基坑围护排桩与地下室外墙相结合的“桩墙合一”的设计与分析

基坑围护排桩与地下室外墙相结合的“桩墙合一”的设计与分析 English Version

详细信息

（Department of Underground Structure & Geotechnical Engineering, East China Architecture Design & Research Institute Co., Ltd., Shanghai 200002, China）

摘要: “桩墙合一”技术考虑基坑围护桩与地下室外墙共同作用作为正常使用阶段的地下室侧壁挡土结构，可减薄地下室外墙的厚度、减少基坑面积，有利于节约工程造价，节能降耗，具有良好的社会经济效益。通过工程应用考虑了“桩墙合一”技术的防水、传力构造等，并通过基坑开挖阶段、正常使用阶段、抗震等多工况进行“桩墙合一”的强度与耐久性设计计算，可作为今后类似工程设计的参考。
- 基坑围护桩 /
- 地下室外墙 /
- 桩墙合一 /
- 地下室防水
Abstract: Used as the lateral retaining structure during the regular service stage considering the combination of support piles and basement external walls, the technique of the unity of support piles and basement external walls can reduce the thickness of basement external walls and the excavation area, so it has good economic and social performances by saving the project cost. Through project application, the waterproof design and the load transfer slab are considered, and the strength and durability design are calculated under various conditions of excavation stage, regular service stage and earthquake stage. These outcomes can be referenced in future other similar projects.
- support pile /
- basement external wall /
- unity of support pile and basement external wall /
- basement waterproof

[1]	刘国彬, 王卫东. 基坑工程手册[M]. 北京: 中国建筑工业出版社, 2009. (LIU Guo-bin, WANG Wei-dong. Excavation engineering manual[M]. Beijing: China Architecture & Building Press, 2009. (in Chinese))
[2]	DG/TJ08—61—2010 上海市工程建设规范基坑工程技术规范[S]. 上海, 2010. (DG/TJ08—61—2010 Technical Code for Excavation Engineering[S]. Shanghai, 2010. (in Chinese))
[3]	DGJ08—11—2010 上海市工程建设规范地基基础设计规范[S]. 上海, 2010. (DGJ08—11—2010 Foundation design code[S]. Shanghai, 2010. (in Chinese))
[4]	左人宇. “一桩三用”技术与实践[D]. 杭州: 浙江大学岩土工程研究所, 2001. (ZUO Ren-yu. The art of “one pile three uses” and it’s application[D]. Hangzhou: Zhejiang University, 2001. (in Chinese))
