节理岩体中锚杆剪切力学模型研究及试验验证

刘泉声; 雷广峰; 彭星新; 魏莱

doi:10.11779/CJGE201805003

节理岩体中锚杆剪切力学模型研究及试验验证 English Version

刘泉声^{1, 2},
雷广峰^1,3,,
彭星新^{1, 3},
魏莱^{1, 3}

1. 中科院武汉岩土力学研究所岩土力学与工程国家重点实验室,湖北武汉 430071;
2. 武汉大学岩土与结构工程安全湖北省重点实验室,湖北武汉 430072;
3. 中国科学院大学,北京 100049

详细信息

作者简介:
刘泉声(1962- ),男,博士,研究员,博士生导师,主要从事岩石工程方面的教学与研究工作。E-mail：liuqs@whrsm.ac.cn。

计量
- 文章访问数: 437
- HTML全文浏览量: 14
- PDF下载量: 333
出版历程
- 修回日期: 2017-03-13
- 发布日期: 2018-05-24

Shearing mechanical model and experimental verification of bolts in jointed rock mass

LIU Quan-sheng^{1, 2},
LEI Guang-feng^1,3,,
PENG Xing-xin^{1, 3},
WEI Lai^{1, 3}

1. State Key Laboratory of Geomechanics and Geotechnical Engineering, Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, Wuhan 430071, China;
2. Key Laboratory of Safety for Geotechnical and Structural Engineering of Hubei Province, Wuhan University, Wuhan 430072, China;
3. University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 依据最小余能原理,在考虑节理岩体中锚杆剪切变形的基础上,分析了节理面水平剪切位移与锚杆轴向及切向变形之间的关系。结合锚杆受力特点拟定了锚杆屈服模式的判定流程。建立了考虑“等效剪切面积”的加锚节理面抗剪强度理论计算模型,并通过室内物理试验验证了理论计算模型的准确性。讨论了锚杆倾角、围岩抗压强度、锚杆直径、法向应力等因素对加锚节理面抗剪强度的影响规律。结果表明：所建立的锚杆剪切力学模型能够较好的反映锚杆轴向力及剪切力对节理面抗剪强度的贡献;考虑“等效剪切面积”的加锚节理面抗剪强度计算结果与试验结果较为吻合;锚杆倾角及围岩抗压强度越大,锚杆轴向力越小,剪切力越大;锚杆直径增大,锚杆轴向力及剪切力都会增大;节理面法向应力会显著影响剪胀效应,法向应力越大,节理面抗剪强度越高。
- 节理岩体 /
- 锚杆锚固 /
- 抗剪强度 /
- 物理试验
Abstract: Based on the principle of the minimum residual energy, the relationship between the horizontal shear displacement of the joint surface and the axial and tangential deformation of the bolt is analyzed considering the shear deformation of the bolts in jointed rock mass. The judgment process of the yield mode of the bolt is determined by analyzing the characteristics of the loading on the bolts. The formula for calculating the shear strength of the anchoring joint surface is established considering the equivalent shearing area, and the accuracy of the theoretical calculation is verified by the indoor physical experiments. The influence of bolt inclination, surrounding rock strength, bolt diameter and normal stress on the shear strength of the anchoring joint surface is discussed. The results show that the shearing mechanical model can better reflect the contribution of the axial force and shearing force of the bolts to the shear strength of the joints. The calculated results of the shear strength of the anchoring joint surfaces considering the equivalent shearing area are in good agreement with the experimental ones. The greater the inclination of the bolts and the strength of the surrounding rock, the smaller the axial force of the bolts but the greater the shear force. The axial force and shear force of the bolts will increase with the increase of the diameter of the bolts. The normal stress of the joint surface will significantly affect the dilatancy effect, and the greater the normal stress, the higher the shear strength of the joint.
- jointed rock /
- bolt anchoring /
- shear strength /
- physical test

HTML全文

参考文献(18)

