基于频散特性的层状介质面波自由场反演

薛耀辉; 董志骞; 李钢; 余丁浩; 王睿; 张昊

doi:10.11779/CJGE20231220

基于频散特性的层状介质面波自由场反演 English Version

薛耀辉^1,,
董志骞^{1, 2, ,},
李钢¹,
余丁浩¹,
王睿¹,
张昊²

1.
大连理工大学海岸与海洋工程全国重点实验室, 辽宁大连 116024
2.
建筑安全与环境国家重点实验室, 北京 100013

基金项目:

国家自然科学基金项目 52038002

国家自然科学基金项目 52225804

建筑安全与环境国家重点实验室/国家建筑工程技术研究中心开放课题基金项目 BSBE2023-07

详细信息

作者简介:
薛耀辉(1995—)，男，博士研究生，主要从事地震波场反演、地震动信号处理等方面的研究工作。E-mail: xueyaohui1995@163.com

通讯作者:
董志骞, E-mail: zqdong@dlut.edu.cn

中图分类号: P315.9;TU973.2
计量
- 文章访问数: 0
- HTML全文浏览量: 0
- PDF下载量: 0
出版历程
- 收稿日期: 2023-12-11
- 网络出版日期: 2024-06-05
- 刊出日期: 2025-05-31

Surface-wave free-field inversion based on dispersion property in layered media

1.
State Key Laboratory of Coastal and Offshore Engineering, Dalian University of Technology, Dalian 116024, China
2.
State Key Laboratory of Building Safety and Built Environment, Beijing 100013, China

摘要

摘要: 面波自由场反演是实现土-结相互作用（SSI）体系地震动输入以及揭示结构真实地震响应行为的重要步骤之一。现有反演方法将地表地震动全部作为体波考虑，仅对体波自由场进行反演。为了弥补忽略面波带来的反演精度不足，提出了一种层状介质场地基于频散特性的面波自由场反演方法，为SSI体系地震响应分析提供准确的面波激励。该方法针对频散面波多模态相互耦合、难以分离的问题，采用平均能流密度来表征各频散模态的参与量，并结合频域动力刚度矩阵计算了模态参与系数；然后采用模态参与系数对各频散模态进行解耦，将地表面波分量分配给各单阶频散模态进行单模态面波自由场反演；最后利用模态叠加原理将所有单模态面波自由场合成多模态面波自由场。方法的准确性和应用性分析结果表明，所提反演方法能够准确地还原地下真实的面波自由场以及揭示频散面波对SSI体系地震响应的重要影响，可用于为SSI体系抗震设计、风险评估等工作提供定量的指导。
- 面波自由场反演 /
- SSI体系 /
- 层状介质 /
- 频散特性 /
- 能流密度
Abstract: The surface-wave free-field inversion is one of the important steps in realizing the seismic inputs to the soil-structure interaction (SSI) systems and further revealing the real seismic response behaviors. Currently the available inversion methods regard all ground motions as the body-wave components alone and invert only the body-wave free fields. To make up for the lack of neglecting surface waves in inversion implementations, a surface-wave free-field inversion method based on the dispersion property is proposed in this study to provide more accurate surface-wave excitation for the seismic analysis of the SSI systems resting on layered media. With the problem that multiple modes of the dispersive surface waves are coupled to each other and difficult to separate, the proposed method employs the average energy flow density to characterize the participation volume of dispersive modes and then calculates the mode participation factors using the frequency-domain dynamic stiffness matrix. The calculated mode participation factors are used to decouple the dispersive modes and assign the ground surface waves to each single mode, allowing for the inversion of single-mode surface-wave free fields. Finally, all single-mode surface-wave free fields are superimposed to form the multi-mode wavefields through the mode superposition theory. The findings from the analysis of accuracy and applicability of the proposed inversion method demonstrate its capability to effectively recover the actual underground surface-wave free fields, and shed light on the notable impact of dispersive surface waves on the seismic responses of the SSI systems, thus providing quantitative guidance for the seismic design and risk assessment of the SSI systems.
- surface-wave free-field inversion /
- SSI system /
- layered media /
- dispersion property /
- energy flow density

HTML全文

图 1 Rayleigh面波与Love面波的频散曲线

Figure 1. Dispersion curves of Rayleigh and Love waves

下载: 全尺寸图片幻灯片

图 2 层状介质场地多震相自由场反演流程图

Figure 2. Flow chart of multi-phase free-field inversion in layered media

下载: 全尺寸图片幻灯片

图 3 半空间场地模型

Figure 3. Model of half-space

下载: 全尺寸图片幻灯片

图 4 控制点O处Rayleigh面波位移时程

Figure 4. Time histories of displacement of Rayleigh waves at control point O

下载: 全尺寸图片幻灯片

图 5 两种反演方法在P点处的位移和应力自由场结果对比

Figure 5. Comparison of free-field displacements and stresses at point P between two inversion methods

下载: 全尺寸图片幻灯片

图 6 反演结果与真实钻孔记录位移时程对比

Figure 6. Comparison of time histories of displacement between inverted results and real downhole recordings

下载: 全尺寸图片幻灯片

图 7 土-结构有限元模型

Figure 7. Finite element mode for soil-structure

下载: 全尺寸图片幻灯片

图 8 FKSH11场地多震相反演与单震相反演自由场响应对比

Figure 8. Comparison of inverted free-field responses between multi-phase and single-phase inversion methods at FKSH11 site

下载: 全尺寸图片幻灯片

图 9 FKSH11场地综合体结构左塔楼地震响应

Figure 9. Seismic responses exhibited by left tower of urban complex building at FKSH11 site

下载: 全尺寸图片幻灯片

图 10 FKSH11场地综合体结构地下连续墙塑性损伤

Figure 10. Plastic damages exhibited by basement exterior wall of urban complex building at FKSH11 site

下载: 全尺寸图片幻灯片

表 1 选取的地震动信息

Table 1 Information of selected earthquake events

事件（年份）	震级 (M_W)	台站（场地类别）	震中距/km	地表PGA/(cm·s^-2) 径向/切向/竖向	地表（钻孔）面波能量占比/% Rayleigh/Love波	钻孔深度/m
Tottori (2000)	6.61	HRSH07（软夹型）	127.69	88.10/73.13/42.59	33/30 (29/34)	102
Tottori (2000)	6.61	HYGH12（软夹型）	115.44	57.27/76.97/27.85	58/27 (70/26)	100
Niigata (2004)	6.63	TCGH07（递增型）	72.65	91.15/125.75/66.18	56/32 (73/35)	100
Chuetsu (2007)	6.80	FKSH02（硬夹型）	113.75	34.17/36.46/14.76	40/26 (57/26)	100
Iwate (2008)	6.90	IWTH12（递增型）	133.63	71.68/83.90/36.68	58/22 (50/26)	100
Iwate (2008)	6.90	FKSH11（硬夹型）	208.91	35.18/23.39/12.47	38/39 (54/40)	115

下载: 导出CSV
