基于低应变动测法的双向粉喷桩桩身质量评价

谢胜华; 刘松玉; 杜广印; 季鹏

基于低应变动测法的双向粉喷桩桩身质量评价 English Version

1.东南大学岩土工程研究所,江苏南京 210096 ； 2. 安徽工业大学建筑工程学院,安徽马鞍山 243002

基金项目: 国家自然科学基金项目( 50879011)；江苏省交通科技项目

详细信息

作者简介:
谢胜华 (1977 – ) ,男,安徽怀宁人,博士研究生,讲师,主要从事土力学、高速公路软弱地基处理等方面的研究与教学工作。

中图分类号: TU473
计量
- 文章访问数: 1267
- HTML全文浏览量: 1
- PDF下载量: 425
出版历程
- 收稿日期: 2011-08-02
- 发布日期: 2011-12-06

Quality evaluation of pile integrity by bidirectional dry jet mixing method based on low-strain integrity tests

1. Institute of Geotechnical Engineering, Southeast University, Nanjing 210096, China; 2. School of Civil Engineering and Architecture, Anhui University of Technology, Ma’anshan 243002, China

摘要

摘要: 低应变动测法桩基检测技术,具有检测速度快、反应直观、适应性强等特点,目前该方法在桩基（钻孔灌注桩和预应力管桩）工程检测中得到广泛应用,但在粉喷桩的桩身完整性和桩长检测过程还存在大量的问题还有待进一步进行探索。文中探讨了双向粉喷桩单桩检测方法的适用程度及具体标准,提出用低应变动测法评价双向粉喷桩的桩身强度、桩长等特性以及对检测效果的影响因素分析,并通过现场取芯检测进行对比分析,验证了该法在双向粉喷桩检测的适用性,并在连云港至临沂高速公路（江苏段） LL-8 标双向粉喷桩处理的工程中使用,取得较好的检测效果。
- 桩身完整性 /
- 低应变动测法 /
- 双向粉喷桩 /
- 有效桩长
Abstract: The low-strain reflection wave method for the pile foundation is an inspection technology. It has advantages such as rapid detection speed, intuitive reaction, strong adaptability. At present this method has been widely used in pile foundation (cast-in-situ bored piles and prestressed pipe piles). Nevertheless problems still exist in terms of monitoring of pile shaft completeness and pile length for DJM piles. In this study, the applicability and specific standards of inspection methods for bidirectional DJM piles are discussed. The low-strain dynamic test method is proposed to detect the strength the pile length and characteristics of bidirectional DJM pile body. Through the in-situ core tests, this method is verified in term of bi-directional DJM pile tests, and applied in Lianyungang-Linyi highway (Jiangsu province) LL-8 section bidirectional DJM pile project, and convinced results are achieved.
- pile integrity /
- low strain integrity testing /
- bidirectional dry jet mixing column /
- critical length of column

HTML全文

参考文献(12)

[1]	刘松玉 , 钱国超 , 章定文 . 粉喷桩复合地基理论与工程应用 [M]. 北京 : 中国建筑工业出版社 , 2006. (LIU song-yu, QIAN Guo-chao, ZHANG Ding-wen. The principle and application of dry jet mixing composite foundation[M]. Beijing: China Architecture and Building Press, 2006. (in Chinese))
[2]	刘松玉 , 杜广卯 , 杨泳 , 等 . 双向搅拌粉喷桩成桩操作方法 [P] 2008.7. (LIU Song-yu, DU Guang-yin, YANG Yong, et al. The methods of operation of bidirectional DJM column[P] 2008. 7. (in Chinese))
[3]	刘松玉 , 杨泳 , 孙竹萍 , 等 . 一种双向搅拌粉喷桩机 [P]. 2008-12-31. (LIU Song-yu, YANG Yong, SUN Zhu-pign, et al. The bit of bidirectional DJM machinery [P]. :CN200820032126.7, 2008-12-31. (in Chinese))
[4]	谢胜华 , 刘松玉 , 杜广印 , 等 . 双向搅拌粉喷桩技术开发与应用研究 [J]. 工程勘察 , 2011, 录用待刊 . (XIE Sheng-hua, LIU Song-yu, DU Guang-yin, et al. Technology research on bidirectional dry jet mixing columns and its engineering application[J]. Geotechnical Investigation ＆ Surveying, 2011, submitted. (in Chinese))
[5]	TB 10113 — 96 粉体喷搅法加固软弱土层技术规范 [S]. 北京 : 铁道部标准科情所出版 , 1996. ( China Railway Siyuan Survey and Design Group Co., Ltd. TB 10113 — 96 Technical code on dry jet mixing method to stabilize soft foundation[S]. (in Chinese))
[6]	刘屠梅 , 赵竹占 , 吴慧明 . 基桩检测技术与实例 [M]. 北京 : 中国建筑工业出版社 , 2006. (LIU Tou-mei,ZHAO Zhu-zhan, WU Hui-ming. The foundation pile testing technology and examples [M]. Beijing: China Architecture and Building Press, 2006. (in Chinese))
[7]	JGJ/T 93 — 1995 基桩低应变动力检测规程 [S]. 1995. ( JGJ/T 93 — 1995 The foundation pile low strain dynamic testing procedures [S]. 1995. (in Chinese))
[8]	雷林源 . 桩基动力学 [M]. 北京 : 冶金工业出版社 , 2000. (LEI Lin-yuan. Pile foundation dynamics[M]. Beijing: Metallurgical Industry Press, 2000. (in Chinese))
[9]	徐攸在 . 桩的动测新技术 [M]. 第 2 版 . 北京 : 中国建筑工业出版社 , 2002. (XU You-zai. The new technology of pile dynamic testing[M]. 2nd ed. Beijing: China Architecture and Building Press, 2002. (in Chinese))
[10]	JGJ 106 — 2003 建筑基桩检测技术规范 [S]. 北京 : 中国建筑工业出版社 , 2002. (JGJ 106 — 2003 Technical code for testing of building foundation piles[S]. Beijing: China Architecture and Building Press, 2003. (in Chinese))
[11]	HIRD C C, CHAN C M. Correlation of shear velocity with unconfined compressive strength of cement-stabilised clay[J]. Deep Mixing, 2005 (5) : 79 – 85.
[12]	史佩栋 . 实用桩基工程手册 [M]. 北京 : 中国建筑工业出版社 , 1999. (SHI Pei-dong. Practical handbook for pile foundation engineering[M]. Beijing: China Architecture and Building Press, 1999. (in Chinese))
