RT模式下考虑主应力偏转的刚性挡墙地震主动土压力

张雯萍; 周亦涛; 俞 缙; 刘士雨; 蔡燕燕; 余 闯

doi:10.11779/CJGE201808016

RT模式下考虑主应力偏转的刚性挡墙地震主动土压力 English Version

张雯萍¹,
周亦涛²,
俞缙^1,3,
刘士雨¹,
蔡燕燕^1,3,
余闯⁴

1.华侨大学福建省隧道与城市地下空间工程技术研究中心, 福建厦门361021;
2.河北水利电力学院交通工程系, 河北沧州061001;
3. 中国矿业大学深部岩土力学与地下工程国家重点实验室,江苏徐州 221008;
4. 温州大学建筑工程学院,浙江温州 325035

基金项目: 国家自然科学基金项目（51774147,51679093）; 深部岩土力学与地下工程国家重点实验室开放基金项目（SKLGDUEK1701）; 2015年度福建省高校新世纪优秀人才支持计划项目; 福建省自然科学基金项目（2017J01094,2015J01210）

详细信息

作者简介:
张雯萍(1992- ),女,河南洛阳人,硕士研究生,主要从事岩土力学与地基处理等方面的研究工作。E-mail：zhangwxwz@163.com。

计量
- 文章访问数: 301
- HTML全文浏览量: 8
- PDF下载量: 134
出版历程
- 收稿日期: 2017-07-16
- 发布日期: 2018-08-24

Seismic active earth pressures on rigid retaining walls under RT mode considering rotation of principal stresses

1. Fujian Research Center for Tunneling and Urban Underground Space Engineering, Xiamen 361021, China;
2. Department of Transportation Engineering, Hebei University of Water Resources and Electric Engineering, Cangzhou 061001, China;
3. Department of Geotechnical Engineering, China Institute of Water Resources and Hydropower Research, Beijing 100048, China;
4. School of Civil Engineering, Wenzhou University, Wenzhou 325035, China

摘要

摘要: 依据拟静力学理论,考虑主应力偏转的影响,推导了绕墙顶转动模式（RT模式）下的地震主动土压力的计算公式。通过旋转挡土墙的解析模型,将地震问题转化为静力问题,并根据库仑土压力理论得到地震主动破裂角。在此基础上改进圆弧形小主应力偏转迹线,利用摩尔应力圆得到了RT模式下地震主动侧压力系数和水平微元土层间摩擦系数公式,提出基于微分薄层法的地震主动土压力解析式。分析了主要参数对地震主动破裂角、地震主动侧压力系数、水平微元土层间摩擦系数、地震主动土压力分布和侧向土压力作用位置的影响。将解析结果与其他土压力理论及试验数据进行对比,结果表明本文方法更为可靠。
- 主应力偏转 /
- 刚性挡墙 /
- 绕墙顶转动 /
- 地震主动土压力 /
- 地震主动破裂角 /
- 拟静力法
Abstract: Considering the rotation of the principal stresses, new formulae for seismic active pressures on rigid retaining walls under rotation about top (RT mode) are derived by the pseudo-static method. Through the rotation model, the calculation of seismic active earth pressures by the pseudo-static method is transforming into that of static active earth pressures, and the seismic active rupture angle is obtained by means of the Coulomb earth pressure theory. According to the Mohr stress circle and the improved circular arc trajectory of the minor principal stresses being a circular arch, the coefficients of the lateral seismic active earth pressures and the horizontal interfacial frictions are proposed under RT mode. Then based on the force equilibrium of the differential sliding backfill element, the formula for the seismic active earth pressures on the rigid retaining wall under rotation about top is obtained. Moreover, the effects of influence parameters on the seismic active rupture angle, lateral seismic active earth pressure and its coefficient, horizontal interfacial friction coefficient, resultant of the seismic active earth pressure and height of its application are discussed. And comparisons of the predicted values by the proposed method and other methods are carried out as well as model tests, and it is shown that the proposed method is more reasonable and effective than other methods.
- principal stress rotation /
- rigid retaining wall /
- rotation about wall top /
- seismic active earth pressure /
- seismic active rupture angle /
- pseudo-static method

HTML全文

参考文献(24)

