用下排水管道的力学机理提供参考。
- 排水管道 /
- 承插口 /
- 橡胶圈 /
- 脉冲荷载 /
- 动力响应
Abstract: In recent years, the road collapse accidents caused by the disasters of municipal drainage pipelines occurred frequently. The concrete pipe is the most widely used in municipal drainage, but its mechanical characteristics under the action of traffic loads are not clear. A three-dimensional numerical model for drainage pipe structures with gasketed bell and spigot joints is established using ABAQUS. The influences of different pulse amplitudes, load positions and pipe buried depths on the dynamic responses of drainage pipes are calculated and analyzed considering the bell, spigot, rubber and infinite element absorption boundary. The results show that the stresses on the joints are highly discontinuous, and the traffic loads have significant influences on the pipes within one pipe length at both sides of its position. The circumference of the bell and spigot is mainly subjected to tension and compression stress. The position of traffic loads has no significant effects on the maximum Mises stress in the crown, invert and springline, but has influences on the Mises stress distribution of the crown and invert. The longitudinal and circumferential stresses are proportional to the buried depth, however, the stress increment is inversely proportional to the depth one.
- drainage pipe /
- bell and spigot joint /
- rubber /
- impulsive load /
- dynamic response

HTML全文

参考文献(21)

[1]	LAY G R, BRACHMAN R W I. Full-scale physical testing of a buried reinforced concrete pipe under axle load[J]. Canadian Geotechnical Journal, 2013, 51(4): 394-408.
[2]	NOOR M A, DHAR A S.Three-dimensional response of buried pipe under vehicle loads[C]// New Pipeline Technologies, Security, and Safety. Baltimore, 2003.
[3]	FERNANDO N S M, CARTER J P. Elastic analysis of buried pipes under surface patch loadings[J]. Journal of Geotechnical and Geoenvironmental Engineering, 1998, 124(8): 720-728.
[4]	吴小刚, 吴军, 宋洁人. 交通载荷下管道的位移响应分析初探[J]. 仪器仪表学报, 2006, 27(6): 14-15. (WU Xiao-gang, WU Jun, SONG Jie-ren.The analysis on displacement respond of the pipelines under traffic loads[J]. Chinese Journal of Scientific Instrument, 2006, 27(6): 14-15. (in Chinese))
[5]	张土乔, 邵煜. 交通荷载作用下饱和土中管道的动力分析[J]. 浙江大学学报(工学版), 2007, 41(1): 48-51. (ZHANG Tu-qiao, SHAO Yu.Dynamic analyses of pipes in saturat soil under traffic loads[J]. Journal of Zhejiang University (Engineering Science), 2007, 41(1): 48-51. (in Chinese) )
[6]	李洵. 交通荷载作用下埋地管道的力学性状分析[D]. 杭州: 浙江大学, 2004. (LI Xun.Analysis on mechanical characteristics of pipelines buried in soft soil under transportation loads[D]. Hangzhou: Zhejiang University, 2004. (in Chinese))
[7]	王直民. 交通荷载作用下埋地管道的力学性状研究[D]. 杭州: 浙江大学, 2006. (WANG Zhi-min.Study on mechanical behaviors of buried pipelines under traffic loads[D]. Hangzhou: Zhejiang University, 2006. (in Chinese))
[8]	RAKITIN B, XU M.Centrifuge testing to simulate buried reinforced concrete pipe joints subjected to traffic loading[J]. Canadian Geotechnical Journal, 2015, 52(11): 1762-1774.
[9]	XU M, SHEN D, RAKITIN B.The longitudinal response of buried large-diameter reinforced concrete pipeline with gasketed bell and spigot joints subjected to traffic loading[J]. Tunnelling and Underground Space Technology, 2017, 64: 117-132.
[10]	BECERRIL GARCÍA D, MOORE I D. Behaviour of bell and spigot joints in buried reinforced concrete pipelines[J]. Canadian Geotechnical Journal, 2014, 52(5): 609-625.
[11]	张浩, 杨玲, 郭院成. 交通荷载作用下低填道路软土地基的动力响应分析[J]. 郑州大学学报 (工学版), 2017, 38(1): 11-15. (ZHANG Hao, YANG Ling, GUO Yuan-cheng.Analysis of dynamic response of soft soil foundation beneath low embankment under traffic load[J]. Journal of Zhengzhou University (Engineering Science), 2017, 38(1): 11-15. (in Chinese))
[12]	GB/T 11836—2009 混凝土路和钢筋混凝土排水管[S]. 2009. (GB/T 11836—2009 Concrete and reinforced concrete sewer pipes[S]. 2009. (in Chinese))
[13]	LEE J, FENVES G L.Plastic-damage model for cyclic loading of cement structures[J]. Journal of Engineering Mechanics, 1998, 124(8): 892-900.
[14]	GB/T 21873—2008 橡胶密封件给、排水管及污水管道用接口密封圈材料规范[S]. 2008. (GB/T 21873—2008 Rubber seals-joint rings for water supply drainage and sewerage pipeline specification for material[S]. 2008. (in Chinese))
[15]	张世杰. 管道橡胶密封圈力学性能试验研究与数值模拟[D]. 郑州: 河南工业大学, 2013. (ZHANG Shi-jie.Experimental research and numerical simulation of the mechanical properties of the pipe rubber seals[D]. Zhengzhou: Henan University of Technology, 2013. (in Chinese))
[16]	刘全林, 杨敏. 地埋管与土相互作用分析模型及其参数确定[J]. 岩土力学, 2004, 25(5): 728-731. (LIU Quan-lin, YANG Min.Analytical model and parameters determination of interaction between buried pipe and soil[J]. Rock and Soil Mechanics, 2004, 25(5): 728-731. (in Chinese))
[17]	WANG J, YANG Z.Axial friction response of full-scale pipes in soft clays[J]. Applied Ocean Research, 2016, 59: 10-23.
[18]	JTGD60—2004 公路桥涵设计通用规范[S]. 2004. (JTG D60—2004. General specification for design of highway bridge and culvert D60—2004. General specification for design of highway bridge and culvert[S]. 2004. (in Chinese))
[19]	HYODO M, YASUHARA K.Analytical procedure for evaluating pore-water pressure and deformation of saturated clay ground subjected to traffic loads[C]// Proceedings of the Sixth International Conference on Numerical Methods in Geomechanics. Innsbruck, 1988.
[20]	侯芸, 郭忠印, 田波, 等. 动荷载作用下沥青路面结构的变形响应分析[J]. 中国公路学报, 2002, 15(3): 6-10. (HOU Yun, GUO Zhong-yin, TIAN Bo, et al.Dynamic deflection response of layered pavement structure subjected to dynamic load[J]. China Journal of Highway and Transport, 2002, 15(3): 6-10. (in Chinese))
[21]	魏翠玲, 王复明, 周晶. FWD 无损检测数值的动态分析[J]. 岩土工程学报, 1999, 21(4): 495-497. (WEI Cui-ling, WANG Fu-ming, ZHOU Jing.Dynamic analysis of FWD nondestructive test data[J]. Chinese Journal of Geotechnical Engineering, 1999, 21(4): 495-497. (in Chinese))
