水平地震作用下双级加筋土挡墙格栅应变及破裂面分析

蔡晓光, 李思汉, 黄鑫

蔡晓光, 李思汉, 黄鑫. 水平地震作用下双级加筋土挡墙格栅应变及破裂面分析[J]. 岩土工程学报, 2018, 40(8): 1528-1534. DOI: 10.11779/CJGE201808020
引用本文: 蔡晓光, 李思汉, 黄鑫. 水平地震作用下双级加筋土挡墙格栅应变及破裂面分析[J]. 岩土工程学报, 2018, 40(8): 1528-1534. DOI: 10.11779/CJGE201808020
shu
CAI Xiao-guang, LI Si-han, HUANG Xin. Geogrid strain and failure surface of two-stage reinforced soil retaining wall under horizontal seismic loading[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(8): 1528-1534. DOI: 10.11779/CJGE201808020
Citation: CAI Xiao-guang, LI Si-han, HUANG Xin. Geogrid strain and failure surface of two-stage reinforced soil retaining wall under horizontal seismic loading[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(8): 1528-1534. DOI: 10.11779/CJGE201808020
shu

水平地震作用下双级加筋土挡墙格栅应变及破裂面分析  English Version

  • 防灾科技学院防灾工程系,河北 三河 065201

基金项目: 国家自然科学基金面上项目（51778144）; 地震科技星火计划项目（XH14073Y）; 中央高校基本科研业务费研究生科技创新基金项目（ZY20170305）
详细信息
    作者简介:

    蔡晓光(1979- ),男,教授,主要从事挡土结构抗震及尾矿库动力分析等方面的研究工作。E-mail：caixiaoguang123@163.com。

Geogrid strain and failure surface of two-stage reinforced soil retaining wall under horizontal seismic loading

  • Disaster Prevention Engineering Department, Institute of Disaster Prevention, Sanhe 065201, China

