Application of p-y curves in excavation engineering
-
摘要: 将横向受荷桩的p–y曲线法应用到深基坑工程中，提出了一种考虑支护结构和土之间非线性共同作用的弹性地基反力法计算模型，即对于基坑开挖面以上，采用根据p–y曲线建立的支护结构-土非线性共同作用的计算模型；基坑开挖面以下，将支护结构看作横向受荷桩，基坑开挖面以上土体看为超载作用在支护结构上。之后根据弹性地基梁的挠曲微分方程，推导出考虑非线性共同作用的弹性地基梁挠曲微分方程，应用有限差分法计算支护桩的内力和位移。Abstract: The p-y curve method for single pile under horizontal load is applied in excavation engineering. An elastic sugrade reaction model considering nonlinear interaction between protection-structure and soil for deep excavations is put forward. Above the pit plane, a computational model cansidering the protecting structure-soil nonlinear interaction is adopted; under the pit plane, the protection-structure is regarded as laterally loaded piles and the weight of soil above the pit excavation is applying to the protection-structure as an overloading. The differential equation of the elastic subgrade beam to consider the nonlinear interaction is derived based on the equation of the general elastic subgrade beam. The internal force and deflection of supporting piles are calculated by adopting finite difference method.
-
Keywords:
- p-y curve /
- excavation engineering /
- computational model /
- nonlinear interaction
-
[1] JGJ 120—99 建筑基坑支护技术规程[S]. 1999. (JGJ 120—99 Technical specification for retaining and protection of building foundation excavations[S]. 1999.(in Chinese)) [2] 邓子胜, 邹银生, 王贻荪. 考虑位移非线性影响的深基坑土压力计算模型研究[J]. 工程力学, 2004, 21(1): 107–111. (DENG Zi-sheng, ZOU Yin-sheng, WANG Yi-sun. Calculation of the earth pressure considering nonlinear displacement influence on deep excavation[J]. Engineering Mechanics, 2004, 21(1): 107–111. (in Chinese)) [3] 邓子胜. 深基坑支护结构–土空间非线性共同作用研究[D]. 长沙: 湖南大学, 2004. (DENG Zi-sheng. Research on nonlinear interaction between protection-structure and soil for deep excavations[D]. Changsha: Hunan University, 2004. (in Chinese)) [4] 胡胜刚. 基于p–y曲线模型的桩基非线性性状分析研究[D]. 武汉: 武汉理工大学, 2005. (HU Sheng-gang. Research on nonlinear character of pile foundation based on p-y curve model[D]. Wuhan: Wuhan University of Technology, 2005. (in Chinese)) [5] 高大钊, 孙 钧, 陈汉忠, 等. 深基坑工程[M]. 北京: 机械工业出版社, 1999. (GAO Da-zhao, SUN Jun, CHEN Han-zhong. The foundation pit engineering[M]. Beijing: China Machine Press, 1999. (in Chinese)) [6] 王惠初, 鲁子爱. 用p–y曲线计算横向荷载桩的内力[J]. 重庆交通学院学报, 1985(1): 61–65. (WANG Hui-chu, LU Zi-ai. Method for calculating internal forces of the laterally loaded pile according to p-y curves[J]. Journal of Chongqing Jiaotong University, 1985(1): 61–65. (in Chinese))