[1]	葛修润, 刘建武. 加锚节理面抗剪性能研究[J]. 岩土工程学报, 1988, 10(1): 8-19. (GE Xiu-run, LIU Jian-wu. Study of the shear resistance behaviour of bolted rock joints[J]. Chinese Journal of Geotechnical Engineering, 1988, 10(1): 8-19. (in Chinese))
[2]	张乐文, 汪稔. 岩土锚固理论研究之现状[J].岩土力学, 2002, 23(5): 627-631. (ZHANG Le-wen, WANG Ren. Research on status quo of anchorage theory of rock and soil[J]. Rock and Soil Mechanics, 2002, 23(5): 627-631. (in Chinese) )
[3]	李召峰, 李术才, 张庆松, 等. 富水破碎岩体注浆加固模拟试验及应用研究[J]. 岩土工程学报, 2016, 38(12): 2246-2253. (LI Zhao-feng, LI Shu-cai, ZHANG Qing-song, et al. Model tests on grouting reinforcement of water-rich broken rock mass[J]. Chinese Journal of Geotechnical Engineering, 2016, 38(12): 2246-2253. (in Chinese))
[4]	刘新荣, 李栋梁, 吴相超, 等. 泥岩隧道锚承载特性现场模型试验研究[J]. 岩土工程学报, 2017, 39(1): 161-169. (LIU Xin-rong, LI Dong-liang, WU Xiang-chao, et al. Field model tests on bearing behavior of mudstone tunnel anchorage[J]. Chinese Journal of Geotechnical Engineering, 2017, 39(1): 161-169. (in Chinese))
[5]	张强勇, 李术才, 陈卫忠. 裂隙岩体加索支护模型及其工程应用[J]. 岩土力学, 2004, 25(9): 1465-1468. (ZHANG Qiang-yong, LI Shu-cai, CHEN Wei-zhong. Reinforcing model for anchor cable in jointed rockmass and its application to engineering[J].Rock and Soil Mechanics, 2004, 25(9): 1465-1468. (in Chinese))
[6]	SPANG K, EGGER P. Action of fully-grouted bolt in jointed rock and factors of influence[J]. Rock Mechanics and Rock Engineering, 1990, 23(3): 201-229.
[7]	FERRERO A M. The shear strength of reinforced rock joints[J]. International Journal of Rock Mechanics and Mining Science & Geomechanics Abstracts, 1995, 32(6): 595-605.
[8]	CHEN Yu. Experimental study and stress analysis of rock anchorage performance[J]. Journal of Rock Mechanics and Geotechnical Engineering, 2014, 6(5): 428-437.
[9]	YOSHINAKA R, SKAGUCHI S, SHIMIZU T, et al. Experimental study on the rock bolt reinforcement in discontinuous rocks[J]. Electionics & Communications in Japan, 1987, 133(113): 117-127.
[10]	张治强, 张国. 边坡预应力锚固结构的实验研究[J].东北大学学报, 1999, 20(5): 536-539. (ZHANG Zhi-qiang, ZHANG Guo. Experimental study on prestressly anchoring structure of slope[J]. Journal of Northeastern University (Natural Science), 1999, 20(5): 536-539. (in Chinese))
[11]	杨松林, 徐卫亚, 朱焕春. 锚杆在节理中的加固作用[J].岩土力学, 2002, 23(5): 604-607. (YANG Song-lin, XU Wei-ya, ZHU Huan-chun. Reinforcement of bolt in joints[J]. Rock and Soil Mechanics, 2002, 23(5): 604-607. (in Chinese) )
[12]	杨松林, 徐卫亚, 黄启平. 节理剪切过程中锚杆的变形分析[J]. 岩石力学与工程学报, 2004, 23(19): 3268-3273. (YANG Song-lin, XU Wei-ya, HAUNG Qi-ping. Analysis on the bolt deformation as result of joint shear displacement[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(19): 3268-3273. (in Chinese) )
[13]	陈文强, 贾志欣, 赵宇飞, 等. 剪切过程中锚杆的轴向和横向作用分析[J]. 岩土力学, 2015, 36(1): 143-148. (CHEN Wen-qiang, JIA Zhi-xin, ZHAO Yu-fei, et al. Analysis of axial and transverse effects of rock bolt during shearing process[J]. Rock and Soil Mechanics, 2015, 36(1): 143-148. (in Chinese))
[14]	张伟, 刘泉声. 节理岩体锚杆的综合变形分析[J].岩土力学, 2012, 33(4): 112-119. (ZHANG Wei, LIU Quan-sheng. Synthetical deformation analysis of anchor bolt in jointed rock mass[J]. Rock and Soil Mechanics, 2012, 33(4): 112-119. (in Chinese))
[15]	HETENYI M. Beam on elastic foundation: Theory with applications in the fields of civil and mechanical engineering[M]. Ann Arbor: The University of Michigan Press, 2013.
[16]	PELLET F, EGGER P. Analytical model for the mechanical behavior of bolted rock joints subjected to shearing[J]. Rock Mechanics and Rock Engineering, 1996, 29(2): 73-97.
[17]	HOLMBERG M. The mechanical behavior of untensioned grouted rock bolts[D]. Stockholm: Royal Institute of Technology, 1991.
[18]	LI L, HAGAN P C, SAYDAM S, et al. Shear resistance contribution of support system in double shear test[J]. Tunnelling and Underground Space Technology, 2016, 56: 168-175.
