断裂黏滑错动下隧道减错措施作用效果模型试验研究

王道远; 崔光耀; 袁金秀; 朱永全; 朱正国; 李冬; 王洪凡

doi:10.11779/CJGE201808018

断裂黏滑错动下隧道减错措施作用效果模型试验研究 English Version

王道远^{1, 2, 3},
崔光耀⁴,
袁金秀^2, ,,
朱永全^{1, 3},
朱正国¹,
李冬²,
王洪凡²

1. 石家庄铁道大学土木工程学院,河北石家庄 050043;
2. 河北交通职业技术学院土木工程系,河北石家庄 050091;
3. 西南交通大学交通隧道工程教育部重点实验室,四川成都 610031;
4. 北方工业大学土木工程学院,北京 100144

基金项目: 国家自然科学基金项目（51408008,51478277）; 四川省应用基础研究计划项目（2014JY0090,2015JY0166）; 河北省自然科学基金项目（E201619002）; 河北省人才工程培养经费资助科研项目（A201500116）; 河北省高等学校科学技术研究青年基金项目（QN2016240）; 北方工业大学青年拔尖人才培育计划项目（XN131）

详细信息

作者简介:
王道远(1982- ),男,副教授,主要从事隧道与地下工程的教学与研究工作。E-mail：wtg-888@163.com。

通讯作者:
袁金秀，E-mail：xiugirl2007@163.com

计量
- 文章访问数: 288
- HTML全文浏览量: 14
- PDF下载量: 170
出版历程
- 收稿日期: 2017-04-25
- 发布日期: 2018-08-24

Model tests on effect of dislocation reducing measures of stick-slip fault of tunnels

1. School of Civil Engineering, Shijiazhuang Tiedao University, Shijiazhuang 050043, China;
2. Department of Civil Engineering, Hebei Jiaotong Vocational and Technical College, Shijiazhuang 050091, China;
3. Key Laboratory of Transportation Tunnel Engineering,Ministry of Education,Southwest Jiaotong University, Chengdu 610031, China;
4. School of Civil Engineering, North China University of Technology, Beijing 100144, China

摘要

摘要: 以某隧道工程为依托,开展断裂黏滑错动下隧道减错措施大型模型试验。通过分析纵向应变、接触压力和衬砌安全系数,对无减错措施、仅设置减错层、仅二衬设置减错缝、二衬设置减错缝与影响区段二衬增厚、初支与二衬交错设置减错缝以及组合措施6种工况进行对比研究。结果表明：断裂黏滑错动对上盘的影响范围和剧烈程度均大于下盘;不同工况减错措施对纵向变形、接触压力以及结构受力控制水平分别为A << C≈D≈ B < E < F,A << B < D< C ≈ E ≈ F,A <
- 隧道 /
- 断裂黏滑 /
- 减错措施 /
- 交错设缝 /
- 模型试验
Abstract: Based on a tunnel project, large-scale model tests are carried out on anti-seismic and damping measures for dislocation of stick-slip fault. By analyzing longitudinal strain, contact pressure and safety factor of linings, the anti-seismic and damping effects are comparatively studied under six kinds of working conditions of A (no dislocation reducing measures), B (dislocation reducing layer), C (dislocation reducing joint for secondary lining), D (dislocation reducing joint and increasing thickness for secondary lining), E (interleaving setting of dislocation reducing joint) and F (combined dislocation reducing measures). The results show that the scope of the impact and intensity of stick-slip dislocation on hanging wall is greater than that on footwall. The control effect of the longitudinal deformation from low to high is A << C≈D≈ B < E < F, that of the contact pressure is A << B < D< C ≈ E ≈ F, and that of the structural stress is A <
Keywords:
tunnel /

stick-slip fault /

dislocation reducing measure /

interleaving setting of dislocation reducing joint /

model test
