长壁采空区对采动煤岩应力分布规律的影响研究

王朋飞; 冯国瑞; 赵景礼; CHUGHYoginderP; 王志强

doi:10.11779/CJGE201807010

长壁采空区对采动煤岩应力分布规律的影响研究 English Version

1. 太原理工大学矿业工程学院,山西太原 030024;
2. 中国矿业大学(北京)资源与安全工程学院,北京 100083;
3. 俄罗斯自然科学院,莫斯科 119991;
4. 美国南伊利诺伊大学采矿与矿物工程学院,卡本戴尔 62901;
5. 美国发明家学会,佛罗里达 33612

基金项目: 国家自然科学基金青年科学基金项目（51404270）; 国家留; 学基金委项目（201506430011）

详细信息

作者简介:
王朋飞(1988- ),男,博士,讲师,主要从事采矿与岩石力学方面的研究。E-mail: 18801448768@163.com。

中图分类号: TU456
计量
- 文章访问数: 297
- HTML全文浏览量: 19
- PDF下载量: 215
出版历程
- 收稿日期: 2017-04-02
- 发布日期: 2018-07-24

Effect of longwall gob on distribution of mining-induced stress

1. College of Mining Technology, Taiyuan University of Technology, Taiyuan, 030024, China;
2. School of Resources and Safety Engineering, China University of Mining and Technology (Beijing), Beijing 100083, China;
3. Russian Academy of Natural Sciences, Moscow 119991, Russia;
4. Mining and Mineral Resources Engineering, Southern Illinois University, Carbondale, Illinois 62901, USA;
5. National Academy of Inventors, 33612, Florida, USA

摘要

摘要: 随着当前各类长壁采空区及其附近区段巷道留设技术的不断推广,采空区及其对采动煤岩应力分布规律影响的认识愈发重要。鉴于当下此方面的研究较少,以镇城底矿为工程背景,通过理论分析、相似模拟、数值模拟和现场实测研究了长壁采空区对采动煤岩应力分布规律的影响。多种研究方法表明,采空区承载越大,实体围岩受载则越低,反之亦然。错层位不对称工作面导致应力分布亦不对称,缓坡段采空区应力大于无缓坡段,而缓坡段侧支承压力小于无缓坡段侧,缓坡段具有压力和能量缓冲耗散作用的矸石垫层,可避免接续面巷顶沿空巷道受动载影响。得出基于采空区影响下的老顶关键块回转下沉量计算方法。断裂角越小,采空区承载越小,尤其采空区边缘应力越小。采空区会影响围岩体中应力集中区的应力集中程度、范围和方位,同时影响煤岩体塑性区大小。理论分析、模拟分析和现场实测具有较好的一致性。
- 采空区 /
- 采动应力 /
- 错层位 /
- 不对称 /
- 断裂角
Abstract: With the development of a variety of gateroads within or close to gob, the effect of gob on the distribution of mining-induced stress is increasingly important. In view of the fact that the studies in this respect are few, Zhenchengdi colliery is investigated through theoretical analysis, physical modelling, numerical modelling and field observation. Several research means show that the more load the gob bears, the less the abutment pressure and vice versa. The longwall mining with split-level gateroad (LMSG) has an asymmetrical panel geometry, which results in asymmetrical stress distribution. It has larger gob stress and smaller abutment stress on elevating section side and smaller gob stress and larger abutment stress on non-elevating section side. The caved rock cushion is conductive to avoiding dynamic ground pressure behavior for the LMSG gob-side entry. The method for calculating the subsidence and rotation of the key blocks based on gob effect is obtained. The smaller the angle of break, the smaller the gob pressure and the smaller the gob edge pressure. The gob affects the stress concentration degree, the area and location of the stress concentration zones as well as the area of the yielded zone. The theoretical analysis, physical modelling, numerical modelling and field observation have a good consistency.
- gob /
- mining-induced stress /
- split-level /
- asymmetry /
- angle of break
