高速列车与路基冻胀相互作用机理

盛岱超; 张升; 李希

高速列车与路基冻胀相互作用机理 English Version

中南大学土木工程学院，湖南长沙 410075

基金项目: 国家自然科学基金项目（51208519）

详细信息

作者简介:
盛岱超(1965-)，男，湖南益阳人，博士，博士生导师，主要从事非饱和土力学、计算岩土力学、岩土材料的本构模拟与试验和岩土环境工程等方面的研究与教学工作。E-mail:daichao.sheng@gmail.com。

中图分类号: TU475.2
计量
- 文章访问数: 515
- HTML全文浏览量: 0
- PDF下载量: 674
出版历程
- 收稿日期: 2013-04-14
- 发布日期: 2013-11-30

Effects of train loads on frost heave of embankments

School of Civil Engineering, Central South University, Changsha 41007, China

摘要

摘要: 针对高速铁路路基中低含水率、远离地下水的级配碎石等冻胀不敏感性粗颗粒土,却普遍发生冻胀的特殊现象,提出了一个简洁的#x0201c;循环动载诱发冻胀#x0201d;模型,认为高速列车循环荷载会导致地下水位以下饱和地基土中超静孔隙水压力的发展,进而将地下水#x0201c;泵送#x0201d;至冻结线以上,从而为土中独立冰层的形成,及冻胀的发生持续地提供#x0201c;原材料#x0201d;。模拟结果表明,本模型能够很好的揭示上述特殊工程现象发生的原因；同时,新模型对循环荷载诱发冻胀机理的阐述,也为季节性冻土区高速铁路路基冻胀防治研究提供了一种新的思路。
- 冻胀 /
- 循环荷载 /
- 超静孔隙水压力 /
- 高速铁路
Abstract: Substantial frost heave is observed in coarse fills in high-speed railway embankment. These coarse fills have very low water content and are located above the groundwater. In an attempt to explain the unexpected frost heave, it is proposed that the cyclic train loads cause the development of the excess pore water pressure in the underlying subgrade soils and hence #x02018;pump#x02019; up the water to the frost front, which in turn feeds the formation of ice and results in continuous frost heave. A simple quantitative model is developed to simulate the pumping-enhanced frost heave. The numerical results show that the proposed mechanism can indeed provide a legitimate explanation for the otherwise unexpected frost heave. The engineering implications of this new frost heave mechanism are also discussed, in the context of designing frost heave mitigation measures in seasonally frozen regions.
- frost heave /
- cyclic loading /
- excess pore water pressure /
- high-speed train

HTML全文

参考文献(23)