[1]	OKABE S.General theory of earth pressure[J]. Journal of the Japanese society of Civil Engineers, 1926, 12(1): 123-134.
[2]	MONONOBE N, MATSUO H.On the determination of earth pressure during earthquakes[C]// Proceedings of the World Engineering Conference. Tokyo, 1929: 179-187.
[3]	SHERIF M A, FANG Y S.Dynamic earth pressure on walls rotation about top[J]. Soils and Foundations, 1984, 24(4): 109-117.
[4]	ISHIBASHI I, FANG Y S.Dynamic earth pressures with different wall movement modes[J]. Soils and Foundations, 1987, 27(4): 11-22.
[5]	KHOSRAVI M H, PIPATPONGSA T, TAKEMURA J.Experimental analysis of earth pressure against rigid retaining walls under translation mode[J]. Géotechnique, 2013, 63(12): 1020-1028.
[6]	CHOUDHURY D, SINGH S.New approach for estimation of static and seismicactive earth pressure[J]. Geotechnical and Geological Engineering, 2006, 24: 117-127.
[7]	CALTABIANO S, CASCONE E, & MAUGERI M. Static and seismic limit equilibrium analysis of sliding retaining walls under different surcharge conditions[J]. Soil Dynamics and Earthquake Engineering, 2012, 37(6): 38-55.
[8]	ISKANDER M, CHEN Z, OMIDVAR M, et al.Active static and seismic earth pressure for c-φ soils[J]. Soils and Foundations, 2013, 53: 639-652.
[9]	GHOSH S, DEBNATH C.Pseudo-static analysis of reinforced earth retaining wall considering non-linear failure surface[J]. Geotechnical and Geological Engineering, 2016, 34(4): 981-990.
[10]	林宇亮, 杨果林, 赵炼恒, 等. 地震动土压力水平层分析法[J]. 岩土力学, 2010, 29(12): 2581-2591. (LIN Yu-liang, YANG Guo-lin, ZHAO Lian-heng, et al.Horizontal slices analysis method for seismic earthpressure calculation[J]. Rock and Soil Mechanics, 2010, 29(12): 2581-2591. (in Chinese))
[11]	孙勇. 地震条件下挡土墙主动土压力及其分布的统一解[J]. 岩土力学, 2012, 33(1): 255-261. (SUN Yong.Unified solution of seismic active earth pressure and its distribution on a retaining wall[J]. Rock and Soil Mechanics, 2012, 33(1): 255-261. (in Chinese))
[12]	张国祥. 地震条件下挡土墙主动土压力及其分布的新分析法[J]. 岩土力学, 2014, 35(2): 334-338. (ZHANG Guo-xiang.New analysis method of seismic active earth pressure and its distribution on a retaining wall[J]. Rock and Soil Mechanics, 2014, 35(2): 334-338. (in Chinese))
[13]	张国祥, 王敏. 新建筑边坡规范地震主动土压力计算公式的推导及完善[J]. 岩土力学, 2017, 38(4): 1097-1102. (ZHANG Guo-xiang, WANG Min.Derivation and improvement of formula for calculating seismic active earth pressure in new “Technical code for building slope engineering”[J]. Rock and Soil Mechanics, 2017, 38(4): 1097-1102. (in Chinese))
[14]	卢坤林, 杨扬, 朱大勇, 等. 考虑土拱效应的挡土墙地震土压力及其分布[J]. 水电能源科学, 2010, 28(5): 65-68. (LU Kun-lin, YANG Yang, ZHU Da-yong, et al.Seismic earth pressure on retaining wall considering soil arching effects and its distribution[J]. Water Resources and Power, 2010, 28(5): 65-68. (in Chinese))
[15]	侯键, 夏唐代, 陈炜昀, 等. 考虑土拱效应的挡土墙地震主动土压力静力研究[J]. 岩石力学与工程学报, 2013, 32(增刊1): 2825-2832. (HOU Jian, XIA Tang-dai, CHEN Wei-yun, et al.Static study of seismic active earth pressure on retaining walls considering soil arching effect[J]. Chinese Journal of Rock Mechanics and Engineering, 2013, 32(S1): 2825-2832. (in Chinese))
[16]	黄睿, 夏唐代. 无黏性土的地震主动土压力水平层法改[J]. 哈尔滨工业大学学报, 2014, 46(2): 85-91. (HUNG Rui, XIA Tang-dai.Improved horizontal slice method for seismic active earth pressure of cohesionless soil[J]. Journal of Harbin Institute of Technology, 2014, 46(2): 85-91. (in Chinese))
[17]	HANDY R L.The arch in soil arching[J]. Journal of Geotechnical Engineering, 1985, 111(3): 302-318.
[18]	蒋波, 应宏伟, 谢康和. 挡土墙后土体拱效应分析[J]. 浙江大学学报 (工学版), 2005, 39(1): 131-136. (JIANG Bo, YING Hong-wei, XIE Kang-he.Arching effect behind retaining wall[J]. Journal of Zhejiang University (Engineeing Science), 2005, 39(1): 131-136. (in Chinese))
[19]	CAI Y, CHEN Q, ZHOU Y, et al.Estimation of passive earth pressure against rigid retaining wall considering arching effect in cohesive-frictional backfill under translation mode[J]. International Journal of Geomechanics, 2016:04016093.
[20]	俞缙, 周亦涛, 蔡燕燕, 等. 基于土拱效应的刚性挡墙墙后主动土压力[J]. 岩土工程学报, 2013, 35(12): 2306-2310. (YU Jin, ZHOU Yi-tao, CAI Yan-yan, et al.Active earth pressure for rigid retaining wall considering soil arching effect[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(12): 2306-2310. (in Chinese))
[21]	ZHOU Y, CHEN Q, CHEN F, et al.Active earth pressure on translating rigid retaining structures considering soil arching effect[J]. European Journal of Environmental and Civil Engineering, 2016: 1-17.
[22]	GOEL S, PATRA N R.Effect of arching on active earth pressures for rigid retaining walls considering translation mode[J]. International Journal of Geomechanics, 2008, 8(2): 123-133.
[23]	张永兴, 陈林. 地震作用下挡土墙主动土压力分布[J]. 深圳大学学报 (理工版), 2012, 29(1): 31-37. (ZHANG Yong-xing, CHEN Lin.Seismic active earth pressure of retaining wall[J]. Journal of Shenzhen University (Science and Engineering), 2012, 29(1): 31-37. (in Chinese))
[24]	彭述权, 周健, 樊玲, 等. 考虑土拱效应刚性挡墙土压力研究[J]. 岩土力学, 2008, 29(10): 2701-2707. (PENG Shu-quan, ZHOU Jian, FAN Ling, et al.Research on earth pressure of rigid retaining wall considering soil arching[J]. Rock and Soil Mechanics, 2008, 29(10): 2701-2707. (in Chinese))
