单桩对临近盾构机侧向穿越时的响应

李大勇; 宋言江; 李德胜

单桩对临近盾构机侧向穿越时的响应 English Version

1.山东省土木工程防灾减灾重点实验室,山东青岛 266510 ； 2. 山东科技大学土木建筑学院,山东青岛 266510 ； 3. 蓬莱安全生产监督管理局,山东蓬莱 265600

基金项目: 国家自然科学基金项目( 51078227)；山东省自然科学基金项目( ZR2009FM003)；山东省“泰山学者”建设工程专项基金项目；教育部留学回国人员科研启动基金项目

详细信息

作者简介:
李大勇 (1971 – ) ,男,博士,教授。研究方向为海洋岩土工程。

中图分类号: U452
计量
- 文章访问数: 1286
- HTML全文浏览量: 1
- PDF下载量: 366
出版历程
- 收稿日期: 2011-08-01
- 发布日期: 2011-12-06

Responses of a single pile to laterally passing shield tunneling

1. Key Laboratory of Civil Engineering Disaster Prevention and Mitigation, Qingdao 266510, China; 2. Shandong University of Science and Technology, Qingdao 266510, China; 3.Penglai Administration of Work Safety, Penglai 265600, China

摘要

摘要: 盾构机掘进靠近已有临近桩基时,引起的地层移动会导致桩的承载力降低和产生附加变形。因此,针对隧道侧向穿越桩基时,桩体的承载力及变形的影响问题进行了深入分析,研究中考虑了土仓压力和与桩的距离等因素对桩基的影响,得出了单桩弯矩和桩顶沉降的变化规律；结果表明,盾构掘进中桩基的竖向承载力和沉降下降明显,在工程实践中需引起重视,需考虑采取适当控制措施以保证桩基的安全性；土仓压力大小能有效控制桩的承载力下降,对桩的下沉有一定的控制作用。论文成果对盾构机穿越桩基的安全评估提供了借鉴意义。
- 盾构施工 /
- 桩侧摩阻力 /
- 沉降 /
- 极限承载力 /
- 土仓压力
Abstract: The decrease in the bearing capacity of a single pile and the additional deformation will occur when the shield machine approaches the existing pile. Effects of shield tunneling on a single existing pile are investigated by means of the numerical method in this study in the case of shield machine passing laterally. Earth pressures in the chamber of the shield machine and change in the distance between the pile and the shield machine are taken into account in the numerical simulation. It shows the two factors, i.e., earth pressures in the chamber and the distance, play an important role in this process. Moments along the pile and settlements at the top of the pile are obtained as well. It is proved that the decrease in the bearing capacity of the pile and the increase in the settlement are significant during the shield tunneling. Therefore, some measures should be taken to protect the existing pile from damage. Moreover, the earth pressures in the chamber can prevent effectively the pile from decreasing in the bearing capacity, and to some extent, it can control the settlement induced by the shield tunneling.
- shield tunneling /
- side friction of pile /
- settlement /
- ultimate bearing capacity /
- earth pressure in chamber

HTML全文

参考文献(13)

[1]	MAIR R. Tunneling and geotechnics: new horizons[J]. Géotechnique, 2008, 58 (9): 695 – 736.
[2]	CHEN L T, POULOS H G, LOGANATHAN N. Pile responses caused by tunneling[J]. Journal of Geotechnical and Geoenvironmental Engineering (ASCE) 1999, 125 (3): 802 – 811.
[3]	阮林旺 . 软土盾构推进对相邻土层及桩体影响的三维有限元分析 [D]. 上海 : 同济大学 , 1997. (RUAN Lin-wang. Analysis on the influence of shield tunneling construction to adjacentsoil and pile in soft soil with the three-dimensional finite element software[D]. Shanghai: Tongji University, 1997. (in Chinese))
[4]	李永盛 , 黄海鹰 . 盾构推进对相邻桩体力学影响的实用计算方法 [J]. 同济大学学报 , 1997, 25 (3): 261 – 267. (LI Yong-sheng, HUANG Hai-ying. Method of practical calculation on strength effect shield tunneling construction has on adjacent pile[J]. Journal of Tongji University, 1997, 25 (3): 261 – 267. (in Chinese))
[5]	PASTSAKORN, KITIYODOMN, TATSUNORI Matsumoto, et al. A simplified analysis method for piled raft foundations subjected to ground movements induced by tunneling[J]. Int J Numer Anal Meth Geomech, 2005, 29 : 1485 – 1507.
[6]	杨晓杰 , 邓飞皇 , 聂雯 , 等 . 地铁隧道近距穿越施工对桩基承载力的影响研究 [J]. 岩石力学与工程学报 , 2006, 25 (6): 1290 – 1295. (YANG Xiao-jie, DENG Fei-huang, NIE Wen, et al. Study on the influence of subway tunnel construction on pile bearing capacity[J]. Chinese Journal of Rock Mechanics and Engineering, 2006, 25 (6): 1290 – 1295. (in Chinese))
[7]	芮勇勤 , 岳中琦 , 唐春安 , 等 . 隧道开挖方式对建筑物桩基影响的数值模拟分析 [J]. 岩石力学与工程学报 , 2003, 22 (5): 735 – 741. (RUI Yong-qin, YUE Zhong-qi, TANG Chun-an, et al. Analysis the influence of tunnel excavation way on pile[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22 (5): 735 – 741. (in Chinese))
[8]	朱逢斌 , 杨平 , ONG W. 盾构隧道开挖对邻近桩基影响数值分析 [J]. 岩土工程学报 , 2008, 30 (2): 298 – 302. ( ZHU Feng-bin, YANG Ping, ONG W. Numerical analysis on influence of shield tunnel excavation to neighboring piles[J] Chinese Journal of Geotechnical Engineering, 2008, 30 (2): 298 – 302 . (in Chinese) )
[9]	刘丽 . 盾构掘进过程中邻近桩基的反应分析研究 [D]. 青岛 : 山东科技大学 , 2006. (LIU Li. Research on the responses of adjacent pile with shield tunnel construction[D]. Qingdao: Shandong University of Science and Technology , 2006. (in Chinese))
[10]	潘军刚 . 隧道近接施工引起邻近既有桩基的内力和变形研究 [D]. 青岛 : 山东科技大学 , 2007. (PANG Jun-gang. Study on the response of internal forces and deformations of existing pile foundation to tunneling [D]. Qingdao: Shandong University of Science and Technology , 2007. (in Chinese))
[11]	李德胜 , 李大勇 . 双孔隧道盾构施工对邻近桩基变形和内力的研究 [J]. 铁路勘查与设计 , 2008(2): 40 – 44, 68. (LI De-sheng, LI Da-yong. Research on the effect of double orifice shield tunneling construction on the deformation and internal force of adjacent pile[J]. Railway Exploration and Design, 2008(2): 40 – 44, 68. (in Chinese))
[12]	李德胜 , 李大勇 . 盾构机下穿桩基施工对单桩承载力影响的数值研究 [J]. 工程地质学报 , 2009, 17 (2): 284 – 288. (LI De-sheng, LI Da-yong. Numerical simulation of effect of shield tunneling on bearing capacity of single pile[J]. Journal of Engineering Geology, 2009, 17 (2): 284 – 288. (in Chinese))
[13]	李德胜 . 盾构隧道近接施工对邻近既有桩基的影响研究 [D]. 青岛 : 山东科技大学 , 2008 . (LI De-sheng. Studyeffect of pile foundation adjacent to shield tunneling[D]. Qingdao: Shandong University of Science and Technology , 2008. (in Chinese))
