Application of ABAQUS in calculating deformation of excavations
-
摘要: 探讨了商业有限元软件ABAQUS中多孔介质弹性模型与黏土临界状态塑性模型中有关参数的物理含义和基于常规三轴试验及压缩试验成果确定模型中参数值的方法。基于e–lnp′平面中各向等压固结线、回弹线、K0状态压缩线及临界状态线间的相关关系以及修正剑桥模型，推导了K0状态下初始孔隙比与平均主应力的相关关系，并通过子程序嵌入ABAQUS的计算中。采用ABAQUS中多孔弹性模型和临界状态塑性模型相结合的弹塑性本构关系，针对某土钉支护案例的变形进行了计算。分析了支护水平位移以及地面沉降的计算结果的合理性，验证了ABAQUS数值模拟在分析计算基坑开挖变形问题的可行性。Abstract: The physical meanings of the parameters for the porous elasticity model and the critical state plasticity model in ABAQUS, a popular commercial finite element software, are discussed, and the methods to decide the parametric values from triaxial compression tests or oedometer tests are presented. Based on the relationship among the normal consolidation line, unloading-reloading line, K0 consolidation line and the critical state line of e–lnp′ curves and the modified Cam-clay model, the correlation between the initial void ratio and the mean effective stress in the field is deduced and used in the simulation by ABAQUS. A soil-nailing case is simulated in ABAQUS by means of the porous elasticity model and the critical state plasticity model. The deformation results of this soil nailing case are analyzed, and the rationality is verified by the monitoring data in practice. |
-
[1] 李广信. 高等土力学[M]. 北京: 清华大学出版社, 2004. (LI Guang-xin. Advanced soil mechanics[M]. Beijing: Tsinghua University Press, 2004. (in Chinese)) [2] JGJ120—99 建筑基坑支护技术规程[S]. 北京: 中国建筑工业出版社, 1999. (JGJ120—99 Technical specification for retaining and protection of building foundation excavation[S]. Beijing: China Architecture & Building Press, 1999. (in Chinese)) [3] CECS96: 97 基坑土钉支护技术规程[S]. 北京: 中国工程建设标准化协会, 1997. (CECS96: 97 Specification for soil nailing in foundation excavations[S]. Beijing: Standard Association of Engineering Construction, 1997. (in Chinese)) [4] 杨光华, 黄宏伟. 基坑支护土钉力的简化增量计算法[J].岩土力学, 2004, 25(1): 15–19. (YANG Guang-hua, HUANG Hong-wei. Simplified incremental calculation method of soil nail forces for retaining and protection of foundation pits[J]. Rock and Soil Mechanics, 2004, 25(1): 15–19. (in Chinese)) [5] 杨光华. 土钉支护中土钉力和位移的计算问题[J]. 岩土力学, 2012, 33(1): 137–146. (YANG Guang-hua. Calculation of soil nail forces and displacement in soil nailing retaining wall[J]. Rock and Soil Mechanics, 2012, 33(1): 137–146. (in Chinese)) [6] HELWANY S. Applied soil mechanics with ABAQUS applications[M]. New York: John Wiley & Sons, 2007. [7] WOOD D V. Soil behaviour and critical state soil mechanics[M]. London: Cambridge University Press, 1990. [8] 段建立, 谭跃虎, 樊有维, 等. 复合土钉支护的现场测试研究[J]. 岩土力学与工程学报, 2004, 23(12): 2128–2132. (DUAN Jian-li, TAN Yue-hu, FAN You-wei, et al. Field testing study on composite soil nailing Chinese[J]. Chinese Journal of Rock Mechanics and Engineering, 2004, 23(12): 2128–2132. (in Chinese)) [9] 杨育文. 复合土钉墙实例分析和变形评估[J]. 岩土工程学报, 2012, 34(4): 734–741. (YANG Yu-wen. Case studies of composite soil-nailing walls and movement estimate[J]. Chinese Journal of Geotechnical Engineering, 2012, 34(4): 734–741. (in Chinese))（本文责编 李运辉）
