筐网基桩群对桥墩冲刷保护之探讨

筐网基桩群对桥墩冲刷保护之探讨 English Version

详细信息

1. Department of Hydraulic & Ocean Engineering, Taiwan Cheng Kung University, Tainan 70101, China; 2. Department of Construction Engineering, Taiwan Kaohsiung First University of Science and Technology, Kaohsiung 82445, China

摘要: 室内试验证明利用在基桩上部增设筐网,增大基桩对水流流速减少的效果,以提高基桩群对桥墩保护效率。在实际应用于桥墩冲刷保护时,将于桥墩上游布置三角形筐网基桩群,以减弱水流流速降低桥墩冲刷,同时可以阻挡漂流木对桥墩撞击,达到保护桥墩的功效。例举台湾3座桥墩保护,经由洪水作用后均能达到减少冲刷之效果,且漂流木不再冲击桥墩,对保护桥墩安全提供一良好的工法,值得善加应用。
- 桥墩冲刷 /
- 冲刷控制 /
- 基桩群 /
- 筐网
Abstract: The pile with porous basket can provide a better effect for velocity reduced than the one without porous basket in the lab tests. Therefore, group piles with porous baskets setting in the front of three bridges are used for protection in the field in Taiwan. From the results, the pile groups with porous baskets not only reduce the flow velocity owing to weaken scour depth of pier, but also resist the drifters to impact the piers. Hence, the method of the piles with porous basket to protect pier scouring is thought to be a very recommendable skill.
- pier scour /
- control erosion /
- pile group /
- porous basket

[1]	MELVILLE B W, HADFIELD A C. Use of sacrificial piles as pier scour countermeasures[J]. Journal of Hydraulic Engineering, ASCE, 1999, 125(11): 1221-1224.
[2]	Souza-Pinto, DE N L, Riprap Protection against scour around bridge piers[D]. Iowa City: State University of Iowa, 1959.
[3]	POSEY C J. Test of scour protection for bridge piers[J]. Journal of Hydraulic Division, ASCE, 1974, 100(12): 1773-1783.
[4]	CHIEW Y M. Mechanics of riprap failure at bridge piers[J]. Journal of Hydraulic Engineering, ASCE, 1995, 121(9): 635-643.
[5]	CHIEW Y M. Scour protection at bridge piers[J]. Journal of Hydraulic Engineering, ASCE, 1992, 118(9): 1260-1269.
[6]	ODGAARD A J, WANG Y. Sediment management with submerged vanes Ⅰ: applications[J]. Journal of Hydraulic Engineering, ASCE, 1991, 117: 284-302.
[7]	LAUCHLAN C S. Counter-measures for pier scour[D]. New Zealand: The University of Auckland, 1999.
[8]	HUANG C K, TANG C J, KUO T Y. Use of surface guide panels as pier scour countermeasures[J]. International Journal of Sediment Research, 2005, 20(2): 117-128.