[1]	BESKOW G. Soil freezing and frost heaving with special application to roads and railroads[J]. Swedish Geological Survey Year Book 1935, 26(3), Series C, No. 375.
[2]	CHENG G D. The mechanism of repeated-segregation of the formation of thick layered ground ice[J]. Cold Regions Science and Technology, 1983, 8: 57-66.
[3]	李明霞. 秦沈客运专线涵洞洞顶填土冻胀机理和处理措施研究[D]. 北京: 北京交通大学, 2008: 8-17. (LI Ming-xia. Study on heaving mechanism and treatment measure of embankment filling on culvert of Qinhuangdao to Shenyang passage-dedicated railway[D]. Beijing: Beijing Jiaotong University, 2008: 8-17. (in Chinese))
[4]	MACHIIK. Mud pumping on tracjs-present state and counter measures[J]. Japanese Railway Engineering, 1978, 17(4): 20-21.
[5]	SELIG E T, WATER J M. Track geotechnology and substructure management[M]. London: Thomas Telford, 1994.
[6]	张建俊. 冻融循环作用下季冻区高铁路基沉降预测的试验研究[D]. 阜新: 辽宁工程技术大学, 2009: 7-9. (ZHANG Jian-jun. Experimental research on the prediction about the subsidence of high-speed railway subgrade under the action of freeze-thaw cycle in seasonal frozen soil region[D]. Fuxin: Liaoning Technical University, 2009: 7-9. (in Chinese))
[7]	刘华, 牛富俊, 牛永红, 等. 冻土区高速铁路路基填料及防冻层设置研究[J]. 岩石力学与工程学报, 2011, 30(12): 2549-2557. (LIU Hua, NIU Fu-Jun, NIU Yong-Hong, et al. Study of design of filling material and setting anti-frost layer for high-speed railway roadbed in seasonally frozen regions[J]. Chinese Journal of Rock Mechanics and Engineering, 2011, 30(12): 2549-2557. (in Chinese))
[8]	LIU Hua, NIU Fu-jun, NIU Yong-hong, et al. Experimental and numerical investigation on temperature characteristics of high-speed railway's embankment in seasonal frozen regions[J]. Cold Regions Science and Technology, 2012, 81: 55-64.
[9]	WONG R C K, THOMSON P R, CHOI E S C. In situ pore pressure response of native peat and soil under train load: a case study[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2006, 132(10): 1360-1369.
[10]	ALOBAIDI I, HOARE D J. The development of pore water pressure at the subgrade-subbase interface of a highway pavement and its effect on the pumping of fines[J]. Geotextiles and Geomembranes, 1996, 14: 111-135.
[11]	KETTIL P, LENHOF B, RUNESSON K, et al. Coupled simulation of wave propagation and water flow in soil induced by high-speed trains[J]. International Journal for Numerical and Analytical Methods in Geomechanics, 2008, 32(11): 1311-1319.
[12]	SEED H B, LEE K L. Liquefaction of saturated soil during cyclic loading[J]. Journal of the Soil Mechanics and Foundations Division (ASCE), 1966, 6: 101-110.
[13]	DAFALIAS Y F. Bounding surface plasticity I: Mathematical foundation and hypoelasticity[J]. Journal of Engineering Mechanics, ASCE, 1986, 112(9): 966-987.
[14]	KOLYMBAS D. An outline of hypoplasticity[J]. Archive Applied Mechanics, 1991, 61(3): 143-151.
[15]	PASTOR M, ZIENKIEWICZ O, CHAN A. Generalized plasticity and the modelling of soil behaviour[J]. International. Journal of Numerical and Analytical Methods in Geomechanics, 1990, 14(3): 151-190.
[16]	BIOT M A. Theory of propagation of elastic waves in a fluid-saturated porous solid: I Low-frequency range[J]. Journal of the Acoustical Society of America, 1956, 28(2): 168-78.
[17]	SKEMPTON A W. The pore-pressure coefficient A and B[J]. G#x000e9;otechnique, 1954, 4: 143-147.
[18]	LI Shuang-yang, LAI Yuan-ming, ZHANG Shu-juan, et al. Dynamic responses of Qinghai-Tibet railway embankment subjected to train loading in different seasons[J]. Soil Dynamics and Earthquake Engineering, 2012, 32: 1-14.
[19]	SHENG D, AXELSSON K, KNUTSSON S. Frost heave due to ice lens formation in freezing soils: 1 Theory and verification[J]. Nordic Hydrology, 1995, 26(2): 125-146.
[20]	SHENG D, AXELSSON K, KNUTSSON S. Frost heave due to ice lens formation in freezing soils: 2 Field application[J]. Nordic Hydrology, 1995, 26(2): 147-168.
[21]	SHENG Dai-chao, ZHANG Sheng, YU Zhi-Wu, et al. Assessing frost susceptibility of soils using PCHeave[J]. Cold Regions Science and Technology, 2013, 95: 27-38.
[22]	HILLEL D. Soil and water: physical principles and processes[M]. New York: Academic Press, 1971.
[23]	TB10020#x02014;2009高速铁路设计规范（试行）[S]. 2009. (TB10020#x02014;2009 Code for design of high speed railway[S]. 2009. (in Chinese))