HTML全文

    摘要
  • 摘要: 基于大型振动台模型试验,研究水平地震荷载作用下双级土工格栅加筋土挡墙的格栅应变和潜在破裂面规律。用福建砂作为回填砂、混凝土砌块作为挡墙和土工格栅作为筋材构成了试验模型。模型高度1.8 m。输入地震波为卧龙波和EL-Centro波,共9个试验工况。试验结果表明,随着峰值加速度增大,应变值增大,且应变最大值点向土体内部扩展。潜在破裂面随峰值加速度增加逐渐向土体内部扩展。综合已有破裂面计算方法,提出了考虑平台宽度的双级折线型破裂面模型,模型可为双级加筋土挡墙设计计算提供参考。
    Abstract: Based on the large-scale shaking table model tests, the geogrid strain and failure surface of two-stage reinforced soil-retaining wall under horizontal seismic loading are studied. The experimental model is made of backfill, retaining wall and geosynthetics, where the backfill is standard soil, the retaining wall is concrete blocks and the geosynthetics is geogrid. The model height is 1.8 m. The input seismic waves are Wolong waves and EL-Centro waves. The test results show that with the increase of the peak acceleration, the strain value increases, and the maximum strain point extends to the soil interior. With the increase of the peak acceleration, the potential rupture surface gradually extends to the soil interior. Based on the existing methods for calculating the fracture surface, a double-broken line model considering the width of the offset is proposed. The proposed model can be used as a reference for the design of the two-stage reinforced soil retaining wall.
    • HTML全文
    • 参考文献(14)
  • [1] 王丽艳, 孙田, 陈苏. 近远场地震中土工格栅加筋土挡墙抗震特性的振动台试验研究[J]. 土木工程学报, 2015, 48(2): 103-110.
    (WANG Li-yan, SUN Tian, CHEN Su.Large scale shaking table test on seismic behaviors of geogrid reinforced retaining walls under near-fault and far-fault ground motions[J]. China Civil Engineering Journal, 2015, 48(2): 103-110. (in Chinese))
    [2] 雷胜友. 双面加筋土高挡墙的离心模型试验[J]. 岩石力学与工程学报, 2006, 24(3): 417-423.
    (LEI Sheng-you.Centrifugal modelling of high double-face reinforced earth retaining wall[J]. Chinese Journal of Rock mechanics and Engineering, 2006, 24(3): 417-423. (in Chinese))
    [3] GB/T 50290—2014土工合成材料应用技术规范[S]. 2014.
    (GB/T 50290—2014 Technical code for application of geosynthetics[S]. 2014. (in Chinese))
    [4] FHWA-NHI-10-024.Design and construction of mechanically stabilized earth walls and reinforced soil slopes-volume I[S]. America: US Department of Transportation Federal Highway Administration, 2009.
    [5] 王祥, 徐林荣. 双级土工格栅加筋土挡墙的测试分析[J].岩土工程学报, 2003, 25(2): 220-224.
    (WANG Xiang, XU Lin-rong.Test and analysis of two-step retaining wall reinforced by geogrid[J]. Chinese Journal of Geotechnical Engineering, 2003, 25(2): 220-224. (in Chinese))
    [6] JTG D30—2015公路路基设计规范[S]. 2015.
    (JTG D30—2015 Specifications for design of highway subgrades[S]. 2015. (in Chinese))
    [7] TB 10025—2015 铁路路基支挡结构设计规范[S]. 2015.
    (TB 10025—2015 Code for design on retaining structures of railway subgrades[S]. 2015. (in Chinese))
    [8] 高江平, 俞茂弘, 胡长顺, 等. 加筋土挡墙滑动破裂面的大型模型试验[J]. 长安大学学报(自然科学版), 2005, 25(6): 6-9.
    (GAO Jiang-ping, YU Mao-hong, HU Chang-shun, et al.Large model experiment on sliding rupture of reinforced earth retaining wall[J]. Journal of Chang'an University (Natural Science Edition), 2005, 25(6): 6-9. (in Chinese))
    [9] 黄向京, 许桂林, 彭立. 加筋格宾组合式挡墙破裂面及承载力特性[J]. 中国公路学报, 2011, 24(6): 31-38.
    (HUANG Xiang-jing, XU Gui-lin, PENG Li.Failure surface and bearing capacity character of combined reinforced gabion retaining wall[J]. China Journal of Highway and Transport, 2011, 24(6): 31-38. (in Chinese))
    [10] 王维, 黄向京, 许桂林, 等. 加筋格宾挡墙破裂面及承载力特性研究[J]. 铁道科学与工程学报, 2010, 7(6): 43-49.
    (WANG Wei, HUANG Xiang-jing, XU Gui-lin, et al.Study on the failure surface and the bearing capacity character of reinforced gabion retaining wall[J]. Journal of Railway Science and Engineering, 2010, 7(6): 43-49. (in Chinese))
    [11] BS 8006-1 2010. Code of practice for strengthened/reinforced soils and other fillsS 8006-1 2010. Code of practice for strengthened/reinforced soils and other fills[S]. 2010.
    [12] 周世良, 汪承志, 何光春, 等. 台阶式格栅加筋挡墙潜在破裂面计算模式研究[J]. 公路交通科技, 2007, 24(11): 15-20.
    (ZHOU Shi-liang, WANG Cheng-zhi, HE Guang-chun, et al.Study on rational model of potential fractured surface for stepped geogrid reinforced soil retaining wall[J]. Journal of Highway and Transportation Research and Development, 2007, 24(11): 15-20. (in Chinese))
    [13] 西南交通大学研究组. 国道G213加筋土结构震害统计报告[R]. 成都: 西南交通大学, 2009.
    (Study Group of Southwest Jiaotong University. Seismic damage statistical report about reinforcement earth structure on national highway G213[R]. Chengdu: Southwest Jiaotong University, 2009. (in Chinese))
    [14] 曹礼聪, 张建经, 付晓, 等. 条带式刚性面板加筋土挡墙筋带应变响应特性研究[J]. 岩石力学与工程学报, 2017, 36(7): 1768-1779.
    (CAO Li-cong, ZHANG Jian-jing, FU Xiao, et al.Strain response of the stripe reinforced soil with rigid retaining wall[J]. Chinese Journal of Rock Mechanics and Engineering, 2017, 36(7): 1768-1779. (in Chinese))
