海上人工岛内深基坑变形与稳定分析

丁勇春; 李光辉; 王建华

海上人工岛内深基坑变形与稳定分析 English Version

(1.中交第三航务工程勘察设计院有限公司，上海 200032；2. 上海交通大学土木工程系，上海 200240)

详细信息

作者简介:
丁勇春(1979– )，男，江苏大丰人，博士，高级工程师，主要从事基坑工程及港口岩土工程的设计与研究工作。

中图分类号: TU473.5；U655.54
计量
- 文章访问数: 1117
- HTML全文浏览量: 0
- PDF下载量: 523
出版历程
- 收稿日期: 2012-11-12
- 发布日期: 2012-11-12

Deformation and stability of deep excavations in artificial offshore island

(1. CCCC Third Harbor Consultants Co., Ltd., Shanghai 200032, China; 2. Department of Civil Engineering, Shanghai Jiaotong University, Shanghai 200240, China)

摘要

摘要: 采用数值方法研究了某跨海大桥海上人工岛内隧道基坑的变形性状与整体稳定性。基于有限元程序Plaxis建立考虑复杂施工条件下土与结构相互作用的平面应变计算模型，分析坑中坑方案和大开挖方案两种不同基坑开挖方法对大直径钢圆筒岸壁结构及基坑围护桩变形、整体稳定性及失稳破坏模式的影响。研究表明：相对大开挖方案，最不利状态下坑中坑方案使钢圆筒相对侧向变形由1.41%降至0.69%，结构整体稳定安全系数由1.51增至1.68，结构失稳破坏模式由钢圆筒绕其下部倾覆转动转变为岛内土体绕围护桩滑移，但坑中坑方案由于增加了临时围护结构的施工，对工期和投资的影响较大。由于两种开挖方案均能满足基坑的安全度控制要求，同时又不涉及基坑变形对周边环境的影响，大开挖方案对工期及投资控制更有利。
- 人工岛 /
- 水上基坑 /
- 大直径钢圆筒 /
- 数值模拟 /
- 变形 /
- 稳定
Abstract: A two-dimensional finite element method (FEM) numerical simulation was carried out to investigate the deformation behavior and the global stability of the large-diameter steel cylinder bulkhead as well as the steel tube pile retaining structure in combination with the practice of a waterfront tunnel pit excavation in an artificial offshore island. Two numerical models were established respectively with Plaxis to compare the performance of the local excavation scheme and the large excavation scheme under complex construction conditions. The numerical results show that the local excavation scheme can reduce the relative lateral deformation of the steel cylinder bulkhead from 1.41 percent to 0.69 percent, raise the safety factor of global stability from 1.51 to 1.68, and transform the collapse mode of the structures from the type of steel cylinder overturning rotation around its bottom to the type of block slide around the steel tube pile top in the island. Nevertheless, the local excavation scheme may prolong the construction period and increase the project investment owing to the additional construction of temporary retaining structure. Both of the excavation schemes can satisfy the safety control requirements of stability; meanwhile, relatively large deformation of the excavation will not bring negative impact on the surroundings. The large excavation scheme is more favorable in construction period and project investment control than the local excavation scheme.
- artificial island /
- waterfront excavation /
- steel cylinder /
- numerical simulation /
- deformation /
- stability

HTML全文

参考文献(13)

[1]	谢世楞. 人工岛设计的进展[J]. 海岸工程, 1995, 14(1): 1–7. (XIE Shi-leng. Advances in design of artificial island[J]. Coastal Engineering, 1995, 14(1): 1–7. (in Chinese))
[2]	严恺. 海港工程[M]. 北京: 海洋出版社, 1996. (YAN Kai. Port and harbor engineering[M]. Beijing: China Ocean Press, 1996. (in Chinese))
[3]	张志明, 刘连生, 钱立明, 等. 海上大型人工岛设计关键技术研究[J]. 水运工程, 2011(9): 1–7. (ZHANG Zhi-ming, LIU Lian-sheng, QIAN Li-ming, et al. On key design technology for large offshore man-made island[J]. Port & Waterway Engineering, 2011(9): 1–7. (in Chinese))
[4]	张振东. 江苏近海辐射沙脊群人工岛建设工程问题初探[J]. 淮海工学院学报(自然科学版), 2010, 19(3): 89–92. (ZHANG Zhen-dong. Brief study on engineering construction problems of artificial island on radiate sandbanks of Jiangsu[J]. Journal of Huaihai Institute of Technology (Natural Science), 2010, 19(3): 89–92. (in Chinese))
[5]	The Overseas Coastal Area Development Institute of Japan (OCDI). Technical standards and commentaries for port and habour facilities in Japan[R]. Tokyo: Ports and Harbours Bureau, Ministry of Land, Infrastructure, Transport and Tourism (MLIT), 2009.
[6]	American Petroleum Institute (API). Recommended practice for planning, designing and constructing fixed offshore platforms[R]. Washington D C: American Petroleum Institute Production Department, 1996.
[7]	中国港湾建设总公司澳门国际机场工程总经理部. 澳门国际机场工程技术篇[R]. 广州: 广东科技出版社, 1995. (General Manager Department of Macau International Airport Project, China Harbor Engineering Company. Technical part of Macau International Airport Project[R]. Guangzhou: Guangdong Science and Technology Press, 1995. (in Chinese))
[8]	JGJ 120—99 建筑基坑支护技术规程[S]. 1999. (JGJ 120—98 Technical specification for retaining and protection of building foundation excavations[S]. 1999. (in Chinese))
[9]	DG/TJ 08—61—2010 基坑工程技术规范[S]. 2010. (DG/TJ 08—61—2010 Technical code for excavation engineering[S]. 2010. (in Chinese))
[10]	刘国彬, 王卫东. 基坑工程手册[M]. 2版. 北京: 中国建筑工业出版社, 2009. (LIU Go-bin, WANG Wei-dong. Excavation engineering manual[M]. 2nd ed. Beijing: China Architecture and Building Press, 2009. (in Chinese))
[11]	李小军, 陈映华, 宣庐峻. 采用水上深基坑围护法建造特大型船坞坞口的创新设计[J]. 岩土工程学报, 2006, 28(增刊1): 1560–1564. (LI Xiao-jun, CHEN Ying-hua, XUAN Lu-jun. Creative design of super large dry-dock head construction by means of deep steel sheet piling excavation in water area[J]. Chinese Journal of Geotechnical Engineering, 2006, 28(S1): 1560–1564. (in Chinese))
[12]	中交公路规划设计院有限公司联合体. 港珠澳大桥主体工程隧道人工岛岛体结构初步设计[R]. 北京：中交公路规划设计院有限公司, 2009. (Association of CCCC HighwayConsultants Co., Ltd. Primary design of artificial island for immersed tube tunnel of Hong Kong-Zhuhai-Macao Bridge[R]. Beijing: CCCC Highway Consultants Co., Ltd., 2009. (in Chinese))
[13]	王卫东, 王建华. 深基坑支护结构与主体结构相结合的设计、分析与实例[M]. 北京: 中国建筑工业出版社, 2007. (WANG Wei-dong, WANG Jian-hua. Design, analysis and case histories of deep excavations supported by permanent structures[M]. Beijing: China Architecture and Building Press, 2007. (in Chinese))
